Shenzhen Wanlida After-sale Service Department SG3318+ Introduction to models
2、Whole composition and the structure
No. Figure Number Name Quantity Remark
1 34-01-3501-00 Assembly of upper front casing for D03 1
2 42-02-3599-00 Assembly of small glass for D03 1
3 29-02-3599-00 Assembly of camera glass for D03 1
4 30-01-3599-00 Assembly of flashlight for D03 1
5 39-00-3599-00 decorative parts of small glass for D03 1
6 58-23-3599-00 Assembly of MP3 keypad for D03 1
7 35-01-3501-00 D03 upper back casing assembly 1
8 43-02-3599-00 D03 large glass assembly 6
9 65-02-3599-00 Assembly of decorative parts of 1
10 20-17-0100-01 Screw M1.4*0.30*3.0L 5
11 20-17-3599-00 Screw M1.4*0.30*5.5L 1
12 44-03-3501-00 Left screw blocking cap of upper casing 1
13 44-04-3501-00 Right screw blocking cap of upper casing 1
14 61-00-1200-00 S588 shaft (left) 1
15 36-01-3501-00 Assembly of lower front casing for D03 1
16 25-03-3599-00 Assembly of side key for D03 1
17 37-01-3501-00 Assembly of lower back casing for D03 1
18 75-03-3501-00 Assembly of battery for D03 1
19 20-17-0102-01 Bolt M1.2*0.25*3.3L (Self-attack) 2
20 45-08-3508-00 D03 I/O plastic plug 1
21 27-13-3508-00 Finished parts of antenna (built-in) for 1
22 46-02-3508-00 D03 RF plastic plug 1
23 21-02-3501-00 Assembly of keypad for D03 1
24 28-02-3599-00 D03 Flexible printed Circuit (FPC) 1
25 24-01-3499-00 Finished parts of D04 LCD 1
26 31-00-3499-00 Finished parts of camera for D04 1
27 88-01-3599-00 D03 1318 single speaker 1
28 74-01-2399-01 D01 motor 1
29 28-03-3599-00 Mainboard PCBA for D03 1
30 21-04-2301-00 Assembly of keypad membrane for D01 1
31 62-00-3431-00 MP3 keypad membrane for D04 1
32 88-03-3599-00 Headphone/single side sound for D03 1
