Marantz NR1506 Manuel utilisateur
.
AV Surround Receiver
NR1506
Owner’s Manual
You can print more than one page of a PDF onto a single sheet of paper.
Contents Connections Playback Settings Tips Appendix
1
Front panel Display Rear panel Remote Index
Accessories 7
Inserting the batteries 8
Operating range of the remote control unit 8
Features 9
High quality sound 9
High performance 9
Easy operation 12
Part names and functions 13
Front panel 13
Display 16
Rear panel 18
Remote control unit 21
Connections
Connecting speakers 25
Speaker installation 25
Speaker connection 27
Connecting a TV 32
Connection 1 : TV equipped with an HDMI connector and
compatible with the ARC (Audio Return Channel) 33
Connection 2 : TV equipped with an HDMI connector and
incompatible with the ARC (Audio Return Channel) 34
Connection 3 : TV equipped without an HDMI connector 35
Connecting a playback device 36
Connecting a set-top box (Satellite tuner/cable TV) 37
Connecting a DVD player or Blu-ray Disc player 38
Connecting a video camcorder or game console 39
Connecting an iPod or USB memory device to the USB port 40
Connecting an FM/AM antenna 42
Connecting to a home network (LAN) 44
Wired LAN 44
Wireless LAN 45
Connecting an external control device 46
REMOTE CONTROL jacks 46
Connecting the power cord 47
Playback
Basic operation 49
Turning the power on 49
Selecting the input source 49
Adjusting the volume 50
Turning off the sound temporarily (Muting) 50
Playback a DVD player/Blu-ray Disc player 50
Contents Connections Playback Settings Tips Appendix
Contents
2
Front panel Display Rear panel Remote Index
Playing an iPod 51
Listening to music on an iPod 52
iPod Browse Mode settings 53
Performing repeat playback 55
Performing random playback 55
Playing a USB memory device 56
Playing files stored on USB memory devices 57
Listening to music on a Bluetooth device 59
Playing music from Bluetooth device 60
Pairing with other Bluetooth devices 62
Reconnecting to this unit from a Bluetooth device 63
Listening to FM/AM broadcasts 64
Listening to FM/AM broadcasts 65
Tuning in by entering the frequency (Direct Tune) 67
RDS search 67
PTY search 68
TP search 69
Radio Text 69
Changing the tune mode (Tune Mode) 70
Tuning in to stations and presetting them automatically (Auto
Preset) 70
Presetting the current broadcast station (Preset Memory) 71
Listening to preset stations 71
Specify a name for the preset broadcast station (Preset Name) 72
Skipping preset broadcast stations (Preset Skip) 73
Cancelling Preset Skip 74
Listening to Internet Radio 75
Listening to Internet Radio 76
Playing the last played Internet Radio station 77
Using vTuner to add Internet Radio stations to favorites 78
Playing back files stored on a PC and NAS 79
Applying media sharing settings 80
Playing back files stored on a PC and NAS 81
Contents Connections Playback Settings Tips Appendix
3
Front panel Display Rear panel Remote Index
AirPlay function 83
Playing songs from your iPhone, iPod touch or iPad 84
Playing iTunes music with this unit 84
Selecting multiple speakers (devices) 85
Perform iTunes playback operations with the remote control unit
of this unit 85
Spotify Connect function 86
Playing Spotify music with this unit 86
Convenience functions 87
Performing repeat playback 88
Performing random playback 88
Registering to Favorites 89
Playing back content added to the “Save to Favorite” 89
Deleting content added to favorites 90
Searching content with keywords (Text Search) 90
Playing back music and a favorite picture at the same time
(Slideshow) 91
Setting the Slideshow Interval 92
Adjusting the volume of each channel to match the input source
(Ch Level Adjust) 93
Adjusting the tone (Tone) 94
Displaying your desired video during audio playback (Video
Select) 95
Selecting a sound mode 96
Selecting a sound mode 97
Direct playback 98
Pure Direct playback 98
Auto surround playback 99
HDMI control function 106
Setting procedure 106
Smart Menu function 107
Sleep timer function 109
Using the sleep timer 110
Smart select function 111
Calling up the settings 112
Changing the settings 113
Web control function 114
Controlling the unit from a web control 114
Panel lock function 116
Disabling all key button operations 116
Disabling all button operations except VOLUME 116
Canceling the Panel lock function 117
Remote lock function 118
Disabling the sensor function of the remote control unit 118
Enabling the remote sensor function 118
Contents Connections Playback Settings Tips Appendix
4
Front panel Display Rear panel Remote Index
Settings
Menu map 119
Menu operations 122
Inputting characters 123
Using the keyboard screen 124
Audio 125
Dialog Level 125
Subwoofer Level 125
Surr.Parameter 126
M-DAX 130
Audio Delay 131
Volume 131
Audyssey®132
Manual EQ 134
Video 137
HDMI Setup 137
On Screen Disp. 142
TV Format 143
Inputs 144
Input Assign 144
Source Rename 146
Hide Sources 146
Source Level 146
Input Select 147
Speakers 148
Audyssey® Setup 148
Procedure for speaker settings (Audyssey® Setup) 150
Error messages 157
Retrieving Audyssey® Setup settings 158
Manual Setup 159
Speaker Config. 159
Distances 161
Levels 162
Crossovers 163
Bass 164
Contents Connections Playback Settings Tips Appendix
5
Front panel Display Rear panel Remote Index
Network 165
Information 165
Connection 165
Wi-Fi Setup 166
Settings 169
Network Control 171
Friendly Name 171
Diagnostics 172
Maintenance Mode 173
General 174
Language 174
ECO 174
Smart Sel.Names 176
Front Display 177
Firmware 177
Information 179
Usage Data 181
Setup Lock 181
Tips
Tips 183
Troubleshooting 185
Resetting factory settings 201
Appendix
About HDMI 202
Playing back a USB memory devices 205
Playing back a Bluetooth device 206
Playing back a file saved on a PC or NAS 207
Playing back Internet Radio 208
Personal memory plus function 208
Last function memory 208
Sound modes and channel output 209
Sound modes and surround parameters 210
Types of input signals, and corresponding sound modes 213
Explanation of terms 216
Trademark information 224
Specifications 226
Index 231
License 234
Contents Connections Playback Settings Tips Appendix
6
Front panel Display Rear panel Remote Index
Thank you for purchasing this Marantz product.
To ensure proper operation, please read this owner’s manual carefully before using the product.
After reading this manual, be sure to keep it for future reference.
Accessories
Check that the following parts are supplied with the product.
.
Quick Start Guide CD-ROM
(Owner’s Manual)
Safety Instructions Notes on radio Cable labels
Power cord FM indoor antenna AM loop antenna Sound calibration
microphone
(ACM1HB)
Sound calibration
microphone stand
Remote control unit
(RC028SR)
R03/AAA batteries
Contents Connections Playback Settings Tips Appendix
7
Front panel Display Rear panel Remote Index
Inserting the batteries
1Remove the rear lid in the direction of the arrow and
remove it.
.
2Insert two batteries correctly into the battery
compartment as indicated.
.
R03/AAA batteries
3Put the rear cover back on.
NOTE
0To prevent damage or leakage of battery fluid:
0Do not use a new battery together with an old one.
0Do not use two different types of batteries.
0Remove the batteries from the remote control unit if it will not be in use for long
periods.
0If the battery fluid should leak, carefully wipe the fluid off the inside of the battery
compartment and insert new batteries.
Operating range of the remote control
unit
Point the remote control unit at the remote sensor when operating it.
.
Approx. 7 m
30° 30°
Contents Connections Playback Settings Tips Appendix
8
Front panel Display Rear panel Remote Index
Features
High quality sound
0With discrete circuit technology, the power amplifier provides
identical quality for all 5-channels (50 Watts x 5-channels)
For optimum realism and stunning dynamic range, the power amplifier
section features discrete power devices (not integrated circuitry).
By using high current, high power discrete power devices, the amplifier
is able to easily drive high quality speakers.
High performance
04K 60Hz input/output supported
.
When 4K Ultra HD (High Definition) is used, an input/output speed of 60
frames per second (60p) is achieved for video signals. When connected
to 4K Ultra HD and 60p video signal input compatible TV, you can enjoy
the sense of realism only available from high-definition images, even
when viewing fast-moving video.
This unit also supports image processing for 4K 60p, 4:4:4 and 24-bit
videos. By processing the video at the original resolution, this unit lets
you enjoy flawless, high-definition picture quality.
0HDCP 2.2
This unit is compatible with HDCP2.2 copyright protection standard.
Contents Connections Playback Settings Tips Appendix
9
Front panel Display Rear panel Remote Index
0HDMI connections enable connection to various digital AV
devices (6 inputs, 1 output)
.
61
OutIn
This unit is equipped with 6 HDMI inputs and 1 HDMI output enabling
connection to various HDMI compatible devices such as Blu-ray Disc
players, game consoles and HD video camcorders.
0The device is equipped with a AirPlay® function in addition to
network functions such as Internet radio etc. (v p. 83)
.
You can enjoy a wide variety of content, including listening to Internet
Radio, playing audio files stored on your PC, and displaying
photographs stored on your PC on our television.
This unit also supports Apple AirPlay which lets you stream your music
library from an iPhone®, iPad®, iPod touch® or iTunes®.
0Playback of DSD and FLAC files via USB and networks
This unit supports the playback of high resolution audio formats such as
DSD (2.8 MHz) and FLAC 192 kHz files. It provides high quality
playback of high resolution files.
Contents Connections Playback Settings Tips Appendix
10
Front panel Display Rear panel Remote Index
