Manhattan 160360 Manuel utilisateur

MAN-160360-UM-0606-03

5000 SERIES

5.1 MULTIMEDIA

SPEAKER SYSTEM

USER MANUAL

MODEL 160360

INTRODUCTION

Thank you for purchasing the MANHATTAN® 5000 Series 5.1 Multimedia Speaker System,

Model 160360.

These speakers feature internally powered ampliﬁers, making them compatible with computers

and CD and DVD players, including portable versions of such devices. They are also completely

shielded in terms of magnetization, and so will not interfere with the performance or operation

of your computer or TV monitor. Follow the simple setup steps, and you’ll soon be able to enjoy

these great features:

• Full-range speakers that enhance multimedia experiences – ideal for games, movies and

music

• Front-ﬁring subwoofer that radiates deep bass response

• Separate channel controls that adjust to suit preferences, media and room acoustics

• Contemporary styling that complements ﬂat-panel monitors and decor

• Shielding that prevents distortion and maintains clear, crisp sound

• RMS power 20 W + 5 W x 5

• Lifetime Warranty

SAFETY PRECAUTIONS

Prior to the installation of your speakers, read the following safety guidelines to help prevent

damage to any electrical components or harm to users.

• Do not place this product or any of its parts near heat or potential heat sources, nor in any

moist or damp environment.

• Do not hit, drop or mishandle electrical components in such a way as to loosen, break or

otherwise render inoperative any interior or exterior parts.

• Do not remove the back panel except as directed by a qualiﬁed technician in order to

minimize the possibility of electrical shock. If in need of repair or inspection, bring the

speaker(s) to a professional repair person.

• Should liquids or other materials (including fragments of broken parts) get inside the speaker

cabinet, immediately shut power off to the speaker and have it professionally inspected

and/or repaired before further operation.

• Turn off the power and unplug from power source when the system is not in use.

SETUP

1. Carefully unpack the speakers and cables. Do not lift or remove the speakers from the box

by the function knobs or other attachments as this may damage the speaker unit.

2. Place the satellite speakers and subwoofer in the desired listening location.

3. Attach the satellite speakers to the

subwoofer unit using the included RCA-to-

stereo cables as shown at right. Match

each color-coded cable connector to the

proper color-coded speaker and subwoofer

input jacks. If speaker wire is included

instead of RCA-to-stereo cables, attach

one of the bare wire ends to the positive

terminal of the speaker; attach the other

end of the same wire to the positive terminal

of the subwoofer. Repeat the steps with the

remaining wires to connect the negative

terminals (gently twist each bare end to

prevent stray strands from touching the

other terminal).

4. Connect the RCA-to-stereo cables as shown to the

computer sound card or other audio source.

5. If connecting to a computer, conduct a sound card

test. With the speakers properly connected and

turned on, ﬁnd the computer’s sound card in the

device manager and begin the test. Each channel

should be able to be tested for sound and link.

6. With the “test” window still open, turn up the volume

on each channel (speaker). Test sound should be

heard.

SETUP

1. Carefully unpack the speakers and cables. Do not lift or remove the speakers from the box

by the function knobs or other attachments as this may damage the speaker unit.

2. Place the satellite speakers and subwoofer in the desired listening location.

3. Attach the satellite speakers to the

subwoofer unit using the included RCA-to-

stereo cables as shown at right. Match

each color-coded cable connector to the

proper color-coded speaker and subwoofer

input jacks. If speaker wire is included

instead of RCA-to-stereo cables, attach

one of the bare wire ends to the positive

terminal of the speaker; attach the other

end of the same wire to the positive terminal

of the subwoofer. Repeat the steps with the

remaining wires to connect the negative

terminals (gently twist each bare end to

prevent stray strands from touching the

other terminal).

4. Connect the RCA-to-stereo cables as shown to the

computer sound card or other audio source.

5. If connecting to a computer, conduct a sound card

test. With the speakers properly connected and

turned on, ﬁnd the computer’s sound card in the

device manager and begin the test. Each channel

should be able to be tested for sound and link.

6. With the “test” window still open, turn up the volume

on each channel (speaker). Test sound should be

heard.

SPECIFICATIONS

• RMS Output Power: 20 W + 5 W x 5

• Frequency Response:

Satellites: 180 Hz – 20 kHz

Subwoofer: 50 Hz – 200 Hz

• Signal to Noise Ratio (S/N): ≥ 80 dB

• Total Harmonic Distortion (THD): ≤ 0.3%

• Impedance:

Satellites (front, center, rear): 4 Ohms

Subwoofer: 4 Ohms

• Dimensions:

Satellites (front, center, rear): 95 x 80 x 120 mm (3.75 x 3.15 x 4.75 in.)

Subwoofer cabinet: 275 x 150 x 225 mm (10.8 x 5.9 x 8.86 in.)

• Diameter, driver(s):

Satellites (front, center, rear): 7.6 cm (3 in.)

Subwoofer: 10 cm (4 in.)

• Power: Internal power supply

• Connectors: RCA cables (included)

NOTES

SPECIFICATIONS

• RMS Output Power: 20 W + 5 W x 5

• Frequency Response:

Satellites: 180 Hz – 20 kHz

Subwoofer: 50 Hz – 200 Hz

• Signal to Noise Ratio (S/N): ≥ 80 dB

• Total Harmonic Distortion (THD): ≤ 0.3%

• Impedance:

Satellites (front, center, rear): 4 Ohms

Subwoofer: 4 Ohms

• Dimensions:

Satellites (front, center, rear): 95 x 80 x 120 mm (3.75 x 3.15 x 4.75 in.)

Subwoofer cabinet: 275 x 150 x 225 mm (10.8 x 5.9 x 8.86 in.)

• Diameter, driver(s):

Satellites (front, center, rear): 7.6 cm (3 in.)

Subwoofer: 10 cm (4 in.)

• Power: Internal power supply

• Connectors: RCA cables (included)

NOTES

www.manhattan-products.com

Are you completely satisﬁed with this product?

Please contact your MANHATTAN® dealer with comments or questions.

All products mentioned are trademarks or registered trademarks of their respective owners.
