Matrox Meteor Instructions de montage

Artisan Technology Group is your source for quality

new and certied-used/pre-owned equipment

• FAST SHIPPING AND

DELIVERY

• TENS OF THOUSANDS OF

IN-STOCK ITEMS

• EQUIPMENT DEMOS

• HUNDREDS OF

MANUFACTURERS

SUPPORTED

• LEASING/MONTHLY

RENTALS

• ITAR CERTIFIED

SECURE ASSET SOLUTIONS

SERVICE CENTER REPAIRS

Experienced engineers and technicians on staff

at our full-service, in-house repair center

WE BUY USED EQUIPMENT

Sell your excess, underutilized, and idle used equipment

We also offer credit for buy-backs and trade-ins

www.artisantg.com/WeBuyEquipment

REMOTE INSPECTION

Remotely inspect equipment before purchasing with

our interactive website at www.instraview.com

LOOKING FOR MORE INFORMATION?

Visit us on the web at www.artisantg.com for more

information on price quotations, drivers, technical

specications, manuals, and documentation

View

Instra

6HSWHPEHU

0DQXDOQR07

0DWUR[0HWHRU

,QVWDOODWLRQDQG+DUGZDUH5HIHUHQFH

Matrox®is a registered trademark of Matrox Electronic Systems Ltd.

Microsoft®, MS-DOS®, Windows®, and Windows NT® are registered

trademarks of Microsoft Corporation.

Intel®, Pentium®, and Pentium II® are registered trademarks of Intel

Corporation.

Texas Instruments is a trademark of Texas Instruments Incorporated.

RAMDAC™ is a trademark of Booktree.

All other nationally and internationally recognized trademarks and

tradenames are hereby acknowledged.

Disclaimer: Matrox Electronic Systems Ltd. reserves the right to make

changes in specifications at any time and without notice. The

information provided by this document is believed to be accurate and

reliable. However, no responsibility is assumed by Matrox Electronic

Systems Ltd. for its use; nor for any infringements of patents or other rights

of third parties resulting from its use. No license is granted under any

patents or patent rights of Matrox Electronic Systems Ltd.

PRINTED IN CANADA

Contents

Chapter 1: Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . .7

Matrox Meteor . . . . . . . . . . . . . . . . . . . . . . . . .8

Acquisition . . . . . . . . . . . . . . . . . . . . . . . . . .9

Data transfer . . . . . . . . . . . . . . . . . . . . . . .10

Software . . . . . . . . . . . . . . . . . . . . . . . . . . .10

What you need to get started. . . . . . . . . . . . . .12

Inspecting the Matrox Meteor package . . . . . .13

Standard package. . . . . . . . . . . . . . . . . . . .13

Optional parts . . . . . . . . . . . . . . . . . . . . . .13

Handling components. . . . . . . . . . . . . . . . .14

Installation overview . . . . . . . . . . . . . . . . . . . .15

Chapter 2: Hardware installation . . . . . . . . . . . . . . . . . .17

Installing Matrox Meteor . . . . . . . . . . . . . . . . .18

Attaching a video input. . . . . . . . . . . . . . . . . .21

No circuitry protection . . . . . . . . . . . . . . . .21

Chapter 3: Installing software. . . . . . . . . . . . . . . . . . . . .23

Installing the software. . . . . . . . . . . . . . . . . . .24

Note about Intellicam . . . . . . . . . . . . . . . . . . .24

Chapter 4: Transferring data . . . . . . . . . . . . . . . . . . . . . .25

Transfer speeds . . . . . . . . . . . . . . . . . . . . . . .26

Chapter 5: Using multiple Matrox Meteor boards . . . . 27

Using multiple Matrox Meteor boards. . . . . . . 28

Multiple board installation . . . . . . . . . . . . . . . 28

Grabbing simultaneously from different boards29

Number of cameras per board . . . . . . . . . . . . 30

PCI bandwidth requirements . . . . . . . . . . . . . 31

Chapter 6: Using Matrox Meteor/

RGB’s trigger input capability. . . . . . . . . . . 33

Using the Matrox Meteor trigger . . . . . . . . . . . 34

Signal paths and requirements . . . . . . . . . 34

TTL pulse . . . . . . . . . . . . . . . . . . . . . . . . . 35

Pulse width . . . . . . . . . . . . . . . . . . . . . . . . 35

No circuitry protection . . . . . . . . . . . . . . . . 36

Appendix A: Troubleshooting. . . . . . . . . . . . . . . . . . . . . 37

Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . 38

Common problems and solutions . . . . . . . . . . 38

Contacting Matrox . . . . . . . . . . . . . . . . . . . . . 41

Appendix B: Technical information . . . . . . . . . . . . . . . . 43

Technical information . . . . . . . . . . . . . . . . . . 44

Global information. . . . . . . . . . . . . . . . . . . 44

Grab information. . . . . . . . . . . . . . . . . . . . 44

Data transfers . . . . . . . . . . . . . . . . . . . . . . 45

Board input . . . . . . . . . . . . . . . . . . . . . . . . . .46

DB-9 female connector . . . . . . . . . . . . . . . .46

S-VHS connector . . . . . . . . . . . . . . . . . . . .47

Phono connector. . . . . . . . . . . . . . . . . . . . .47

Specifications . . . . . . . . . . . . . . . . . . . . . . . . .48

Electrical . . . . . . . . . . . . . . . . . . . . . . . . . .48

Environmental . . . . . . . . . . . . . . . . . . . . . .48

Appendix C: Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . .49

Customer support

❖Note, when a reference is made to Matrox Meteor or Matrox Meteor/RGB, the

information that follows also applies to the version of these boards that includes

the integrated PCI-to-PCI bridge.

Chapter 1: Introduction

This chapter briefly describes the features of Matrox

Meteor.

8 Chapter 1: Introduction

Matrox Meteor

Matrox Meteor is a single-slot, monochrome and color PCI

frame grabber. It features real-time transfers to off-board

system or display RAM (depending on the system and VGA

board used) and provides support for live video-in-a-window.

You can use the Matrox Imaging Library (MIL) or any of its

derivatives to program Matrox Meteor.

Matrox Meteor comes in four versions:

■Matrox Meteor, a standard monochrome and color frame

grabber.

■Matrox Meteor/PPB, a standard monochrome and color

frame grabber with an integrated PCI-to-PCI bridge.

■Matrox Meteor/RGB, an RGB color frame grabber.

■Matrox Meteor/PPB/RGB, an RGB color frame grabber with

an integrated PCI-to-PCI bridge.

❖Note, when a reference is made to Matrox Meteor or Matrox

Meteor/RGB, the information that follows also applies to the

version of these boards that includes the integrated

PCI-to-PCI bridge.

Matrox Meteor 9

Acquisition

Matrox Meteor boards have standard monochrome and color

acquisition capabilities. They accept RS-170/CCIR

monochrome video signals and NTSC/PAL color video signals

in either a composite or Y/C (S-Video or S-VHS) format. They

have four software-selectable video input channels for

interfacingwithuptofourvideosources.Furthermore,foreasy

signal calibration, they support programmable brightness,

contrast, hue, and saturation.

Meteor/RGB boards provide support for component RGB

acquisition, with independent gain and offset controls for each

channel. They support all of Meteor’s input capabilities, except

for color video signals in Y/C format. This capability has been

exchanged for support of a synchronous trigger input (by way

of the Y/C connector).

For added flexibility, the Meteor/RGB frame grabber can

simultaneously grab from up to three standard monochrome

video sources, provided the sources are genlocked.In this case,

thethreeinputscannotbedisplayedinreal-timesincethevideo

data is packed (consecutive pixels belong to different channels).
