Mami Mini TRACER Manuel utilisateur

Mini TRACER

MAMI

MANUFACTURING AND MINOR INVENTIONS

Preliminary issue

M000037

TABLE OF CONTENTS

MINI-TRACER

EXTRA FUNCTIONS AND FEATURES....................................................................................................................... - 3,4 -

CONNECTIONS .......................................................................................................................................................... - 5 -

WIRELESS DETECTOR AND REMOTE CONTROL OPERATION.......................................................................... - 6 -

- PROGRAMMING .................................................................................................................................. - 7 -

INSTALLER SYSTEM PROGRAMMING:

-SYSTEM OPTION REGISTERS ......................................................................................................................... - 8 -

OPTION REGISTER 1.................................................................................................................................. - 8 -

OPTION REGISTER 2.................................................................................................................................. - 8 -

OPTION REGISTER 8.................................................................................................................................. - 8 -

- ENTRY EXIT DELAY ......................................................................................................................................... - 8 -

- CHECK-IN INTERVAL........................................................................................................................................ - 8 -

- SIREN DURATION ............................................................................................................................................ - 8 -

- REPEATER ALLOCATION ................................................................................................................................ - 8 -

- WIRELESS EQUIPMENT CODING ................................................................................................................. - 9 -

SETTING AND DISPLAYING....................................................................................................................... - 9 -

SELF LEARNING THE CODE ..................................................................................................................... - 9 -

- RESPONSE TELEPHONE NUMBERS ............................................................................................................ - 9 -

- RADIO TRANSMITTER/ TELE-COMMUNICATOR (SUBSCRIBER CODE) ................................................... - 9 -

- CIRCUIT (ZONE) OPTIONS

WITH SIREN .............................................................................................................................................. -10 -

OPEN/CLOSE ............................................................................................................................................ -10 -

ALARM/RESTORE .................................................................................................................................... -10 -

PRESET PATTERNS A,B,C, AND D ......................................................................................................... -10 -

REPORTING .............................................................................................................................................. -10 -

ALWAYS ACTIVE (24HR) .......................................................................................................................... -10 -

PRESET PATTERNS A,B,C, AND D .......................................................................................................... -10 -

ENTRY/EXIT .............................................................................................................................................. -10 -

ACTIVE WIRELESS ZONES .................................................................................................................... -10 -

ACTIVE PERIMETER SECTIONS ............................................................................................................. -10 -

WIRELESS SUPERVISION TEST ............................................................................................................. -10 -

- SECTIONAL PERIMETER INTRUSION (SPI) SYSTEM ................................................................................... -11 -

PRESET PATTERNS A,B,C, AND D .......................................................................................................... -11 -

SENSITIVITY............................................................................................................................................... -11 -

ARMING ..................................................................................................................................................... -11 -

- EVENT MEMORY LOGGING/ DISPLAYING .................................................................................................... -11 -

INSTALLER KEYPAD PROGRAMMING:

S ETTING INDIVIDUAL KEYPAD ID NUMBER ........................................................................................ -12 -

LOCAL BLEEPER FUNCTION ENABLE .................................................................................................... -12 -

CHANGING INSTALLER PASSWORD ....................................................................................................... -12 -

CHANGING SYSTEM ID OF THE KEYPAD ............................................................................................. -12 -

ERASING SYSTEM MEMORIES:

ERASING (DEFAULTING) THE CONTROL PANEL MEMORY .................................................................. -12 -

ERASING (DEFAULTING) THE KEYPAD MEMORY .................................................................................. -12 -

CONTROL PANEL MEMORY ..................................................................................................................... -12 -

CONNECTIONS 1:

MAINS ......................................................................................................................................................... -5,13 -

BATTERY .................................................................................................................................................... -5,13 -

KEYPADS .................................................................................................................................................... -5,13 -

SECTIONAL PERIMETER INTRUSION (SPI) SYSTEM ............................................................................. -5,13 -

RADIO TRANSMITTER ANTENNA ............................................................................................................. -13 -

EXPANDER BOARD MODULE ................................................................................................................. -13 -

RADIO RECEIVER FOR WIRELESS EQUIPMENT .................................................................................... -13 -

REMOTE LED INDICATOR .......................................................................................................................... -13 -

NORMALLY OPEN / NORMALLY CLOSED ZONES .................................................................................. -13 -

CONNECTIONS 2:

END OF LINE RESISTORS ........................................................................................................................ -13,14

-

SECURITY LIGHTS..................................................................................................................................... -5,14 -

SIREN ....................................................................................................................................................... -5,14 -

BUZZER ...................................................................................................................................................... -5,14 -

KEY-SWITCH / WIRED PANIC BUTTON ................................................................................................... -5,14 -

TAMPER ...................................................................................................................................................... -5,14 -

SUMMARY OF ALL KEY PAD ENTRIES ................................................................................... Appendix A

NOTES ...................................................................................................................................... Appendix B

G E N E R A L INFORMATION .............................................................................................................................. - 2 -

M000037

-1-

M I N I - T R A C E R

Radio Alarm Control Panel

MARCH 2007

GENERAL FEATURES:

The "MINI-TRACER" is a microprocessor based ALARM PANEL designed to perform all the functions

associated with the monitoring of alarm conditions, in both wired and wireless environment, and subsequent

transmission by Radio to a REMOTE MONITORING CONTROL ROOM.

The "MINI-TRACER" not only conforms with SAIDSA specifications but offers many more features

which are not available in traditional alarm panels.

The "MINI-TRACER" is capable of reporting the condition of all 6 zones in one transmission giving the full

current status of the alarm panel

These features make the "MINI-TRACER" a versatile, efficient and most innovative ALARM CONTROL PANEL

- Supports 2 key pads and /or displays.

- 6 zones BOTH WIRED and /or 6 WIRELESS.

- Arm/disarm and warning selection via Keypad, Key-Switch or Remote Control

- Normal or multi-user operation ( 4 partitions).

- Remembers all selections during power failures and will resume from the last status.

- Supervised alarm circuits/zones with end of line resistors (2k7).

- Programmable "entry / exit delay" .

- Programmable siren activation on individual zones.

- UHF RADIO transmitter.

- Built-in battery 1.5 A charger for Stand-by 7 A/h battery (48 hrs autonomy on average installation ).

- Buzzer output for auxiliary signals (arm, disarm, battery-low etc....).

- EEPROM memory for retention of both options and code selections during "power-down".

- Optional wired panic button

- Optional input for key-switch operation

- Programmable silent PANIC alarm.

- Programmable reporting of battery low condition in each wireless sensor .

- Programmable reporting of system mains failure, mains restoral, system battery low and restoral.

- Programmable reporting of arm and disarm with user identification.

- Programmable Auto arming with optional entry-exit feature ( hands free).

- Subscriber ID code and options fully programmable by the installer.

- TEST transmission can be sent to control room via the remote control or keypad.

- Programmable "check-in" transmission from 1 to 250 hours.

- Four preset active levels “A, B, C, or D”

- Diagnostic for testing wireless devices.

- Easy programming and display of current options and settings .

- Programmable alarm reporting on individual zones.

- Each keypad can be switched off individually.

- Self Learning function for the Remote Control code and Wireless Detectors.

- Supports both Old and New report protocols and wireless codes.

- Quick setting of the four preset levels: “A, B ,C or D” to ARM

- Quick setting of the four preset levels: “A, B ,C or D” to WARN

- Keypad system security identification feature.

- Duress code.

- Tamper on Wireless Detectors

- Battery low on wireless detectors

- Wireless detectors Supervision

- Keypad wrong-code lockout

- 255 Event logging in non volatile memory.

- Zone “swinger” to automatically disable false triggering zones

- 6 sector perimeter expander interface, for SPI beams

M000037

-2-

The "MINI-TRACER" is capable of monitoring BOTH WIRED and WIRE-LESS detector circuits at the same

time. A REMOTE PANIC BUTTON option is built in as a standard feature.

The "MINI-TRACER" will send an alarm/report whenever the following inputs are triggered:

- Any of the 6 wired active inputs.

- Any of the 6 wireless active inputs.

- Remote panic button.

- Supervisory signals such as:

- battery low in the wireless sensors. - low battery in the system.

- arm / disarm. - battery restored in system.

- mains failure - test transmission

- mains restored - Tamper & password change

- panic button

For complete application flexibility the six wired inputs may be programmed to send an alarm whenever one of the

following conditions occur:

- When the external circuit is opened (Normally Closed circuit).

- When the external circuit is closed (Normally Open circuit).

- Both when the external circuit is Opened or Closed.

(In this case it is possible to program any of the circuits as an "alarm circuit" or a "door entry monitoring circuit").

- When the trigger condition remains for longer than 15 sec (slow detection).

For example : You may require that the particular circuit calls the control room both when an alarm occurs

and when it is restored, or that a particular circuit calls the control room both when a door is locked or unlocked.

The six wireless inputs work parallel to the wired inputs and therefore share all the available

optional features such as:

- individual siren activation selection - individual "ENTRY/EXIT DELAY" selection

- individual "warning only" selection - individual "24 hrs" ready activation.

A great feature of the ‘MINI-TRACER" is the fact that it is fully programmable to suit every possible requirement.

You can for instance define 4 levels each containing a set of zones which you will most likely select in everyday

operation. You do not have to remember which set you normally arm or set to warning mode.

The "MINI-TRACER" will memorize the four patterns for you and so when arming the system, automatically

step through these preset patterns allowing you to stop at the one you desire. These patterns may be changed

at will by the installer or by the customer using the two buttons on the hand-held remote control.

These preset levels can be “Quick selected” . See “long-key” on table of key entries

ALL COMMANDS and INDICATIONS are performed / shown on up to 4 wall mounted Keypads / Display units .

The Key Pad / DISPLAY units can display the following information:

- the wired/wireless sensor which caused the alarm. - the wired/wireless sensor which caused the warning signal.

- the perimeter beam which was activated. - system armed / disarmed indication.

- which zone is set to 24hrs, armed or on warning. - Entry / exit delay activated.

- mains failure has occurred. - system battery is only 80 % charged.

- system has triggered and the signal was sent to control room.

The GREEN numeric display shows the Sector which was activated on the perimeter beams.

The RED numeric display shows the type of transmission which was sent to the control room e.g.:-

- Numbers 1 to 6 indicating the alarm Zone which was triggered.

- The letter "p" indicating panic button activation.

- The letter " t " indicating test transmission.

- The letter " b " indicating battery low in one of the wireless sensors.

- The letter " r " indicating that the system had a reset.

- The letter “ h ” indicating a warning or a call facility.

- The letter “ u ” indicating the system is not programmed yet.

- The letter “ E ” indicating a tamper condition is present.

- The letter “ ? ” indicates that the ID of the keypad is not the same as the ID of the Tracer

- The letter ” j ” indicates wireless Radio Frequency blocking.

GENERAL INFORMATION

M000037

- 3 -

The Key Pad is used to do the following:

- program the system's options.

- access the 4 preset patterns and if necessary change them.

- access each zone individually.

- change the user codes ( 10 different user codes per key pad ).

- activate a panic alarm .

- activate a test signal.

- reset the system /alarm .

- Quick-setting one of four preset levels: “A , B , C or D” to ALARM or WARNING

- to activate / deactivate the perimeter Sectors.

- to send a panic signal

Combination of 2 keys pressed simultaneously will give different conditions, these are shown in Appendix “A”:

NOTE:

When arming the system if any of the zones are in open condition the system will sound the key pad bleeper

6 times before initializing the arming sequence.

During the arming sequence it is possible to cancel the operation by pressing ’ 0 ' or shorten the delay by pressing ‘1’.

To stop the keypad beeping during a Mains Failure, push and hold the ‘0’.

Most COMMANDS are performed through a 2 CHANNEL HAND-HELD REMOTE CONTROL:

- arming and disarming of the system - partial arming selection

- partial "warning only" selection - programming of the 4 different patterns of arming

- panic button - test transmission

- security lights

REPORTING OF AN ALARM TO A CONTROL ROOM

Reporting of an alarm is achieved in the following manner:

The system will transmit , via radio, 3 times at random intervals within 25 seconds

NOTE: After each Radio transmission the system is dormant for 12 seconds to allow all detectors to

settle down. During this period the “running” LED on the key board will flash.

1- STAND-ALONE OPERATION (No Key Pad) - “SNIPER”

SNIPER operation can be set where a single Arm / Disarm level operation is needed. (Register 08 / bit 2 )

The remote control (All users) will arm only “level A” instantly

The Keypad can be removed after programming, leaving only remote control and/or Key-switch for Arming /Disarming.

2- ARM / DISARM CONFIRMATION

Re- transmission (confirmation) of Arming and Disarming signals can be selected (register 08 / bit 3, ON to Enable)

This is meant for business installations where the monitoring of arming status is crucial.

The arming status is sent again, randomly between 30 to 60 minutes, after it was initially Armed or Disarmed.

The confirmation is reported to the base-station as a -user 33- Arm/Disarm.

3-

DURESS

In a life threatening situation. ( When someone forces you to disarm your alarm panel at gun-point) you can make the alarm

panel send a duress to the control room.

4- DURESS ACTIVATION WHEN USING A KEYPAD

Increment first digit of user code by one (1) when disarming the alarm panel.

I.e if ‘ 1 2 3 4 # # ‘ is normally pressed, press ‘2 2 3 4 # # ’ for duress.

EXTRA FUNCTIONS / FEATURES:

M000037

4- AUTO - ARMING

When auto -arming is selected (programable for 2 hours or 15 minutes by installer) the system will arm itself if no

movement or any other activations have been detected within the selected time period.

A second (Installer programmable) option is to enable the entry / exit zone (zone 1 - Wired only).

When the last activation was detected on zone 1 the system will arm itself at Level ‘D’ after the expiry time . In the event

where any of the other zones was the last to be triggered the system will arm at Level ‘A’ after the time period expired.

This function is useful when you forget to arm your alarm system. The system will arm itself 15 min /2 hours after you have

left the house or went to bed. The Auto arming option is set in option register “08” bit 8.

The End-user can then switch it on ( ) or off ( )

Note: Entry / Exit will only function correctly if Zone 1 is the last zone triggered when you leave your premises.

Level ‘A’ will be the “at home /sleep” arming pattern and Level ‘D’ the “away” arming pattern.

The exit delay is always calculated to be double the entry delay

5- DISABLING THE KEY PADS

Each key pad can be disabled individually. To disable temporarily a key pad , enter the user 1 code. Press # for

approximately 4 seconds followed by the D key. To re-enable the keypad repeat the operation.

REMEMBER THAT THE SECOND TIME THERE IS NO INDICATION FROM THE BUZZER ON THE KEYPAD

6- TAMPER ( WIRELESS SENSORS ONLY )

Circuit that monitors illegal violation of alarm devices when the system is not armed. When it`s triggered it will send a

tamper condition to the control room and the “WL TBL” and “TRIGG” leds will be illuminated on the keypad with

buzzer sounding. To cancel the above, enter the user code followed by # #.

7- WIRELESS ZONE SUPERVISION

This feature enables the MINI-TRACER to detect when a wireless passive is faulty ( NOT REPORTING).

The user can program which wireless zone the MINI-TRACER must monitor.

Please note that the wireless passive must be enabled for supervision - pages 8 & 10 and

-See also the wireless detector instructions.

8- EVENT MEMORY LOG FACILITY

The MINI-TRACER-Combo is capable of storing the last 255 events in memory. The installer can view these

events in case of the user not reporting to a control room. The log facility will display the day the event was

recorded, the time and the reason for the event.

9- WIRELESS RF BLOCKING

MINI-TRACER will report a “System Tamper” if Radio Frequency blocking was detected on the system

lasting longer then 30 seconds. This is to prevent intruders trying to “JAM” the system.

10- SPI PERIMETER BEAM

An extra 6 perimeter zones can be installed on the MINI-TRACER. The unit will detect an activation

on the perimeter beam and sound an audible alarm. This condition will not be reported to control the room.

Refer to the instruction of the SPI beam for installation and programming instructions.

11- RESPONSE / GUARD SUPERVISION

This features allows the control room to supervise all activities undertaken by the response officer.

For this purpose the MINI-TRACER uses a third remote control code .

On this special Officer remote control , button A will be the Panic button and button B will be “Guard Responded”.

Please note that this feature is only active for 30 minutes after an alarm was triggered.

This Response code can only be stored by the SELF-LEARNING method and not MANUALLY

- 4 -

1A

+

0A

+

There are two registers which need to be programmed:

The first sets the number of the repeater it will use to reach the control room.

The second is if the unit itself becomes a repeater.

Only then will the MINI-TRACER operate as a simple Store-and-forward repeater provided the received signals

from the nearby systems carry the same repeater address as the “I AM “ value. See page 8

12- REPEATER SELECTION

13- SWINGER ZONE DISABLE

If the same zone triggers more then 5 times during the same “armed” period the Super-Tracer automatically disables

those zones until the next arming or until 10 hours have expired since the last alarm triggered by the “swinger” zone.

M000037

Installing the "MINI-TRACER" is very simple. The connections are easy to read and understand.

Connect the battery, the external transformer and wire up the different zone circuits and audible devices such as the buzzer and

siren. These connections are as follows :

1 - ALARM CIRCUIT CONNECTIONS:

There are 6 inputs available on the

MINI-TRACER. (ZONES CIRCUITS 1 to 6)

For proper operation a 2.7 KOhm

resistor is required at the end of

each zone (last detector)

Any zone will trigger if it is shorted to Ground or +12V .The Inputs have both lightning and short circuit protection.

There is + 12V on the “C” inputs between zones 5 & 6 , 4 & 3 , and 2 & 1.

2- KEYPAD / DISPLAY: 4 wires are required to connect remote display units. They are :

(A) Transmitted data line , (B) Received data line, (Negative supply) and ( Positive 12v supply)

3- SIREN: 12 Volts DC- 1Amp is available between connectors (neg) & (pos) to operate the siren.

4- BUZZER: 12 Volts DC - 1 Amp is available between (neg) & (pos) to operate an optional buzzer.

5- AC - SUPPLY: A 220/16 Volts AC, 800 mA TRANSFORMER supplies power to the charger and on the panel

terminals “AC 16V”. This input is protected against lightning .(15W max)

6- BATTERY CONNECTIONS: A 7 Amp/hr, 12V stand-by battery must be connected between (NEGATIVE) and

(POSITIVE). Accidental reversal of the battery connections is protected by a crowbar polarity protection device which

will blow the safety fuse. It may therefore be necessary to change the BATTERY and OUTPUT fuses after connecting

the battery incorrectly. The unit is NOT GUARANTEED for damages caused by REVERSE / INCORRECT connections.

7- KEY-SWITCH / PANIC INPUT [KS]: The [KS] input is programable for Arming/Disarming or Panic.

To Arm / Disarm with a Key-switch, use the normally open contacts of a momentary key-switch.

Register 08 / bit 1 (see programming section) must be programmed ON for Key-switch operation (OFF for panic).

The normally open contact of the key-switch is connected to 12v Positive “+” and “KS”.

To use the [KS] input for hardwired panic buttons (normally open), program Register 08 / bit 1 as OFF.

Panic buttons are connected in parallel between 12V Positive “+” and “KS”.

8- S.P.I. PERIMETER BEAM CONNECTIONS: The 4 wires to the Master unit of the SPI perimeter alarm system are

connected to the same inputs as the remote keypad. (A) for transmitted data line (B) for the received data line.

(-) for negative supply (+) for positive 12V DC supply.

- 5 -

Special components have been used to protect the key pad and detector power supply from short circuits.

The characteristic of these devices is such that on excessive current they will heat up and TEMPORARELY SHUT DOWN .

Only once the short has been removed will they slowly recover to their initial value.

THE MAXIMUM CURRENT TO KEYPADS AND SENSOR CIRCUITS IS LIMITED TO 700mA FOR EACH.

CONNECTIONS

6 C 5 4 C 3 2 C 1

ZONE CIRCUITS 1 to 6

}

16V

AC

- +

BAT

B A - +

K/P - SPI

- + - +

SIREN

BUZZER

- +

KS

RX

M000037

FUNCTION selection of the DETECTORS CODE

FUNCTION WHEN ACTIVATED

WARNING (1 SEC ON BLEEPER)

PANIC ACTIVATED

DURESS

not used

KEYPAD RELAY 1

KEYPAD RELAY 2

not used

ZONE 1

ZONE 2

ZONE 3

ZONE 4

ZONE 5

ZONE 6

FUNCTION selection of the REMOTE CONTROL CODE

BRIDGE NO. BRIDGE NO.

1=ON 0=OFF 1=ON 0=OFF

4 3 2 1 4 3 2 1

FUNCTION

WHEN ACTIVATED APPLICATION

0 0 0 0

0 0 0 1

0 0 1 0

0 0 1 1

0 1 0 0

0 1 0 1

0 1 1 0

0 1 1 1

WARNING (1 SEC ON BLEEPER)

PANIC ACTIVATED

ARM/DISARM (USER1)

TEST TRANSMISSION

ARM ONLY (to "D" level)

DISARM ONLY

not used

DOOR BELL/POOL WARNING

EMERGENCY / MEDICAL ASSISTANCE

1 0 0 0

1 0 0 1

1 0 1 0

1 0 1 1

1 1 0 0

1 1 0 1

1 1 1 0

1 1 1 1

FUNCTION

TURN SYSTEM ON OR OFF

CHECK IF THE SYSTEM IS WORKING

ARM/DISARM Remote Control USER 2

not used

ARM/DISARM Remote Control USER 3

not used

ARM/DISARM Remote control USER 4

not used

ARM/DISARM Remote Control USER 5

not used

4 3 2 1 4 3 2 1 4 3 2 1 4 3 2 1

Solder Bridges on

Back of Remote Control

1= Solder On

0= Solder Off

USER 2: USER 3: USER 4: USER 5:

CONFIGURATION OF REMOTE CONTROLS IN MULTI-USER MODE:

(Button 1 for Panic = Channel 1)

(Button 2 ARM /DISARM USER X)

In MULTI-USER MODE Each user must have a remote control with button 2 set as shown below and in table 2

Using wireless sensors is simple provided you are aware of the following facts:

1 - The operating range may vary widely from one installation and location to another. The position of the radio receiver is

therefore critical and must be chosen accordingly.

2- Each installation requires two exclusive I.D. Codes :

- a DETECTOR CODE for sensors and detectors and...

- a REMOTE CONTROL CODE for the hand held remote controls

an optional 3rd CODE ( RESPONSE) may be used to indicate to the control room that armed response is on site

- Each code has two parts: IDENTIFICATION and FUNCTION

IDENTIFICATION : This is the part that makes that device recognizable by the system.

The MINI-TRACER recognizes a 16 BIT code known as Smart-Code.

FUNCTION : This is the part of the code which defines the function which that device has e.g. ZONE number ( for detectors) or

arm/disarm, panic, test (for remote controls). The functions are determined by a 4 bit configuration. See table 1 and 2

NOTE:

- A wireless sensor transmits an alarm condition only for a short period of time (2 - 4 Seconds)

- To save power the sensors are designed not to transmit if continuous movement is detected.

- A detector will only transmit if either a 30 seconds (test mode ) or 3 minutes (normal mode) has elapsed from the last detection.

WIRELESS DETECTORS and REMOTE CONTROL operation

0 0 0 0

0 0 0 1

0 0 1 0

0 0 1 1

0 1 0 0

0 1 0 1

0 1 1 0

0 1 1 1

FUNCTION WHEN ACTIVATED

4 3 2 1 4 3 2 1

1 0 0 0

1 0 0 1

1 0 1 0

1 0 1 1

1 1 0 0

1 1 0 1

BIT SETTING: BIT SETTING:

Table 1

Although each code and function can be programmed individually IT IS EASIER TO PROGRAM THE DETECTOR and

THE REMOTE CONTROL FIRST and then program the code into the MINI-TRACER unit using the self learning method.

( see page 7)

To program the sensors and detectors see the intructions supplied with each device

Remote Control may have up to four buttons and each button may be. programmed to carry out a specific task

The standard unit supplied has only two buttons 1= Panic, 2=Arm/Disarm.

Table 2

- 6 -

M000037

A

B

1

2

3

4

5

6

7

8

FACTORY DEFAULT

0

#

1

0

1

0

0 # 1D

010

SET DETECTORS CODE

SET REMOTE CONTROL CODE

SELF LEARNING OF REMOTE CONTROL AND DETECTORS CODE.

INSTALLER CODE REG. NO.

4 - the decimal equivalent of the stored code will be

displayed one digit at the time. Enter to exit

PROGRAMMING THE DETECTOR AND REMOTE CONTROL CODES

Following is the procedure to program the Detectors and Remote Controls to operate properly with the MINI-TRACER:

1- program the sensors / detectors following the instructions supplied with each device keeping THE SAME code for all detectors.

2- program the ZONE number ( function) according to your requirements (table 1- page6)

3- enter the self learning mode in the MINI-TRACER by entering:

4- activate any of the programmed DETECTORS making sure that the MINI-TRACER displays the received code

5- press to store/learn the DETECTOR’s code

6- Re-enter the self learning mode in the MINI-TRACER by entering:

7- press any button on the REMOTE CONTROL until the MINI-TRACER displays the different code received.

5- press to store / learn the REMOTE CONTROL code.

Using the same method a 3rd code may be stored using the key to define the code used by an Armed Response

officer to send a “standing” signal to base. Please note that this code cannot be entered manually ( only by self-learn)

A

0 # 1D

010

B

MANUALLY PROGRAMMING THE REMOTE CONTROL AND DETECTORS CODE.

1 - Enter the manual setting mode by entering: for the Detectors code

or: for the Remote Control code

2 - set the desired code by toggling each bit of the code using keys 1 to #

(see TABLE)

3 - press and buttons together to store the code and exit .

A

0#1

0

10

B

0#1

0

10

#

*

New!!

C

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16

1 2 3 4 5 6 7 8 9 0 A B C D * #

KEY

BIT NO

The new MINI-TRACER introduces a new Code structure

which has many advantages to the old 10 bit code. These features are:

- 16 BITS = 65,535 CODE COMBINATIONS.

- multiple PARITY and CHECKSUM = each segment of the code has CHECK SUM and PARITY.

which results in: - wider scope and applications , less duplicate codes and very reliable operation.

known as “SMART CODE”

New!!

1 2 345 6

ARM

WARN

PER

- 7 -

-4-

(Please note: Both the “Wireless Zone supervision” option (Pg 8) and the active wireless zones (pg 10)

need to be enabled by the installer before this function will work correctly.)

The MINI-TRACER is capable of reporting a faulty wireless detector.

To display the faulty (non reporting) wireless detector press and hold the key until it beeps

WIRELESS ZONE SUPERVISION

*

An “ F “ is shown on the display.

HOLD

TILL BEEP

New!!

1 2 345 6

ARM

WARN

PER

Faulty detector shown on the ARM Leds

*

WIRELESS ZONE SUPERVISION TEST

ALTHOUGH THE "FACTORY" OPTIONS REFLECT THE CHOICE OF THE MAJORITY OF

INSTALLERS AND END-USERS, PROPER OPERATION AND COMPLIANCE WITH SPECIFIC

REQUIREMENTS CAN BE ACHIEVED THROUGH REPROGRAMMING.

THE PROGRAMMABLE OPTIONS ARE DIVIDED INTO 4 SECTIONS:

- 1 - ENCODING THE WIRELESS DETECTORS AND REMOTE CONTROLS

- 2 - SYSTEM OPTION REGISTERS.

- 3 - SYSTEM I.D. CODES AND TEL. NUMBERS

- 4 - CIRCUIT (ZONE) OPTION REGISTERS.

- 5 - KEYPAD LOCAL OPTION REGISTERS.

SECTIONS 1, 2, 3 AND 4 RELATE TO THE MAIN BOARD:

SECTION 4 IS RELATES TO THE KEYPAD UNIT ITSELF.

FACTORY DEFAULT

"INSTALLER CODE"

= 1 0 0 0

THE TRACER IS ORIGINALLY PROGRAMMED WITH A "FACTORY DEFAULT" SET OF OPTIONS.

INSTALLER PROGRAMMING THE MINI-TRACER

9

0

A B C D #

9

0

A B C D #

*

#

M000037

SPARE

OFF = NO REPORT

SPARE

ON = REPORT ARM / DISARM SIGNALS

ON = REPORT SYSTEM BATTERY LOW

ON = REPORT SYSTEM MAINS FAILURE

SPARE

0 # 0 2010

OPTIONS REGISTER NO. 2

1

2

3

4

5

6

7

8

0

#

1

7

8

9

0

1

0

FACTORY DEFAULTS

For the next 3 options you need to enter a value between 0 and 250.

EXAMPLES: - To set the entry-delay to 35 seconds enter: 1 0 0 0 # 1 7 0 3 5 (sec)

- To set the check-in interval time to 24 hours enter:: 1 0 0 0 # 1 8 0 2 4 (hrs)

- To set the siren duration to 4 minutes enter: 1 0 0 0 # 1 9 2 4 0 (4 x 60) (sec)

N.B. - A CHECK-IN INTERVAL VALUE OF "0" WILL AUTOMATICALLY DISABLE THE OPTION ( NO CHECKING-IN TRANSMISSION ).

- THE “EXIT” DELAY IS AUTOMATICALLY SET TO DOUBLE THE “ENTRY” DELAY

ENTRY / EXIT DELAY VALUE (SEC)

CHECK-IN INTERVAL (HRS)

SIREN DURATION (SEC)

OFF = SILENT PANIC BUTTON

OFF = NORMAL OPERATION

OFF = AUXIL. SIGNALS ON BUZZER ONLY

SPARE

ON = SIREN WITH PANIC BUTTON

ON = MULTI-USER OPERATION

ON = AUXIL. SIGNALS ON BUZZER & SIREN

SPARE

0 # 0 1010

OPTIONS REGISTER NO. 1

= OFF

= ON

NOTE:

1

2

3

4

5

6

7

8

OFF = USE KS INPUT FOR PANIC BUTTON

ON = USE KS INPUT WITH A KEY-SWITCH

OFF = TRACER OPERATION

ON = SNIPER OPERATION

OFF = NO CONFIRMATION(REPEATED)

OFF = SPARE

OFF = NO REPORT

OFF = AUTO ARM TIME - 15 MINUTES

ON = ARM/DISARM CONFIRMATION(REPEATED)

ON = SPARE

ON = REPORT WIRELESS SUPERVISION

ON = AUTO-ARM TIME - 2HRS

OFF= AUTO ARM - DISABLED

ON = AUTO ARM ENABLED

0 # 0 8010

OPTIONS (MODE) REGISTER NO.8

1

2

3

4

5

6

7

8

- 8 -

FACTORY DEFAULT

FACTORY DEFAULT FACTORY DEFAULT

ON = WIRELESS RF BLOCKING ENABLED OFF = WIRELESS RF BLOCKING DISABLED

ON = REPORT “BATTERY LOW” IN SENSORS

ON = PERIMETER MASK LINKED TO ARM LEVEL OFF = PERIMETER AND ARM MASKS NOT LINKED

OFF = AUDIBLE ARM/DISARM ON KEY-PAD

OFF = DISABLE WARNING VIA REMOTE

ON = SILENT ARM/DISARM ON KEY-PAD

ON = ENABLE WARNING VIA REMOTE

New!!

5

4

0

2

3

2

4

(35SEC)

(24HRS)

(240SEC)

0#010

I AM REPEATER “ 1”

REPEATER “1”

New!!

ON = SNIPER OPERATION

0#

010

Set the “I AM” Repeater Number

21

0

1

2

#

Display the Repeater Number

*

THE CURRENT REPEATER

NUMBER WILL BE INDICATED.

This feature can only be used if the MINI-TRACER itself is setup TO BE A REPEATER with the NECESSARY HARDWARE and OPTION 6 of Option-Register 8 is ON.

0#

010

Set the Repeater Number

21

0#

0#0101

2

Display the “I AM ” Repeater Number

*

THE CURRENT REPEATER

NUMBER WILL BE INDICATED.

New!!

PROGRAMMING THE FIELD REPEATER NUMBER

PROGRAMMING

SPARE SPARE

M000037

Mami Mini TRACER Manuel utilisateur

Manuels Panneau de contrôle populaires d'autres marques
