Instrukcja obsługi
User’s Manual
/” ”42/”2291VTDEL
LED1902/LED2205/LED2402
www.manta.com.pl
www.manta.info.pl
Instrukcja obsługi
User’ s Manual
LED TV 19” / 22” / 24”
LED1902/LED2205/LED2402
SLEEP
PVRLIST
TS
FAV.CH
REC
?
P.MODE S.MODE P.SIZE
GUIDE
TEXT
SUBTITLE
DTV/RADIO
STOP
6
5
7
89
4
3
2
1
1. POWER button: turn the television on/switch it to stand-by mode
2. SOURCE button: select asignal source
3. MENU button: enter the menu
4. VOL- button: lower the volume
5. VOL+ button: increase the volume
6. CH- button: select the previous channel
7. CH+ button: select the next channel
8. Remote control sensor: receives the signal from the remote control
9. LED indicator light: shows the status of the device (green = on, red = stand-by mode)
12345
DC IN
PC
Audio
VGASCART Earphone
6
7
8
9
10
11
YPbPr CI AVRFUSB
AV: connect video output from aDVD or VCR
2.
1.
YPbPr: connect to aDVD player, set-top-box or another AV device with component video output
(YPbPr)
3.
RF: connect aVHF/UHF antenna or an antenna cable
4. SCART ers RGB,
AVsignals with audio input/output between the TV and the external device.
5.
VGA/PC Audio: connect to aPC or another device with aVGA connector
6.
Earphones : connect headphones
7.
DC 12V: connect apower adapter connector
8.
COAXIAL: connect to a5.1 audio system
9.
USB: connect aUSB device
10.
HDMI: connect an AV device with aHDMI connector
11.
CI: connect aCI module
DC IN
PC
Audio
VGASCART Earphone
DC IN
PC
Audio
VGASCART Earphone
YPbPr CI AVRFUSB
YPbPr CI AVRFUSB
YPbPr CI AVRFUSB
