User Instrucons

Bathing Cushion

Ensure that you read and understand this instrucon manual before using

this product. Failure to follow the instrucons and safety precauons in

this manual can result in damage and/or serious injury.

Please keep these instrucons in a safe locaon for future reference

WARNINGS (Risk of possible injury or other serious adverse reacons)

• Ensure that you feel completely condent to use the Bathing Cushion either on your own or

with assistance if required. You may be at risk of drowning or injury if you are uncertain or not

condent in using the Bathing Cushion or if a medical condion prevents you from using the

Bathing Cushion as laid out in these instrucons. If you have any concerns about an exisng

medical condion aecng your ability to safely operate the Bathing Cushion, consult a health

professional.

• The independence that the Bathing Cushion provides does not negate the need to ensure that

adequate assistance is on hand in case it is required. It is advisable that a telephone or other

means of communicaon is taken into the bathroom when bathing without assistance. As with

all mechanical and electrical devices, unforeseen breakdowns can occur and so whilst in the

unlikely event that there is a malfuncon of the Bathing Cushion, a method of summoning

adequate assistance should be available.

• Do not operate the Airo compressor in the presence of ammable anaesthec mixtures with

air, oxygen or nitrous oxide, as these mixtures can create a combusble environment leading

to the potenal for re or even an explosion in the presence of a spark.

• Do not use the Bathing Cushion if under the inuence of alcohol or if taking medicaon which

may aect your ability to exercise judgment, coordinaon or motor control.

• The Bathing Cushion should only be used as a bathing aid, NEVER use it out of a bath. NEVER

use the Bathing Cushion to climb in or out of the bath. NEVER use it as a step, stand or as a

device for liing items.

• Do not use the Bathing Cushion as a support to steady yourself when cleaning the bath or

when reaching into the bath to retrieve items, as doing so may place an uneven or unbalanced

load on the Bathing Cushion causing it to become unstable.

• The Bathing Cushion should only be used for its stated purpose and should not be modied in

any way.

• Ensure that when in use, the Airo compressor, the hand control lead and air hose are laid out

in such a way as to avoid any risk of tripping or strangulaon.

• Do not allow children to play with the Bathing Cushion or Airo as operaon of the equipment

in an uncontrolled or unsupervised situaon may lead to personal injury and/or damage.

• To avoid personal injury during use and/or damage to the equipment, keep animals away from

the Bathing Cushion and Airo compressor.

• Before each use, ensure that there are no obvious signs of damage or lose sucon cups. If in

doubt, do not use and seek advice from your supplier.

Safety Informaon

Simple solutions for everyday independence

• To ensure full stability when in use, make sure that the sides of the Bathing Cushion touch the

sides of the bath when fully inated.

• Remove any non slip mats from the area where the sucon cups will be posioned.

• Ensure that any oil and soap residue is removed from the Bathing Cushion and bath. Pay

parcular aenon to the sucon cups and oor of the bath. Ensure that the sucon cups

adhere rmly to the bath before each use. The sucon cups may not adhere to the surface in

baths that have been re-enamelled or that have rippled or textured surfaces. Do not use if the

sucon cups do not adhere to the bath.

• ALWAYS INFLATE THE BATHING CUSHION AND USE THE BATHING CUSHION TO LOWER

YOURSELF INTO THE BATH. This allows the micro processor in the Airo to calculate the

required baery power to raise the Bathing Cushion and if it calculates that there would be

insucient power, it will not allow the hand control to operate the down funcon.

• To maintain stability, DO NOT try to lower yourself into the bath or raise yourself from the

boom of the bath unl you are IN AN UPRIGHT SEATED POSITION CENTRALLY AND RIGHT TO

THE BACK OF THE SEAT SO THAT YOU ARE TOUCHING THE BACKREST (see gs. 6 & 9).

• To avoid the risk of electric shock, NEVER recharge the baery in the bathroom, outdoors or in

a damp environment.

• Do not use any other air supply to inate the Bathing Cushion.

• The sucon cups contain Latex. Users with an allergy to Latex should take parcular care to

avoid prolonged contact with the sucon cups. The sucon cups are situated at the base of

the seat and are not normally in direct contact with the user during use.

CAUTIONS (Risk of possible problems including device malfuncons, device failure,

damage to the device or damage to other property)

• Only recharge the baery with the Mangar Internaonal baery charger supplied with the

Airo compressor.

• To prevent damage, always release the sucon under each sucon cup before liing the Bathing

Cushion from the bath. Do not aempt to release the sucon by pulling up on the seat, backrest

or ‘handle’.

• Never use hot air to dry the Bathing Cushion following cleaning as this may aect the integrity

of the welded seams and fabric and lead to premature failure of the cushion resulng in an

inability of the cushion to raise you from the bath.

• Disconnect the Airo compressor from the Bathing Cushion before transporng so as to avoid

accidental inaon of the cushion.

• Do not use bath addives containing peanut oil as this can damage the sucon cups. If such

addives have been used, ensure that the sucon cups are thoroughly wash and rinsed to

remove residues.

Safety Informaon

Table of Contents

Safety Informaon.................................................................................................................... 2

Warnings................................................................................................................................ 2

Cauons................................................................................................................................. 3

Product descripon.................................................................................................................. 5

Intended use ......................................................................................................................... 5

Construcon.......................................................................................................................... 5

Standard product contents................................................................................................... 5

Installaon and use.................................................................................................................. 6

Before ng the Bathing Cushion in the bath..................................................................... 6

Fing the Bathing Cushion in the bath................................................................................ 6

Connecng the air hose and hand control........................................................................... 7

Dry trials (without water in the bath)................................................................................... 7

Using the Bathing Cushion.................................................................................................... 8

Maintenance and care.............................................................................................................. 10

To remove the Bathing Cushion from the bath..................................................................... 10

Cleaning................................................................................................................................. 11

Maintenance.......................................................................................................................... 11

Transportaon/Storage.......................................................................................................... 12

Disposal/Recycling................................................................................................................. 12

Troubleshoong .................................................................................................................... 12

Appendices................................................................................................................................ 13

Specicaons......................................................................................................................... 13

Warranty................................................................................................................................ 13

Spare parts............................................................................................................................. 14

Symbols used......................................................................................................................... 14

Cercate of conformity........................................................................................................ 15

Simple solutions for everyday independence

Intended use

The Bathing Cushion is intended solely for use as a bathing aid to assist a person to lower

themselves into and out of a bath. Users should have sucient upper body strength to be able

to hold the sides of the bath for added support if required. The Bathing Cushion is not intended

for any other use and should never be used outside of a bath. When properly maintained, the

Bathing Cushion will give many years of trouble free service.

Construction

The Bathing Cushion is constructed from a very strong polyurethane coated nylon material which

has been precision cut into panels and then joined together by high frequency welding. This

produces a very strong light weight and air ght construcon. The Bathing Cushion incorporates

an air pressure relief valve which will not allow the cushion to be over inated by the Airo Mk3

compressor.

Power is provided by the Mangar Internaonal

Airo Mk3 baery powered compressor.

PLEASE READ the separate Airo Mk3

compressor instrucons before using your

Bathing Cushion.

Standard product contents

1 x Bathing Cushion

(c/w): Bathing Cushion User Instrucons

Product Descripon

Installaon and Use

Before ng the Bathing Cushion in the

bath

• Remove any non slip mats from the area

where the sucon cups will be posioned.

• Ensure the boom of the bath is clean

and smooth, with no oil or bath cleaner

residues that will prevent the sucon feet

from scking. WARNING: The sucon cups

may not adhere to the surface in baths

that have been re-enamelled or that have

rippled or textured surfaces. Do not use if

the sucon cups do not adhere to the bath.

• Pass the air hose through the loop in the

corner of the backrest (A g.1), on the

side that you propose geng into and out

of the bath. The air inlet valve (B) can be

rotated, allowing the hose to be led to the

appropriate corner.

Fing the Bathing Cushion in the bath

• Fold the backrest over onto the seat as

indicated in g. 2. Lightly place the deated

Bathing Cushion in the middle of the empty

bath with the ‘handle’ (C) aligned with the

centre of the bath.

• Hold the ‘handle’ and pull the Bathing

Cushion towards the slope of the bath

unl there is a gap of approximately 25mm

between the bath slope and ‘handle’

(C gs. 2 & 3).

• Firmly press all four sucon cups down

and check that they are securely stuck to

the bath. Wet them to help them sck if

necessary.

• Fold the backrest out so that it rests on the

slope of the bath.

25mm approx.

Simple solutions for everyday independence

Installaon and Use

Connecng the air hose and hand control

• Connect the air hose from the Bathing

Cushion to the Airo air outlet socket

(D g. 4).

• Connect the Hand Control (E) to the Airo

Hand Control socket (F).

Dry trials (without water in the bath)

• Select ‘Up’ on the hand control (G g. 5)

to inate the Bathing Cushion and when

the relief valve blows (it will hiss), release

the ‘Up’ buon. Press rmly down on the

Bathing Cushion to secure the sucon

cups to the oor of the bath. Check all four

sucon cups are securely stuck to the bath.

Wet them to help them sck if necessary.

• Whilst sll clothed and with the help of

an assistant if required, carry out some

dry ‘pracce runs’ according to these

instrucons unl you are totally condent

using the product.

Note: During a ‘dry trial’ the Bathing Cushion

may make a noise when being lowered and

raised due to the fabric rubbing against the dry

sides of the bath, this is normal and the noise

will disappear when the bath is full of water.

Installaon and Use

to get into the bath

• With the Bathing Cushion in the bath,

ensure that all 4 sucon cups are adhering

to the oor of the bath, ll the bath with

water at a suitable temperature (Maximum

50°C/120°F).

• With the Bathing Cushion fully inated, sit

on the seat and then swing your legs into

the bath.

• To maintain stability, ENSURE THAT YOU

ARE SEATED CENTRALLY AND RIGHT AT

THE BACK OF THE SEAT SO THAT YOU ARE

TOUCHING THE BACKREST (g. 6).

WARNING: Do not sit further forwards

as shown in gure 7, as you may slide o

the front of the seat and sustain possible

serious injury.

• Select ‘Down’ to lower yourself into the

bath. KEEP YOUR KNEES BENT AND FEET

FLAT ON THE FLOOR OF THE BATH AS YOU

ARE LOWERED SO AS TO AVOID SLIDING

FORWARDS ON THE SEAT. Hold the sides

of the bath or grab handles for added

support if required.

• You can stop at any me by releasing the

‘Down’ buon.

Note: you may nd it more comfortable to

leave a small amount of air in the Bathing

Cushion, to cushion yourself on the boom

of the bath (g. 8). 8

Using the Bathing Cushion

WARNING: ALWAYS INFLATE THE BATHING CUSHION AND USE THE BATHING CUSHION TO LOWER

YOURSELF INTO THE BATH. This allows the micro processor in the Airo to calculate the required

baery power to raise the Bathing Cushion and if it calculates that there would be insucient

power, it will not allow the hand control to operate the down funcon.

Simple solutions for everyday independence

Installaon and Use

to get out of the bath

• When you have nished bathing, PLACE

YOURSELF IN AN UPRIGHT SEATED

POSITION CENTRALLY AND RIGHT TO THE

BACK OF THE SEAT SO THAT YOU ARE

TOUCHING THE BACKREST, WITH FEET AND

KNEES DRAWN BACK (g. 9).

NOTE: Parally inang the Bathing

Cushion will allow the backrest to inate

and assist you in sing upright. Hold the

sides of the bath for added support if

required.

• Select ‘Up’ on the hand control when you

are ready to get out of the bath.

• You can stop at any me by releasing the

‘Up’ buon.

• Select ‘Up’ again to connue raising

yourself. Keep inang the Bathing Cushion

unl the relief valve blows; it will hiss. If

necessary, hold onto the side of the bath or

the grab handle to steady yourself as you

are being raised (See gs. 9 & 10).

• With the Bathing Cushion fully inated,

rotate your upper body and swing your legs

over the side of the bath.

Maintenance and Care

• Aer use, drain the bath water and release

the sucon cups from the oor of the

bath. Do this by liing the rim of a pair of

sucon cups (g. 11) to release the sucon

between sucon cup and bath.

• Tilt the Bathing Cushion so that the

released sucon cups do not re-adhere to

the surface (It helps to place a small towel

beneath them to stop them re-adhering to

the bath).

• Release the remaining pair of sucon cups

by liing their rims as before.

• Remove the Bathing Cushion from the bath

and disconnect the air hose.

NOTE: To deate the Bathing Cushion when

not sing on it, disconnect the air hose.

The Airo compressor will not suck air from

the Bathing Cushion. To speed up deaon,

apply some weight to the Bathing Cushion by

pressing down on it.

For ease of carrying and hanging up for storage,

fold the Bathing Cushion as indicated (g. 12)

and pass the ‘handle’ (C) through the slot

between the seat and backrest.

To remove the Bathing Cushion from the bath

Table des matières

Manuels masseur populaires d'autres marques

ELEEELS

ELEEELS P2 Manuel utilisateur

Cenocco

Cenocco CC-9111 Manuel utilisateur

Panasonic

Panasonic EP790-C1 Manuel utilisateur

Human Touch

Human Touch NOVO Manuel utilisateur

Adler

Adler AD 2167 Manuel utilisateur

Taurus

Taurus Wellness TW-MC-M Manuel utilisateur

Infinity

Infinity Syner-D Circadian Manuel utilisateur

Hydas

Hydas LH-095 Manuel utilisateur

AEG

AEG FM 5567 Manuel utilisateur

OBH Nordica

OBH Nordica Shiatus Tunes Manuel utilisateur

Hutech

Hutech Q9 Manuel utilisateur

Medisana

Medisana MM 825 Manuel utilisateur

SOLAC

SOLAC Therma Hydro Manuel utilisateur

Invacare

Invacare Texas Manuel utilisateur

Casada

Casada Bismarck II Manuel utilisateur

Fujiiryoki

Fujiiryoki Cyber-Relax EC-1700 Manuel utilisateur

Medisana

Medisana HM 886 Manuel utilisateur

HoMedics

HoMedics BA-C200 Manuel utilisateur
