Manhattan 100939 Manuel utilisateur

MAN-100939/100946-UM-0109-03

Multi-Card

reader/Writer

uSer MaNual

MODELS 100939 & 100946

Thank you for purchasing the MANHATTAN®Multi-Card Reader/Writer, Model 100939 (black)

or Model 100946 (blue).

Convert any unused PC bay into a digital content management center that lets you access

picture ﬁles from memory cards without directly connecting a camera or other media device to

the computer. Follow the simple instructions in this user manual and enjoy the beneﬁts of these

convenient features:

• Easily access media and manage content almost anywhere

• Includes USB mass-storage capabilities

• Compatible with CompactFlash, Microdrive, Memory Stick, MagicGate, SecureDigital and

Multimedia

• Supports automatic card detection and data transfer speeds up to 480 Mbps

• Eliminates the need for a direct connection of a media device to save battery power

• Windows and Mac compatible — hot swappable, Plug and Play

• Lifetime Warranty

iNStallatioN

1. Using the included USB cable, connect the Multi-Card Reader/Writer to a USB port on your

computer. Double-click on "My Computer" to conﬁrm that a removable disk icon appears.

2. Check that the green Power LED lights to conﬁrm a proper connection.

3. Insert your storage card in the appropriate reader slot to use the card reader function.

4. Check that the Power LED changes to red to indicate the device is ready for operation.

5. Double-click on the corresponding icon to read or write desired ﬁles to or from your computer

or storage card.

6. Check that the Power LED ﬂashes to indicate the operation is in progress.

Memory Card Formatting:

XD users may need to format the memory card prior to use, indicated by a "write protection" or

"read/write error" message. If this is the case, follow the steps below to use the Flash Ranger

tool for formatting the memory card.

1. Go to "Start"

→

"Programs"

→

"Multimedia Card Reader"

→

"Flash Ranger."

2. Select the XD icon, then click "Low Level Format."

3. When prompted with "Low level format is completed. Please remove the card," click "OK"

and remove the memory card.

4. Re-insert the memory card and continue using the Multi-Card Reader/Writer.

SpeCifiCatioNS

Standards and Certiﬁcations

• Hi-Speed USB 2.0, USB 1.1, CE, FCC

General

• LED: Power/activity

• Transfer rates: 480 Mbps / 12 Mbps / 1.5 Mbps

• Material: plastic

Physical

• Textured matte nish

• USB type A male to mini B male extension cable, 1 m (3.3 ft.)

• Dimensions: 10.5 x 1.8 x 6 cm (4.1 x 0.7 x 2.4 in.)

• Weight: 62.4 g (2.2 oz.)

System Requirements

• USB port

• Windows 2000/XP/Vista, Mac 10.4.5 or higher

• Supports CompactFlash Type I/II, CF 3.0, CF 4.0, CF Elite Pro, CF High Speed, CF PRO I/II,

Extreme CF, Extreme III CF, Ultra II CF, XS-XS CF, IBM and Hitachi Microdrive, MagicStor, Memory

Stick, Memory Stick Duo, Memory Stick Extreme III PRO, Memory Stick Extreme PRO, Memory

Stick Micro (M2), Memory Stick PRO, Memory Stick PRO Duo, Memory Stick PRO HG, Memory

Stick ROM, Memory Stick Select, Memory Stick Ultra II PRO, High Speed Memory Stick PRO,

High Speed Memory Stick PRO Duo, MagicGate, MagicGate Duo, MagicGate PRO, Magic-

Gate PRO Duo, High Speed MagicGate PRO, High Speed MagicGate PRO Duo, SecureDigital

(SD), Elite Pro SD, Extreme SD, Extreme III SD, High Speed miniSD*, High Speed SD, microSD /

TransFlash, miniSD*, Pro SD, SDHC, Ultra SD, Ultra II SD, Ultra II SD Plus, Ultra Speed SD, Ultra-X

SD, MMC / MMC 4.0 / MMC 4.2, RS-MMC*, High Speed MMC / RS-MMC*, RS-MMC

4.0*, MMCmobile*, MMCplus*, XD / XD 1.21

* Adapter required

Package Contents

• Multi-Card Reader/Writer

• USB extension cable

• User manual

All products mentioned are trademarks or registered trademarks of their respective owners.

www.manhattan-products.com

MANHATTAN®offers a complete line of PC Components, Peripherals, Cables

and Accessories. Ask your local computer dealer for more information or visit us online at
