Marshall Electronics VS-103E-HDSDI Manuel utilisateur

VS-103E-HDSDI

Marshall Electronics

•Encodes2channelsofEmbeddedAudiofromHDMIorHDSDIinput

•PoE(PowerOverEthernet802.3af)

•USBRecording

•WatchdogforSystemRecovery

•RS-232,RS-422/485Communication

•MotionDetection

•2CHSensorInput/2CHAlarmOutput

•AdjustableVideoBitrate:32Kbps~16MbpsforPrimaryVideo,32Kbps~1MbpsforSecondaryVideo

•AdjustableVideoDataBandwidth:2,400bps~115,200bps

•VariousProtocols:TCP/IP,Multicast,UDP,HTTP,SMTP,FTP,DHCP,DNS,DynamicDNS,RTP,RTSP,SNMP

•FullTechnicalSupportwithSDK&API

èSupports60fpsat1920x1080Resolution

è3G-HD/SD-SDI,HDMIandCompositevideoinputs

èEncodesAudioEmbeddedfromHD/SD-SDI&HDMIinputs

èDualStreaming(H.264/H.264,H.264/MJPEG)

èMPEG2-TSSupported

èTwoWayAudioCommunication(G.711,AAC)

èHD/SD-SDI,HDMI&AnaloginputAudio

èOver30TypesofPTZProtocolSupported

èCompliantwithONVIF,PSIA

1080p60 Full HD Video Encoder with Embedded Audio

Broadcast / Multimedia Division

FRONT

www.LCDracks.com 800-800-6608

REAR

Encodes 2 channels of Embedded Audio from HDMI or HDSDI input

Price: $2,599.00

VS-103E-HDSDI Specifications

Features, specications, pricing, and dimensions are subject to change without notice.

Physical appearance of products may vary slightly from images shown on this document. Please visit our website for updates and information.

www.LCDracks.com 800-800-6608

System

System Mode Encoder

Encoding Mode Normal / MPEG2-TS mode

Network

Network Interface Ethernet 10/100Base-T (RJ-45)

Network Protocol TCP/IP, UDP, Multicast, DHCP, SMTP,

HTTP, HTTPS, SNMP, RTP, RTSP,PSIA, ONVIF

Video

Compression Main Stream: H.264

Secondary Stream: H.264 / MJPEG

Data Rate 32Kbps ~ 8Mbps

Resolution 1920x1080/p60 ~ 352x240/30fps, 18 resolution step

PC Resolution HDMI Input format: 800 x 600, 1280 x 1024, 1440 x 900,

1440 x 900

Input 1 1 x HDMI type A, HDMI RX

Input 2 1 x Composite (BNC Type)

Input 3 1 x HD/SD-SDI (BNC Type) – (VS-103E-HDSDI only)

Motion Detection Sensitivity Adjustable

Audio

Compression G.711 , AAC

Sample Rate G.711: 8KHz, AAC: 32KHz

Data Rate G.711: 64Kbps, AAC: 64Kbps, 128Kbps

Input 1 x Line-In (3.5mm Stereo) 2 channels of Embedded Audio

Output 1 x Line-Out (3.5mm Stereo )

Serial

Port 1 1 x RS-232 (Terminal Block)

Port 2 1 x RS-422/485 (Terminal Block)

Data Rate 2,400bps ~ 115,200bps

Sensor Sensor Input 2 x NO Contact (Terminal Block)

Alarm Alarm Output 2 x NO Contact (Terminal Block)

Reset

Audible Beep 1 x Buzzer 88dB Min

Reset Button 1 x Factory Reset Button

User Interface System Status LED

Storage Recording/Backup 1 x USB 2.0 Port

Security Authentification 4 levels of user authentification, IP address Filtering, HTTPS Encryption

Software VMS 16 Included 16CH Recording & Live Monitoring with Search & Playback

Physical

Dimension 134.08(W) x 125.5(D) x 36.87(H)mm / 5.28(W) x 4.94(D) x 1.45(H)in

Weight 504g / 1.11lb

Power Source DC 12V/0.8A, PoE (Power over Ethernet): 802.3af

Power Consumption Max 9.6W

Operating Temp. -10°C ~ 50°C / 14°F ~ 122°F
