Matsui DMZ2 Series Manuel utilisateur
performance
portability
durability
The reliable choice in portable dehumidifying dryers.
dmz2 series
Introducing the
DMZ2 Dehumidifying Dryer.
Versatile, high performance
in a compact, portable design. dmz2 series
Only from Matsui.
packed with performance
The DMZ2 is the ideal dehumidifying dryer to inte-
grate with your central loading system or to handle
multiple hoppers. It offers more features as stan-
dard equipment with a smaller footprint than com-
parable systems, giving you maximum performance
in minimal space.
virtually maintenance-free
The DMZ2’s rotor has a 15-year life, designed to run
without replacement. Heater circuits have solid-
state relays, providing 10 years of maintenance-free
operation. Routine maintenance can be performed
from the front of the system, quickly and easily.
ideal for pet bottle production
The ideal unit when exceptional quality is impera-
tive, the DMZ2 maintains stable IV and low AA lev-
els, and brings moisture content below 50 ppm. It
can dry PET in as little as 3 hours and has through-
put up to 1500 kg/hr and larger.
high performance hopper design
The DMZ2’s drying hopper uses a
unique diffuser-cone technology to
create mass flow with no short
pass. This ensures all resin leaving
the hopper is consistently dry and
up to temperature. Smaller units have a
tilt-open feature to make cleanups and
resin-changes fast and easy.
touchpad programming
An easy-to-use touchpad simplifies programming,
enabling you to preset operations, monitor settings,
view progress and make changes effortlessly.
energy-saving production
Insulated stainless steel construction prevents heat
loss, and while drying resin in half the time, it saves
hours of energy with every material change.
Take a look at what the new DMZ2 offers:
Matsui’s desiccant rotor technology has become the
industry standard in dehumidifying hot-air drying equipment.
Its unique, honeycomb design—molecular sieve desiccant, bond-
ed and then baked onto ceramic paper—eliminates powder that
can contaminate the system. Its large contact area effectively
absorbs at high temperatures, drying resin in half the time while
stabilizing dew points at a constant –40˚F.
Resin Other Desiccant
Dryers Dryers
Polycarbonate 3–4 hours 1.5 hours
Nylon 4–6 hours 2.5 hours
PET 6–8 hours 3.0 hours
Single Tower Type Dehumidifier
Multi-Tower Type Dehumidifier
Desiccant Rotor System
the dmz2 dries resin faster.
and it stabilizes dew points.
Desiccant rotor technology cuts drying time
Regeneration Heating Zone
Cooling Zone
Dehumidifying Zone
the stream of air inside the rotor
Compare Matsui to the competition:
Return Air
Dehumidified Air
Rotor Removes Moisture
Moisture Removed from Rotor
Constant dry heat for the best drying environment.
now in a compact portable design.
Return Air
Dehumidified Air
Regeneration
Exhaust
Regeneration Air Filter
Regeneration Blower
Regeneration Heater
Desiccant Absorption Rotor
To Desiccant Rotor
Drying Heater
Drying Blower
Aftercooler
chicago headquarters
1250 West Lunt Avenue |Elk Grove Village, IL 60007 |T 847-290-9680 |F 847-290-9685
dmz2 series specifications
Matsui America
www.matsuiamerica.com
los angeles office
1240 North Lakeview, Suite 180 |Anaheim, CA 92807 |T 714-693-1101 |F 714-693-1345
available options Weekly Timer, Dew Point Meter, Filter Alarm, Floor Frame, V-Box, Insulated Hopper
Portable Dryer Dimensions LxWxH (inches)
dmz2-40-15 37 x 27 x 56H
dmz2-40-25 37 x 31 x 62H
dmz2-80-50 45 x 31 x 72H
dmz2-120-75 45 x 34 x 72H
dmz2-120-100 45 x 34 x 78H
dmz2-120-150 50 x 44 x 84H
dmz2-170-150 67 x 44 x 84H
dmz2-170-200 67 x 44 x 94H
dmz2-240-250 67 x 47 x 96H
dmz2-240-300 67 x 47 x 102H
Outer Dimensions of Hopper Dryer(inches)
Model A B C
hd-15 11 24 25
hd-25 16 30 36
hd-50 16 30 46
hd-75 20 33 45
hd-100 20 33 53
hd-150 26 42 55
hd-200 26 42 64
hd-250 31 48 65
hd-300 31 48 71
A
B
C
W
L
H
dmz2 model 40U 80U 120U 170U 240U
dew point (˚f) -40
airflow (cfm) 23 47 70 106 165
available hoppers (lbs.) 33 or 55 110 165, 220 or 330 330 or 440 550 or 660
hopper volume (ft3) 0.88 or 1.4 3.0 4.4, 6.0 or 8.8 4.4 or 12.0 14.8 or 17.6
drying blower (kw) .50 .85 1.55 1.75 2.55
regeneration blower (kw) .057 .113 .420 1.15
drying heater (kw) 1.5 (2.1H) 2.4 (4.0H) 3.3 (6.0H) 4.0 (7.8H) 6.0 (12.4H)
regeneration heater (kw) 1.5 2.4 3.1 5.8 7.7
absorbent Zeoliterotor
absorbent motor (kw) .015
aftercooler flow (gpm) 1.5 3.7 4.0 5.2
aftercooler connection (inches) 3/8”
control Microprocessor w/PID Heating
auto start timer Range: 10-min to 99hrs 50min
alarm & protection Overheat, Thermal Trip, Reverse Phase, Automatic Cool Down
power supply (volts) 230V or 460V 3ph, 60Hz
maximum temperature 266ºF (H-356ºF)
breaker-amps (230/460V) 20/20 30/40 40/50 50/30 75/40
hi-temp model 60/40 100/50
weight (lbs) 264 352 440 760 800
approximate dimensions (inches) 17 x 22 x 52H 20 x 28 x 53H 31 x 35 x 72H
