Marantz SR8002 Manuel utilisateur

Life A TM

“room correction” strategies in that it improves the listening characteristics of your entire room rather than for just one or two seats.

audio system.

On the A/V side, the SR8002 features HDMI switching (version 1.3a) for up to four sources and two display devices. And there’s format conversion to HDMI

with Time Base Correction so even your older video sources will look their best. If you’re not quite ready for HDMI (or if your displays aren’t), the SR8002

advanced to enhance your enjoyment. Let’s put this even more succinctly – it’s a Marantz!

• THX Select 2 n

• 125 watts (into 8 ohms) x 7 ch. Amps

• Dolby Digital EX ®, Pro Logic IIx ®(Movie/Music/Game)

• DTS 96/24, ES ®, Neo:6, DTS-HD, Dolby True HD

• SRS Circle Surround II ®

• HDCD Decoder

• HDMI (V1.3a)repeating: 4-In/ 2-Out

• Video up-conversion (w/TBC) to HDMI with 480I/480P converter

• All discrete “Current Feedback” stages

• 32bit DSP

• 192 kHz/24-bit D/A converters for all channels

• Audyssey Auto Calibration

• HD compatible component video switching (4 in / 2 out)

• Assignable dual component video outputs

• Assignable video inputs

• XM-Ready with discrete IR commands

• XM-HD Surround

• Dielectric protected binding posts

• MDAX Marantz Dynamic Audio eXpander (improves compressed audio)

• Dolby Headphone

• Toroidal transformer

• Copper plated chassis

• 2nd Zone A/V and 3rd Zone Audio output

(Individual source) w/discrete commands

• Speaker A/B switching

• Lip sync. control

• RS-232C terminal for system control

• Direct IR Flasher input and IR Receiver input

• Dual IR Emitter outputs

• Dual DC Trigger outputs

• D-BUS (RC-5 In/Out) remote connection

• Shallow Chassis < 16”

• Learning/pre-programmed backlit remote with LCD

• 3 year limited warranty

Compatible

SR8002

THX SELECT2 DOLBY DIGITAL EX®/DTS ES®SURROUND RECEIVER

*All specications, dimensions and weights are subject to change without notice.

D&M Holdings, Marantz, Marantz America, Inc. or any of its subsidiaries will not assume any liability for errors in this spec sheet which may result in consequential errors being made by retail

dealers, designers, custom installers, cabinet makers or end users, etc based upon information contained within this document.

SR8002

Select 2

•(+ 96/24)

•

•(All 7ch)

Toroidal

192kHz/24-Bit

TI 32-Bit

•

Double Layered Copper Plated

•

Up to HDMI (w/ TBC)

•(Auddysey MultiEQ)

•

4 (1.3a)

4 (Assignable Inputs)

2(1.3a)

2 (Assignable)

FEATURES

MULTICHANNEL/SURROUND

Number of Channels

THX

DTS (HD, ES, Discrete 6.1/ Matrix 6,1, Neo-6)

Dolby Digital Plus

Dolby True-HD

Circle Surround II

SOUND ENHANCEMENTS

HDCD Decoder

Current Feedback Topology

Discrete Amplication

Power Transformer

D/A Conversion

Digital Signal Processing

Video O

Source Direct

Chassis

Variable X-over

Display O

Video Up-conversion

Auto Calibration

XM-Ready

AM/FM tuner

Bass management

Lip-sync (digital audio delay)

Software Upgradable (RS232)

IN/OUTPUTS

VIDEO

HDMI In

Component In

S-Video In

Composite In

HDMI Out

Component Out

S-Video Out

Composite Out

AUDIO

Analog L&R In

Analog L&R Out

Digital Optical In

Digital Coaxial In

Digital Optical Out

Digital Coaxial Out

IEEE1394 Connection

8ch

•

•(Composite & Component)

•

2/2

1/2

•(+ Digital Opt.)

•(Dolby Headphone)

1/1

125W x 7

105db

8Hz - 100kHz (+/- 3 dB)

8Hz - 45kHz (+/- 3 dB)

87.5 - 108.0MHz

Mono/Stereo: 75/70 dB

520 - 1710kHz

50 dB

5Hz - 80MHz (- 1 dB)

5Hz - 8MHz (- 1 dB)

60dB

Black

Aluminum

Learning/Pre-coded with LCD

RC8001SR

AC 120V/60Hz 780w

17 5/16" x 7 1/4" x 15 5/8"

33.1

IN/OUTPUTS (continued)

OTHER

Pre-Amplier Out

Main Amplier In

Multi-Channel In

Multi-Room Audio Out

Multi-Room Video Out

Multi-Room Speaker Out

Speaker A/B

External control (RS232C)

DC Triggers

D-Bus Remote (RC-5) In/Out

External IR In/Out

Front Panel A/V Inputs

Headphone Out

AC Outlets (Switched/Unswitched )

SPECIFICATIONS

AUDIO SECTION

Power Output (8 Ohm)

S/N Ratio

Freq. Response (Analog In)

Freq. Response (Dig In)

TUNER SECTION FM

Frequency Range

S/N Ratio (Mono/Stereo)

TUNER SECTION AM

Frequency Range

S/N Ratio

VIDEO SECTION

Video Freq. Response (Component)

Video Freq. Response (Composit, S-Video)

Signal to Noise

GENERAL

Color

Front Panel

Remote Control

Power Requirement

Power Consumption

Dimensions W" x H" x D" (Inches)

Weight (lbs)
