Maono DM20 Manuel utilisateur
User Manual
Gaming USB Microphone With Noise Cancelling
Maono[ˈmɑnoʊ], meaning "vision" in
Kiswahili, is the Global Best Selling Internet
Microphone Brand that products are sold
well in 153 countries worldwide. With the
beau�ful vision of becoming a global
leading brand of Internet audio products
that deliver a pleasant sound experience,
Maono is always working with audio
professionals, influencers, and users, to
make the world's best microphones and
audio products.
GLOBALBESTSELLING
INTERNET MICROPHONE
- 01 -
Packing List
User Manual ×1
USBA&CtoUSBC
2-in-1 Cable ×1
Condenser Microphone ×1
Connector ×1
Microphone
Capsule
Fastener
Desktop Stand
RGB Switch Noise Cancellation/
Mute
Shock Mount
Adjustable Gain
3.5mm
Headphone Jack
Pop Filter
USB-C
- 02 -
Product Overview
Product Description
Maono DM20 is a USB internet microphone specially designed
for game enthusiasts.On top of the high sampling rate,we have
added ENC noise reduction features to elevate the user
experience.
The simple and modern ascetics and adjustable RGB lighting
modes bring immersive visual enjoyment in game chat and
streaming; Coming with pop filter and shock mount,DM20 is an
all-in-one starter kit with USB-C plug and play, and suitable for
Discord,OBS,XSplit,Twitch,Youtube,Facebook and other
Internet applications.It also works with PlayStation 4 and
PlayStation 5 consoles.
Features
• ENC Noise cancellation • Controllable RGB lights
• Real-time monitoring • One-button mute
• Adjustable gain • Includes shock mount and pop filter
Specification
Mic Type
Polor Pattern
Frequency Response
Sampling Rate/Depth
Flexibility
S/N
Condenser Microphone
Cardioid
50Hz~20kHz
48kHz/24Bit
-3dBFS±3dB(Max gain)
73dB
- 03 -
- 04 -
Polar Pattern
50
+15
+10
+5
0
-5
-10
-15
-20 100 200 300 500 1k 2k 3k 5k 10k
Frequency Response
k
Connect to the Computer
Connect to Headphones
- 05 -
Note:
If you want to use the microphone with boom arms,please
follow instructions below.
1 . Turn the mic stand knob counterclockwise until the knob
and the bolt can be taken out from the pivot joint.Then
separate the microphone from the base bracket.
2. Align the connector with the microphone pivot joint,and
make sure the connector holes are aligned with pivot joint
holes.
①②③
- 06 -
3.Place the bolt into the
hexagonal hole and fix the
bolt’s head side with your
finger. In the meantime,screw
the bolt by turning the knob
clockwise until the
microphone is firmly fixed to
the connector.
- 07 -
①
②
4.Install the microphone to the boom arm by turning the
mic clockwise.
