Mark MBAR 120 Manuel utilisateur

Rev. 16.04.01

MBAR 120

User Manual / Instrucciones de Usuario

UP DOWN INC DEC

MBAR 120

Our DMX indoor MBAR 120 ( 8 sections) offers many possibilities to achieve the effects

which you want. The rolling and chasing effects are very good. It is designed for the stages,

disco, night clubs etc, even the building halls.

1. Weight: 3kg

2. Dimensions: 1000*70*90 mm

3. Power input: AC100-220V/50-60Hz

4. Consumption: 125W

5. LEDS: 80 1.5W 3IN1 LEDs

6. Beam angle: 40 degree

7. 3 pin female XLR socket and 3 pin male XLR socket

10. Built-in microphone

11. Black aluminum material

12.Working place: indoor, temperature:-20℃~45 ,humidity:0%-90%

13. LED display for easier operation

14.Built-in programs, stand alone, DMX mode, music active, static color

15. 6 selectable DMX modes: 2.3.4.7.14.26 DMX channels mode

℃

POWER INPUT

DMX INPUT

DMX OUTPUT POWER OUTPUT

MBAR 120 User Manual/Manual de uso P 1

LED DISPLAY FUNCTIONS

A001 A512

E001

P001

H001

b000

EF00

4F00

3F00

2F00

1F00

8E00

7E00

6E00

5E00F500

UP UP

DOWN

INC

DEC

INC

INCINC

DEC

DECDEC

SLAE

Slave mode

000 255

000

d001

C001

255

1E00

INC

DEC

2E00

INC

DEC

4E00

UP DOWN

INC

DEC

3E00

UP DOWN

INC

DEC

d512

C512

E512

P512

H512

b255

F520

1E20

2E20 3E20

4E20

5E20

6E20

7E20

8E20

1F20

2F20

3F20

4F20

EF20

Program 3

Program 4

Program 5

Program 6

Program 7

Program 8

SU00 INC

DEC Sound

SU20

DOWN

Program 9

Program 10

Program 11

Program 12

Program 13

DMX mode 1

DOWN

Strobe

DOWN

Program 1

DOWN

Manual red dimmer

Manual green dimmer

Manual blue dimmer

Program 2

DMX mode 2

DMX mode 3

DMX mode 4

DMX mode 5

DMX mode 6

MBAR 120 User Manual/Manual de uso P 2

DMX value as follows:

DMX mode 1

CH1 CH2

NO.

DMX value FUNCTION SPEED

0-11

12-23

24-35

36-47

48-59

60-71

72-83

84-95

96-107

108-119

120-131

132-143

144-155

156-167

168-179

180-191

192-203

204-215

216-227

228-239

252-255

Red

Green

Blue

Yellow

Purple

Cyan

White

PROGRAM01

PROGRAM02

PROGRAM03

PROGRAM04

PROGRAM05

PROGRAM06

PROGRAM07

PROGRAM08

PROGRAM09

PROGRAM10

PROGRAM11

PROGRAM12

PROGRAM13

Sound Mode

SPEED

0-255

Sensitivity 0-255

DMX mode 2

CH1 CH2 CH3

R G B

0-255 dimming 0-255 dimming 0-255 dimming

DMX mode 3

CH1 CH2 CH3 CH4

R G B

0-255 dimming 0-255 dimming 0-255 dimming 0-255 dimming

Master dimmer

21 240-251

OFF

DMX mode 4

CH1 CH2 CH3 CH4

RGB

CH5

0-255 dimming 0-255 dimming 0-255 dimming 0-255 dimming 0-255 dimming 0-255 dimming

CH6 CH7

B R

0-255 dimming

MBAR 120 User Manual/Manual de uso P 3

DMX mode 5

CH1 CH2 CH5 CH6 CH7

CH3 CH4

R G B NO. DMX value FUNCTION SPEED FLASH Master

dimmer

0-255

dimming

0=OFF

0-255

dimming

0=OFF

0-255

dimming

0=OFF

0-11

12-23

24-35

36-47

48-59

60-71

72-83

84-95

96-107

108-119

120-131

132-143

144-155

156-167

168-179

180-191

192-203

204-215

216-227

228-239

252-255

Red

Green

Blue

Yellow

Purple

Cyan

White

PROGRAM01

PROGRAM02

PROGRAM03

PROGRAM04

PROGRAM05

PROGRAM06

PROGRAM07

PROGRAM08

PROGRAM09

PROGRAM10

PROGRAM11

PROGRAM12

PROGRAM13

Sound Mode

240-251

OFF

SPEED

0-255

0-4 OFF

FLASH

5-255

0-255

dimming

(0=OFF)

Sensitivity

0-255

DMX mode 6

CH1 CH2 CH3 CH4 CH5 CH6 CH7 CH8 CH9

CH10 CH11 CH12 CH13 CH14 CH15 CH16 CH17 CH18

CH19 CH20 CH21 CH22 CH23 CH24 CH25 CH26

R G B

0-255 dimming 0-255 dimming 0-255 dimming

R G B

0-255 dimming 0-255 dimming 0-255 dimming

R G B

0-255 dimming 0-255 dimming 0-255 dimming

R G B

0-255 dimming 0-255 dimming 0-255 dimming

R G B

0-255 dimming 0-255 dimming 0-255 dimming

R G B

0-255 dimming 0-255 dimming 0-255 dimming

R G B

0-255 dimming 0-255 dimming 0-255 dimming

R G B

0-255 dimming 0-255 dimming 0-255 dimming

flash Master dimmer

0-255

flash

0=OFF

0-255

Light

0=OFF

CH8 CH9 CH10 CH11 CH12 CH13 CH14

G B R G B flash Master dimmerd

0-255 dimming 0-255 dimming 0-255 dimming 0-255 dimming 0-255 dimming 0-255 Flash

frequency 0-255 dimming

MBAR 120 User Manual/Manual de uso P 4

UP DOWN INC DEC

MBAR 120

Nuestra barra LED para interior MBAR 120 ( 8 secciones) ofrece muchas posibilidades para

conseguir el efecto deseado. La rotación de colores y chases es muy fluida. Diseñado para

escenarios, discotecas, salas de fiesta, etc.

1. Peso: 3kg

2. Dimensiones: 1000*70*90 mm

3. Alimentación: AC100-220V/50-60Hz

4. Consumo: 125W

5. LEDs: 80 LEDs 1.5W cada uno, 3en1

6. Ángulo del haz: 40 degree

7. Conector XLR3 macho y XLR 3 hembra

8. Micrófono integrado

9. Acabado en aluminio, color negro

10. Ambiente de uso: interior, temperatura:-20℃~45 , humedad:0%-90%

11. Display LED para selección de funciones

12. Programas incorporados, stand alone, modo DMX, activo por audio, colores estáticos

13. 6 modos DMX seleccionables: 2.3.4.7.14.26 canales DMX

℃

ALIMENTACION

DMX INPUT

DMX OUTPUT ALIMENTACION (Salida)

MBAR 120 User Manual/Manual de uso P 5

FUNCIONES EN PANTALLA

A001 A512

E001

P001

H001

b000

EF00

4F00

3F00

2F00

1F00

8E00

7E00

6E00

5E00F500

UP UP

DOWN

INC

DEC

INC

INCINC

DEC

DECDEC

SLAE

Modo Esclavo

000 255

000

d001

C001

255

1E00

INC

DEC

2E00

INC

DEC

4E00

UP DOWN

INC

DEC

3E00

UP DOWN

INC

DEC

d512

C512

E512

P512

H512

b255

F520

1E20

2E20 3E20

4E20

5E20

6E20

7E20

8E20

1F20

2F20

3F20

4F20

EF20

Program 3

Program 4

Program 5

Program 6

Program 7

Program 8

SU00 INC

DEC Sound

SU20

DOWN

Program 9

Program 10

Program 11

Program 12

Program 13

DMX modo 1

DOWN

Strobo

DOWN

Program 1

DOWN

Dimmer Rojo manual

Dimmer Verde manual

Dimmer Azul manual

Program 2

DMX modo 2

DMX modo 3

DMX modo 4

DMX modo 5

DMX modo 6

MBAR 120 User Manual/Manual de uso P 6

Modos DMX

DMX modo 1

CH1 CH2

NO.

Valor DMX FUNCION VELOCIDAD

0-11

12-23

24-35

36-47

48-59

60-71

72-83

84-95

96-107

108-119

120-131

132-143

144-155

156-167

168-179

180-191

192-203

204-215

216-227

228-239

252-255

Red

Green

Blue

Yellow

Purple

Cyan

White

PROGRAM01

PROGRAM02

PROGRAM03

PROGRAM04

PROGRAM05

PROGRAM06

PROGRAM07

PROGRAM08

PROGRAM09

PROGRAM10

PROGRAM11

PROGRAM12

PROGRAM13

Sound Mode

VELOCIDAD

0-255

Sensibilidad 0-255

DMX modo 2

CH1 CH2 CH3

R G B

0-255 dimming 0-255 dimming 0-255 dimming

DMX modo 3

CH1 CH2 CH3 CH4

R G B

0-255 dimmer 0-255 dimmer 0-255 dimmer 0-255 dimmer

Master dimmer

21 240-251

OFF

DMX modo 4

CH1 CH2 CH3 CH4

RGB

CH5

0-255 dimmer 0-255 dimmer 0-255 dimmer 0-255 dimmer 0-255 dimmer 0-255 dimmer

CH6 CH7

B R

0-255 dimming

MBAR 120 User Manual/Manual de uso P 7

DMX modo 5

CH1 CH2 CH5 CH6 CH7

CH3 CH4

R G B NO. valor DMX FUNCION VELOCIDAD FLASH Master

dimmer

0-255

dimmer

0=OFF

0-255

dimmer

0=OFF

0-255

dimmer

0=OFF

0-11

12-23

24-35

36-47

48-59

60-71

72-83

84-95

96-107

108-119

120-131

132-143

144-155

156-167

168-179

180-191

192-203

204-215

216-227

228-239

252-255

Rojo

Verde

Azul

Amarillo

Púrpura

Cyan

Blanco

PROGRAM01

PROGRAM02

PROGRAM03

PROGRAM04

PROGRAM05

PROGRAM06

PROGRAM07

PROGRAM08

PROGRAM09

PROGRAM10

PROGRAM11

PROGRAM12

PROGRAM13

Modo Audio

240-251

OFF

VELOCIDAD

0-255

0-4 OFF

FLASH

5-255

0-255

dimmer

(0=OFF)

Sensibilidad

0-255

DMX modo 6

CH1 CH2 CH3 CH4 CH5 CH6 CH7 CH8 CH9

CH10 CH11 CH12 CH13 CH14 CH15 CH16 CH17 CH18

CH19 CH20 CH21 CH22 CH23 CH24 CH25 CH26

R G B

0-255 dimmer 0-255 dimmer 0-255 dimmer

R G B

0-255 dimmer 0-255 dimmer 0-255 dimmer

R G B

0-255 dimmer 0-255 dimmer 0-255 dimmer

R G B

0-255 dimmer 0-255 dimmer 0-255 dimmer

R G B

0-255 dimmer 0-255 dimmer 0-255 dimmer

R G B

0-255 dimmer 0-255 dimmer 0-255 dimmer

R G B

0-255 dimmer 0-255 dimmer 0-255 dimmer

R G B

0-255 dimmer 0-255 dimmer 0-255 dimmer

flash Master dimmer

0-255

flash

0=OFF

0-255

Light

0=OFF

CH8 CH9 CH10 CH11 CH12 CH13 CH14

G B R G B flash Master dimmerd

0-255 dimmer 0-255 dimmer 0-255 dimmer 0-255 dimmer 0-255 dimmer 0-255 Frecuencia

flash 0-255 dimming

MBAR 120 User Manual/Manual de uso P 8
