MAN-205078-UM-1106-02

Hi-Speed USB 2.0

to SAtA 150 AdApter

witH power SUpply

USer

MANUAl

MODEL 205078

2

Thank you for purchasing the MANHATTAN®Hi-Speed USB 2.0 to SATA 150 Adapter with

Power Supply, Model 205078. This device connects external SATA storage devices to desktop

and notebook computers using a USB port. Backing up ﬁles or storing large ﬁle archives on ex-

ternal drives is faster and easier to accomplish. Compatibility with all types of drives up to 5.25”,

including 2.5” notebook drives and standard 3.5” CD/DVD, ZIP and magnetic optical drives,

makes this a versatile tool for professional and home use.

Main features:

• Connects one SATA 150 drive to a Hi-Speed USB 2.0 port to transfer, back up and store ﬁles

• Supports SATA 150 speeds up to 1.5 Gbps and Hi-Speed USB 2.0 speeds up to 480 Mbps

with built-in data cables

• Fits SATA 150 and CD/DVD drives up to 5.25”

• Supports 48-bit LBA for drives up to 500 GB

• Plug and Play; Windows compatible; hot-swappable

• Lifetime Warranty

Package contents:

• Hi-Speed USB 2.0 to to SATA 150 Adapter with Power Supply

• User manual and driver CD

NOTE: As data stored on hard disks is not guaranteed by the disk manufacturers, MANHATTAN

accepts no responsibility for lost data. Back up all data regularly.

3

SetUp & operAtioN

System Requirements

Hardware: PC or notebook computer with an available USB interface.

Operating system: Windows 98/SE/Me/2000/XP/Vista.

Setup for Windows 98/SE

1. Plug the adapter into an available USB port.

2. Attach the SATA drive to the adapter.

3. Set the SATA drive to "Master/MA."

4. Secure power to the drive, if needed, and start Windows 98/SE.

5. Windows 98/SE will automatically ﬁnd the USB device. Click "Add new hardware"; then

click "Next."

6. Choose "Search available driver"; click "Next."

7. Insert the driver CD and select "Appointed device." Enter "corresponding product code"; click

"Next." The screen will display "USB Storage Adapter."

8. Click "Finish." The program will automatically complete the setup. A correct setup will be

4

conﬁrmed by an on-screen illustration, with a circle highlighting the new device and without

any yellow, red or green question mark. After ﬁnishing the setup, the USB device will be

found in "My Computer."

Setup for Windows Me/2000/XP

Under Windows Me/2000/XP, the system can ﬁnd and set up "USB Mass Storage Device"

directly.

NOTE: Partition and format any new hard disk drive (HDD) into FAT16 or FAT32 segments prior

to connecting to the Hi-Speed USB 2.0 to SATA 150 Adapter. If your HDD partition is NTFS or

UNIX, format as FAT16 or FAT32 before connecting the adapter.

NOTE: A typical USB can provide 5 V / 500 mA of power to a USB device. For 2.5" drives,

it’s recommended that a PS/2 cable be used (connecting the adapter to the keyboard) if the

HDD operating current is more than 500 mA.

5

SpecificAtioNS

Standards

• Complies with USB 2.0 standards

• Complies with USB 1.1 standards

• Complies with SATA 150 standards

General

• One Hi-Speed USB 2.0 Type A (male) and one SATA 150 connection (L-type male) ports

• Hi-Speed USB 2.0 and SATA 150 transfer interface

• HDD/CD-ROM/CD-R/RW/DVD/MO/ZIP-compatible mode

• 480 Mbps maximum transfer rate

• Supports SATA and enhanced SATA drives

Environmental

• Overall dimensions: 7.0 x 3.2 x 1.7 cm (2.75 x 1.25 x 0.7 in.)

• SATA connector: 11 cm (4.3 in.)

• USB connector: 73 cm (28.7 in.)

• Weight: 48.2 g (314.7 g with power supply); 1.7 oz. (11.1 oz. with power supply)

6

Power Supply

• Input: 100 – 240 V / 50 – 60 Hz maximum 1.5 A / 75 – 100 VA

• Output: 5 V / 2A; 12 V / 2 A

• Cord length: 1.93 m (76.0 in.) overall

7

NOTES

www.manhattan-products.com

Are you completely satisﬁed with this product?

Please contact your MANHATTAN®dealer with comments or questions.

Copyright © MANHATTAN

All products mentioned are trademarks or registered trademarks of their respective owners.
