INSTRUCTION MANUAL

MANUEL D'INSTRUCTION

MANUAL DE INSTRUCCIONES

IMPORTANT: Read Before Using.

IMPORTANT: Lire avant usage.

IMPORTANTE: Leer antes de usar.

Cordless Screwdriver

Visseuse sans Fil

Atornillador Inalámbrico

BFT022F

BFT044F

BFT084F

BFT126F

013043

ENGLISH (Original instructions)

SPECIFICATIONS

Model BFT022F BFT044F BFT084F BFT126F

Hard joint 0.5 - 2 N•m

(4 - 18 in•lbs)

1 - 4 N•m

(8.9 - 35 in•lbs)

3 - 8 N•m

(27 - 71in•lbs)

5 - 12 N•m

(44 - 106 in•lbs)

Fastening torque

Soft joint 0.5 - 2 N•m

(4 - 18 in•lbs)

1 - 4 N•m

(8.9 - 35 in•lbs)

3 - 8 N•m

(27 - 71in•lbs)

5 - 12 N•m

(44 - 106 in•lbs)

No load speed (RPM) 700 /min. 950 /min. 780 /min. 410 /min.

200 x 74 x 250 mm (7-7/8" x 2-15/16" x 9-7/8") (with Battery Cartridge BL1430)

Dimensions

200 x 74 x 235 mm (7-7/8" x 2-15/16" x 9-1/4") (with Battery Cartridge BL1415)

1.5 kg (3.4 lbs.) (with Battery Cartridge BL1430)

Net weight 1.4 kg (3.0 lbs.) (with Battery Cartridge BL1415)

Rated voltage D.C.14.4V

Battery cartridge BL1430 / BL1415

• Due to our continuing program of research and development, the specifications herein are subject to change without notice.

• Specifications and battery cartridge may differ from country to country.

• Weight, with battery cartridge, according to EPTA-Procedure 01/2003

GEA006-2

General Power Tool Safety

Warnings

WARNING Read all safety warnings and all

instructions. Failure to follow the warnings and

instructions may result in electric shock, fire and/or

serious injury.

Save all warnings and

instructions for future reference.

The term "power tool" in the warnings refers to your

mains-operated (corded) power tool or battery-operated

(cordless) power tool.

Work area safety

1. Keep work area clean and well lit. Cluttered or

dark areas invite accidents.

2. Do not operate power tools in explosive

atmospheres, such as in the presence of

flammable liquids, gases or dust. Power tools

create sparks which may ignite the dust or fumes.

3. Keep children and bystanders away while

operating a power tool. Distractions can cause

you to lose control.

Electrical Safety

4. Power tool plugs must match the outlet. Never

modify the plug in any way. Do not use any

adapter plugs with earthed (grounded) power

tools. Unmodified plugs and matching outlets will

reduce risk of electric shock.

5. Avoid body contact with earthed or grounded

surfaces such as pipes, radiators, ranges and

refrigerators. There is an increased risk of

electric shock if your body is earthed or grounded.

6. Do not expose power tools to rain or wet

conditions. Water entering a power tool will

increase the risk of electric shock.

7. Do not abuse the cord. Never use the cord for

carrying, pulling or unplugging the power tool.

Keep cord away from heat, oil, sharp edges or

moving parts. Damaged or entangled cords

increase the risk of electric shock.

8. When operating a power tool outdoors, use an

extension cord suitable for outdoor use. Use of

a cord suitable for outdoor use reduces the risk of

electric shock.

9. If operating a power tool in a damp location is

unavoidable, use a ground fault circuit

interrupter (GFCI) protected supply. Use of an

GFCI reduces the risk of electric shock.

Personal Safety

10. Stay alert, watch what you are doing and use

common sense when operating a power tool.

Do not use a power tool while you are tired or

under the influence of drugs, alcohol or

medication. A moment of inattention while

operating power tools may result in serious

personal injury.

11. Use personal protective equipment. Always

wear eye protection. Protective equipment such

as dust mask, non-skid safety shoes, hard hat, or

hearing protection used for appropriate conditions

will reduce personal injuries.

12. Prevent unintentional starting. Ensure the

switch is in the off-position before connecting

to power source and/or battery pack, picking

up or carrying the tool. Carrying power tools with

your finger on the switch or energising power tools

that have the switch on invites accidents.

13. Remove any adjusting key or wrench before

turning the power tool on. A wrench or a key left

attached to a rotating part of the power tool may

result in personal injury.

14. Do not overreach. Keep proper footing and

balance at all times. This enables better control

of the power tool in unexpected situations.

15. Dress properly. Do not wear loose clothing or

jewellery. Keep your hair, clothing, and gloves

away from moving parts. Loose clothes,

jewellery or long hair can be caught in moving

parts.

16. If devices are provided for the connection of

dust extraction and collection facilities,

ensure these are connected and properly used.

Use of dust collection can reduce dust-related

hazards.

Power tool use and care

17. Do not force the power tool. Use the correct

power tool for your application. The correct

power tool will do the job better and safer at the

rate for which it was designed.

18. Do not use the power tool if the switch does

not turn it on and off. Any power tool that cannot

be controlled with the switch is dangerous and

must be repaired.

19. Disconnect the plug from the power source

and/or the battery pack from the power tool

before making any adjustments, changing

accessories, or storing power tools. Such

preventive safety measures reduce the risk of

starting the power tool accidentally.

20. Store idle power tools out of the reach of

children and do not allow persons unfamiliar

with the power tool or these instructions to

operate the power tool. Power tools are

dangerous in the hands of untrained users.

21. Maintain power tools. Check for misalignment

or binding of moving parts, breakage of parts

and any other condition that may affect the

power tool’s operation. If damaged, have the

power tool repaired before use. Many accidents

are caused by poorly maintained power tools.

22. Keep cutting tools sharp and clean. Properly

maintained cutting tools with sharp cutting edges

are less likely to bind and are easier to control.

23. Use the power tool, accessories and tool bits

etc. in accordance with these instructions,

taking into account the working conditions

and the work to be performed. Use of the power

tool for operations different from those intended

could result in a hazardous situation.

Battery tool use and care

24. Recharge only with the charger specified by

the manufacturer. A charger that is suitable for

one type of battery pack may create a risk of fire

when used with another battery pack.

25. Use power tools only with specifically

designated battery packs. Use of any other

battery packs may create a risk of injury and fire.

26. When battery pack is not in use, keep it away

from other metal objects, like paper clips,

coins, keys, nails, screws or other small metal

objects, that can make a connection from one

terminal to another. Shorting the battery

terminals together may cause burns or a fire.

27. Under abusive conditions, liquid may be

ejected from the battery; avoid contact. If

contact accidentally occurs, flush with water.

If liquid contacts eyes, additionally seek

medical help. Liquid ejected from the battery may

cause irritation or burns.

Service

28. Have your power tool serviced by a qualified

repair person using only identical replacement

parts. This will ensure that the safety of the power

tool is maintained.

29. Follow instruction for lubricating and

changing accessories.

30. Keep handles dry, clean and free from oil and

grease.

GEB050-2

CORDLESS SCREWDRIVER

SAFETY WARNINGS

1. Hold power tool by insulated gripping

surfaces, when performing an operation

where the fastener may contact hidden wiring.

Fasteners contacting a "live" wire may make

exposed metal parts of the power tool "live" and

could give the operator an electric shock.

2. Always be sure you have a firm footing.

Be sure no one is below when using the tool in

high locations.

3. Hold the tool firmly.

4. Keep hands away from rotating parts.

5. Do not touch the bit or the workpiece

immediately after operation; they may be

extremely hot and could burn your skin.

SAVE THESE INSTRUCTIONS.

WARNING:

DO NOT let comfort or familiarity with product

(gained from repeated use) replace strict adherence

to safety rules for the subject product. MISUSE or

failure to follow the safety rules stated in this

instruction manual may cause serious personal

injury.

USD301-1

Symbols

The followings show the symbols used for tool.

･volts

･direct current

･no load speed

･revolutions or reciprocation per minute

ENC007-7

IMPORTANT SAFETY

INSTRUCTIONS

FOR BATTERY CARTRIDGE

1. Before using battery cartridge, read all

instructions and cautionary markings on (1)

battery charger, (2) battery, and (3) product

using battery.

2. Do not disassemble battery cartridge.

3. If operating time has become excessively

shorter, stop operating immediately. It may

result in a risk of overheating, possible burns

and even an explosion.

4. If electrolyte gets into your eyes, rinse them

out with clear water and seek medical

attention right away. It may result in loss of

your eyesight.

5. Do not short the battery cartridge:

(1) Do not touch the terminals with any

conductive material.

(2) Avoid storing battery cartridge in a

container with other metal objects such as

nails, coins, etc.

(3) Do not expose battery cartridge to water

or rain.

A battery short can cause a large current flow,

overheating, possible burns and even a

breakdown.

6. Do not store the tool and battery cartridge in

locations where the temperature may reach or

exceed 50 ﾟC (122 ﾟF).

7. Do not incinerate the battery cartridge even if

it is severely damaged or is completely worn

out. The battery cartridge can explode in a fire.

8. Be careful not to drop or strike battery.

9. Do not use a damaged battery.

SAVE THESE INSTRUCTIONS.

Tips for maintaining maximum battery life

1. Charge the battery cartridge before

completely discharged.

Always stop tool operation and charge the

battery cartridge when you notice less tool

power.

2. Never recharge a fully charged battery

cartridge.

Overcharging shortens the battery service life.

3. Charge the battery cartridge with room

temperature at 10 ﾟC - 40 ﾟC (50 ﾟF - 104 ﾟF).

Let a hot battery cartridge cool down before

charging it.

4. Charge the battery cartridge once in every six

months if you do not use it for a long period of

time.

FUNCTIONAL DESCRIPTION

CAUTION:

• Always be sure that the tool is switched off and the

battery cartridge is removed before adjusting or

checking function on the tool.

Installing or removing battery cartridge

013044

CAUTION:

• Always switch off the tool before installing or

removing of the battery cartridge.

• Hold the tool and the battery cartridge firmly

when installing or removing battery cartridge.

Failure to hold the tool and the battery cartridge

firmly may cause them to slip off your hands and

result in damage to the tool and battery cartridge

and a personal injury.

To remove the battery cartridge, slide it from the tool

while sliding the button on the front of the cartridge.

To install the battery cartridge, align the tongue on the

battery cartridge with the groove in the housing and slip it

into place. Insert it all the way until it locks in place with a

little click. If you can see the red indicator on the upper

side of the button, it is not locked completely.

CAUTION:

• Always install the battery cartridge fully until the red

indicator cannot be seen. If not, it may accidentally

fall out of the tool, causing injury to you or someone

around you.

• Do not install the battery cartridge forcibly. If the

cartridge does not slide in easily, it is not being

inserted correctly.

Switch action

004245

CAUTION:

• Before installing the battery cartridge into the tool,

always check to see that the switch trigger actuates

properly and returns to the "OFF" position when

released.

To start the tool, simply pull the switch trigger. Release

the switch trigger to stop.

Reversing switch action

013071

CAUTION:

• Always check the direction of rotation before

operation.

• Use the reversing switch only after the tool comes

to a complete stop. Changing the direction of

rotation before the tool stops may damage the tool.

• When not operating the tool, always set the

reversing switch lever to the neutral position.

This tool has a reversing switch to change the direction of

rotation. Depress the reversing switch lever from the A

side for clockwise rotation or from the B side for

counterclockwise rotation.

When the reversing switch lever is in the neutral position,

the switch trigger cannot be pulled.

Lighting up the lamps

004247

CAUTION:

• Do not look in the light or see the source of light

directly.

Pull the switch trigger to light up the lamp. The lamp

keeps on lighting while the switch trigger is being pulled.

The light automatically goes out 10 seconds after the

switch trigger is released.

1. Front lamp

1. Reversing switch

lever

1. Switch trigger

1. Red indicator

2. Button

3. Battery cartridge

NOTE:

• Use a dry cloth to wipe the dirt off the lens of lamp.

Be careful not to scratch the lens of lamp, or it may

lower the illumination.

LED indicator

013072

The LED indicator on the tool shows the following

functions.

1. LED indicator

LED indicator Beeper

Auto-stop fastening

This function works when the tool has reached

the preset fastening torque and normal

tightening has been completed. This helps

overtightening to be avoided.

Delayed re-start

For approximately one second after auto-stop

fastening, the tool does not start even if the

switch trigger is pulled.

Warning against

insufficient fastening

Insufficient fastening has been performed

when the switch trigger has released before

reaching the preset fastening torque.

Lights up in red. A long beep

Retighten the

screw.

Warning for battery

cartridge capacity

This indicates the appropriate time to replace

the battery cartridge when the battery power

becomes low.

Flickers in red slowly. A series of long

beeps

Flickers in red quickly. A series of short

beeps

A series of short

beeps

Replace the battery

with fully charged

one.

Replace the battery

with fully charged

one.

Replace the battery

with fully charged

one.

Checking the

remaining battery

capacity, Autostop

This function works when the battery power

is almost used up. At this time, tool stops

immediately.

Check the LED

indicator, lamp and

beeper operation

This function works to check the proper

operation of the LED indicator, lamp and

beeper when a battery cartridge has been

inserted into the tool.

Lights up first in green,

next red.

(And then the lamp

comes on.)

A series of very

short beeps

Anti-reset of

controller

This function works when an abnormal drop

of the battery voltage occurs for some reason,

and the tool stops.

Flickers in red and

green alternatively.

A series of short

beeps

Overheat

This function works when the temperature

of the controller goes up very highly,

and the tool stops.

Remove the battery

cartridge immediately

and cool the tool

down.

Operation error of

the switch trigger

This function works to avoid the tool's

immediate start upon insertion of battery

cartridge into the tool with the switch trigger

being pulled.

Flickers in red and

green alternatively.

Release the switch

trigger.

Function Status Action to be taken

Lights up in green for

approximately one

second.

Status of the LED indicator/beeper

Warning for limit of

the fastening

capacity

The tool automatically stops without the clutch

working when exceeding the fastening capacity

limit.

Flickers in red and

green alternatively.

A series of short

beeps

Remove the battery

cartridge and then

install it again.

Be sure to use the

tool under load within

its capacity.

013073

Adjusting the fastening torque

013092

When you wish to drive machine screws, wood screws,

hex bolts, etc. with the predetermined torque, adjusting

the fastening torque as follows.

1. First remove the battery cartridge from the tool.

2. Loosen and remove the screw that secures ring.

3. Rotate the ring in the front of the tool by hand so

that a hole can be seen below the ring.

4. Place the battery cartridge in place and pull the

switch trigger. Release it so that the adjusting ring

rotates and becomes visible in the hole. And then

remove the battery cartridge.

013091

5. Use an optional adjusting grip to adjust the

fastening torque. Insert the pin of the adjusting grip

into the hole in the front of the tool. And then, turn

the adjusting grip clockwise to set a greater

fastening torque, and counterclockwise to set a

smaller fastening torque.

6. Align the yellow line with your desired number on

the fastening torque scale.

7. Insert the battery cartridge and be sure that a

fastening torque has been set up by using a

fastening torque tester.

8. Rotate the ring in front of the tool and then tighten

the screw to secure the ring.

NOTE:

• Numbers on the fastening torque scale is a

guideline to set up your desired fastening torque.

ASSEMBLY

CAUTION:

• Always be sure that the tool is switched off and the

battery cartridge is removed before carrying out

any work on the tool.

Installing or removing driver bit or socket bit

9mm(3/8")

12mm(15/32")

001761

Use only the driver bit or socket bit shown in the figure.

Do not use any other driver bit or socket bit.

To install the bit, pull the sleeve in the direction of the

arrow and insert the bit into the sleeve as far as it will go.

Then release the sleeve to secure the bit.

004047

To remove the bit, pull the sleeve in the direction of the

arrow and pull the bit out firmly.

NOTE:

• If the bit is not inserted deep enough into the sleeve,

the sleeve will not return to its original position and

the bit will not be secured. In this case, try

re-inserting the bit according to the instructions

above.

1. Bit

2. Sleeve

1. Adjusting ring

2. Ring

3. Scale

4. Adjusting grip

5. Hole for

adjusting grip

6. Yellow line

7. Compression

spring

1. Adjusting grip

2. Ring

OPERATION

Screwdriving operation

013045

Place the point of the driver bit in the screw head and

apply pressure to the tool. Then switch the tool on. When

the clutch cuts in, the motor will stop automatically. Then

release the switch trigger.

NOTE:

• Make sure that the driver bit is inserted straight in

the screw head, or the screw and/or bit may be

damaged.

Limits of fastening capacity

Use the tool within the range of the revolution angle up to

360 ﾟ. If you use the tool beyond the upper limit of this

range, the clutch does not work. And the tool cannot

deliver enough fastening torque (LED indicator flickers in

red and green alternatively).

NOTE:

• The revolution angle means the angle which a

screw/bolt revolves when the tool attains to 100%

from 50% of desired torque.

• Use of a low temperature conditioned battery

cartridge may sometimes give warning for battery

cartridge capacity by warning lamp and beeper

which makes the tool stop immediately. In this case,

the fastening capacity may be inferior to the

specification on this manual even if a charged

battery cartridge is used.

MAINTENANCE

CAUTION:

• Always be sure that the tool is switched off and the

battery cartridge is removed before attempting to

perform inspection or maintenance.

• Never use gasoline, benzine, thinner, alcohol or the

like. Discoloration, deformation or cracks may

result.

Replacing carbon brushes

001145

Remove and check the carbon brushes regularly.

Replace when they wear down to the limit mark. Keep

the carbon brushes clean and free to slip in the holders.

Both carbon brushes should be replaced at the same

time. Use only identical carbon brushes.

Use a screwdriver to remove the brush holder caps. Take

out the worn carbon brushes, insert the new ones and

secure the brush holder caps.

004250

To maintain product SAFETY and RELIABILITY, repairs,

any other maintenance or adjustment should be

performed by Makita Authorized or Factory Service

Centers, always using Makita replacement parts.

OPTIONAL ACCESSORIES

CAUTION:

• These accessories or attachments are

recommended for use with your Makita tool

specified in this manual. The use of any other

accessories or attachments might present a risk of

injury to persons. Only use accessory or

attachment for its stated purpose.

If you need any assistance for more details regarding

these accessories, ask your local Makita Service Center.

• Makita genuine battery and charger

• Adjust grip

• Protector

• Grip Base Set

• Grip 37

• Anti kickback head

1. Brush holder cap

2. Screwdriver

1. Limit mark

NOTE:

• Some items in the list may be included in the tool

package as standard accessories. They may differ

from country to country.

MAKITA LIMITED ONE YEAR WARRANTY

Warranty Policy

Every Makita tool is thoroughly inspected and tested

before leaving the factory. It is warranted to be free of

defects from workmanship and materials for the period

of ONE YEAR from the date of original purchase.

Should any trouble develop during this one year period,

return the COMPLETE tool, freight prepaid, to one of

Makita’s Factory or Authorized Service Centers. If

inspection shows the trouble is caused by defective

workmanship or material, Makita will repair (or at our

option, replace) without charge.

This Warranty does not apply where:

IN NO EVENT SHALL MAKITA BE LIABLE FOR ANY

INDIRECT, INCIDENTAL OR CONSEQUENTIAL

DAMAGES FROM THE SALE OR USE OF THE

PRODUCT. THIS DISCLAIMER APPLIES BOTH

DURING AND AFTER THE TERM OF THIS

WARRANTY.

MAKITA DISCLAIMS LIABILITY FOR ANY IMPLIED

WARRANTIES, INCLUDING IMPLIED WARRANTIES

OF "MERCHANTABILITY" AND "FITNESS FOR A

SPECIFIC PURPOSE," AFTER THE ONE YEAR TERM

OF THIS WARRANTY.

This Warranty gives you specific legal rights, and you

may also have other rights which vary from state to

state. Some states do not allow the exclusion or

limitation of incidental or consequential damages, so

the above limitation or exclusion may not apply to you.

Some states do not allow limitation on how long an

implied warranty lasts, so the above limitation may not

apply to you.

repairs have been made or attempted by others:

repairs are required because of normal wear and

tear:

the tool has been abused, misused or improperly

maintained:

alterations have been made to the tool.

EN0006-1

Autres manuels pour BFT022F

Ce manuel convient aux modèles suivants

Table des matières

Langues :

Autres manuels Makita Tournevis sans fil

Makita

Makita 6722DW Manuel utilisateur

Manuels Tournevis sans fil populaires d'autres marques

Panasonic

Panasonic EYFGB1N Manuel utilisateur
