MAKINEX DPC-2200 Manuel utilisateur

DUAL PRESSURE CLEANER

DPC-2200

OPERATOR’S MANUAL

Rev 0920


Table of Contents
INTRODUCTION ...............................................................................................................................................1
DISCLAIMER ........................................................................................................................................................2
ABOUT THIS MANUAL.........................................................................................................................................3
KEY TERMS..........................................................................................................................................................3
SAFETY INFORMATION ....................................................................................................................................4
EMERGENCY INFORMATION...............................................................................................................................8
SAFETY DECALS ...................................................................................................................................................8
PRODUCT DESCRIPTION AND SPECIFICATION ................................................................................................10
OVERALL MACHINE DIMENSIONS.....................................................................................................................11
CONTROLS AND FEATURES...............................................................................................................................13
OPERATION ...................................................................................................................................................15
OIL LEVEL CHECK...............................................................................................................................................15
REFUELING........................................................................................................................................................16
OPERATING YOUR PRESSURE CLEANER............................................................................................................17
1. HOW TO PRE-START PRESSURE CLEANER ...........................................................................................17
2. ATTACHING HIGH-PRESSURE HOSE TO SPRAY-GUN ...........................................................................17
3. CONNECT GARDEN HOSE TO WATER INLET CONNECTION .................................................................18
4. ADJUST VALVE POSTION TO SURFACE-CLEANER ................................................................................19
5. START THE ENGINE..............................................................................................................................19
6. TWO TYPES OF OPERATION ................................................................................................................20
7. NOZZLE................................................................................................................................................20
8. RETRACTABLE HANDLES......................................................................................................................21
9. STOPPING THE PRESSURE CLEANER....................................................................................................21
MAINTENANCE ..............................................................................................................................................22
GENERAL RECOMMENDATIONS: ......................................................................................................................22
GENERAL MAINTENANCE .................................................................................................................................23
CLEAN DEBRIS...............................................................................................................................................23
CHECK AND CLEAN INLET FILTER ..................................................................................................................23


CHECK HIGH PRESSURE HOSE.......................................................................................................................23
CHECK SPRAY GUN........................................................................................................................................24
CHECK WAND................................................................................................................................................24
NOZZLE MAINTENANCE ................................................................................................................................24
PUMP MAINTENANCE ......................................................................................................................................25
CHANGING PUMP OIL...................................................................................................................................25
CHECKING PUMP OIL LEVEL..........................................................................................................................26
LENGTHY PUMP LAY-OFFS............................................................................................................................27
PUTTING THE PUMP BACK INTO SERVICE.....................................................................................................27
SURFACE-CLEANER MAINTENANCE..................................................................................................................28
ENGINE MAINTENANCE ....................................................................................................................................28
STORAGE...........................................................................................................................................................28
STORAGE WITH FUEL IN TANK......................................................................................................................28
RUST PREVENTION IN CYLINDERS.................................................................................................................28
STORAGE OF PRESSURE CLEANER ................................................................................................................29
OTHER STORAGE TIPS ...................................................................................................................................29
TROUBLESHOOTING.......................................................................................................................................30
LIMITED WARRANTY......................................................................................................................................32
WARRANTY EXCLUSIONS ..................................................................................................................................33
OWNER’S RESPONSIBILITY UNDER LIMITED WARRANTY: ................................................................................34
CONTACT INFORMATION...............................................................................................................................35
APPENDIX A- RISK ASSESSMENT .......................................................................................................................35

Page 1 of 38

INTRODUCTION

Thank you for purchasing a MAKINEX product.

This manual provides information and procedures to safely operate and maintain

the Dual Pressure Cleaner DPC-2200 Range. For your own safety and protection

from injury, carefully read, understand and observe the safety instructions

described in this manual.

Keep this manual or a copy of it with the machine. If you lose this manual or need

an additional copy, please contact MAKINEX. This machine is designed and built

with user safety in mind; however, it can present hazards if improperly operated

and serviced. Please follow the operating instructions carefully. If there are any

questions regarding operating or servicing of this machine, please contact

MAKINEX.

The information contained in this manual was based on machines in production at

the time of publication. MAKINEX reserves the right to change any portion of this

information without notice.

All rights, especially copying and distribution rights are reserved.

No part of this publication may be reproduced in any form or by any means,

electronic or mechanical, including photocopying, without express written

permission from MAKINEX.

Any type of reproduction or distribution not authorised MAKINEX represents an

infringement of valid copyrights and will be persecuted. We expressly reserve the

right to make technical modifications, even without due notice, which aim at

improving our machines or their safety standards.

DPC-2200 USER MANUAL Page 2 of 38

DISCLAIMER

MAKINEX and its affiliates take no responsibility for any damage, injury or death

resulting from the incorrect or unsafe use of this product. Use of this product

should be undertaken by competent persons only. It is the operator’s responsibility

to ensure that the following safety procedures are followed. If you are unsure, do

not operate this product.

Record the model and serial numbers as well as date and place of purchase for

future reference. Have this information available when ordering parts and when

making technical or warranty inquiries

MAKINEX SUPPORT

Refer to contact details on pg. 35

MODEL NO.

DPC-2200

SERIAL NO.

DATE OF PURCHASE

PURCHASE LOCATION

DPC-2200 USER MANUAL Page 3 of 38

ABOUT THIS MANUAL

This manual uses the following symbols to help differentiate between different

kinds of information. The safety symbol is used with a key word to alert you to

potential hazards in operating and owning power equipment. Follow all safety

messages to avoid or reduce the risk of serious injury or death.

KEY TERMS

READ

CAREFULLY

READ CAREFULLY –refers to important information that

should be paid careful attention.

CAUTION

CAUTION - indicates a potential hazardous situation which,

if not avoided, may result in minor or moderate injury

WARNING

WARNING –indicates a potentially hazardous situation

which, if not avoided, could result in death or serious injury

DANGER

DANGER –indicates an imminently hazardous situation

which, if not avoided, will result in death or serious injury

PROHIBITED

PROHIBITED –identifies actions that should never be

carried out by anyone interacting with the machine.

These safety warnings do not eliminate all possible hazards that could occur

therefore it is essential to use common sense and to strictly follow any

instructions to prevent accidents.

DPC-2200 USER MANUAL Page 4 of 38

SAFETY INFORMATION

WARNING

Read this manual thoroughly before operating your

pressure cleaner. Failure to follow instructions could

result in serious injury or death

DANGER

RISK OF EXPLOSION OR FIRE

Fuel and its vapours are extremely flammable and

explosive

Fire or explosion can cause severe burns or death

ALWAYS shut off engine and allow it to cool a least 2 minutes before adding

fuel to the tank

ALWAYS use care in filling tank to avoid spilling fuel. Move pressure cleaner

away from fuelling area before starting engine.

ALWAYS keep maximum fuel level below top of tank to allow for expansion.

ALWAYS operate and use equipment in well ventilated areas free from

obstructions. Equip areas with fire extinguishers suitable for gasoline fires

ALWAYS keep pressure cleaner a minimum of 1.2m away from surfaces (such

as houses, automobiles, or live plants) that could be damaged from muffler

exhaust heat.

ALWAYS store fuel in an OSHA approved container, in a secure location away

from work area.

NEVER spray flammable liquids.

In the event of a fuel spill, ensure machine and entire area is cleaned of excess

before operation.

DANGER

RISK OF BREATHING

Running engine gives off Carbon Monoxide, an

odourless, colourless, poisonous gas.

Breathing Carbon Monoxide can cause nausea,

fainting or death.

Some chemicals or detergents may be harmful if

inhaled or ingested, causing severe nausea,

fainting or poisoning.

ALWAYS operate pressure cleaner in a well-ventilated area. Avoid enclosed

areas such as garages, basements etc.

DPC-2200 USER MANUAL Page 5 of 38

ALWAYS keep exhaust gas from entering a confined area through windows,

doors, ventilation intakes, or other openings.

ALWAYS follow manufacturer’s recommendations, use a respirator or mask

whenever there is a chance that vapours may be inhaled.

If the operating area becomes enclosed, turn off engine and release system

pressure by pulling gun trigger. Immediately leave the affected area.

WARNING

RISK OF FALL HAZARD

Use of pressure cleaner can create puddles and

slippery surfaces.

Kick back from spray gun can cause you to fall.

Keep operating area clear of all persons, pets and obstacles.

DO NOT operate the product when fatigued or under the influence of alcohol

or drugs. Stay alert at all times.

DO NOT operate the machine with missing or broken parts.

NEVER leave wand unattended while unit is running.

Keep children away from pressure cleaner at all times.

DO NOT overreach or stand on an unstable support. If you become unstable

during use, release the trigger and stop engine if necessary. Re-assess

operating area before commencing operation.

The cleaning area should have adequate slopes and drainage to reduce the

possibility of a fall due to slippery surfaces. If the area becomes slippery or

unstable, turn off engine and release system pressure by pulling gun trigger.

Allow the area to drain and assess when suitable to operate again.

Be extremely careful if you must use the pressure cleaner from a ladder,

scaffolding, or any other off ground location.

Firmly grasp spray gun with both hands when using high pressure spray to

avoid injury when spray gun kicks back.

NEVER spray near power source.

DPC-2200 USER MANUAL Page 6 of 38

WARNING

RISK OF FLUID INJECTION

The high-pressure stream of water that this equipment

produces can cut through skin and its underlying

tissues, leading to serious injury and possible

amputation. Spray guns trap high pressure, even

when engine is stopped and water is disconnected,

which can cause injury.

Should the spray penetrate the skin, SEEK MEDICAL

ATTENTION IMMEDIATELY

ALWAYS point spray gun in safe direction and squeeze trigger, to release

high pressure, every time you stop the engine.

NEVER aim spray gun at people, animal, or plants.

NEVER place hands in front of nozzle.

Make sure hose and fittings are tightened and in good condition.

DO NOT allow hose to contact muffler.

NEVER attach or remove wand or hose fittings while system is pressurised.

Use only hose and high-pressure accessories rated for pressure higher than

your pressure cleaner’s psi.

To relieve system pressure, shut off engine, turn off water supply, and pull

gun trigger until water stops flowing.

DO NOT allow children to operate pressure cleaner.

NEVER direct the spray jet at any surface that may contain asbestos material.

DO NOT leave spray gun unattended while machine is running.

NEVER use a spray gun which does not have a trigger lock or trigger guard in

place and in working order.

ALWAYS be certain spray gun, nozzles and accessories are correctly

attached.

ALWAYS wear personal protective clothing such as goggles, ear muffs,

gloves, and closed foot wear.

DPC-2200 USER MANUAL Page 7 of 38

DANGER

RISK OF CHEMICAL BURN

Use of acids, toxic or corrosive chemicals,

poisons, insecticides, or any kind of flammable

solvent with this product could result in serious

injury or death.

Wear protective clothing to protect eyes and skin from contact with sprayed

material.

DANGER

RISK OF HOT SURFACES

Contact with hot surfaces, such as engines

exhaust components, could result in serious burn.

During operation, touch only the control surfaces of the pressure cleaner.

Keep children away from the pressure cleaner at all times. They may not be

able to recognise the hazards of this product.

DANGER

RISK OF MOVING PARTS

Starter and other rotating parts can entangle

hands, hair, clothing, or accessories.

DO NOT wear loose clothing, jewellery or anything that may be caught in the

starter or other rotating parts.

Tie up long hair and remove jewellery.

DANGER

RISK OF EYE INJURY

Spray can splash back or propel objects.

ALWAYS wear safety goggles when using this equipment or in vicinity of

where equipment is in use.

Before starting the pressure cleaner, be sure you are wearing adequate safety

goggles.

NEVER substitute safety glasses for safety goggles.

Table des matières

Autres manuels MAKINEX Nettoyeur haute pression

MAKINEX

MAKINEX DPW-4000-VS Manuel utilisateur

MAKINEX

MAKINEX DPW-4000 Manuel utilisateur

MAKINEX

MAKINEX DPW-2500 Manuel utilisateur

Manuels Nettoyeur haute pression populaires d'autres marques

Shark

Shark RG-232637 Manuel utilisateur

Shakti Technology

Shakti Technology S3 Manuel utilisateur

Kärcher

Kärcher K 4 Pure Manuel utilisateur

Porter-Cable

Porter-Cable D25806-025-2 Manuel utilisateur

REM POWER

REM POWER HDEm 662 Manuel utilisateur

Landa

Landa HS-3000 Manuel utilisateur

Craftsman

Craftsman 580.752270 Manuel utilisateur

HIKOKI

HIKOKI AW 100 Manuel utilisateur

Delco

Delco DC 1302 Manuel utilisateur

Kärcher

Kärcher K 3 Full Control Manuel utilisateur

BIEMMEDUE

BIEMMEDUE 120/10 - 170/13 Manuel utilisateur

ARKSEN

ARKSEN 014-HG-14141-HR Manuel utilisateur

Black & Decker

Black & Decker PW1700SPX Manuel utilisateur

Kärcher

Kärcher 595 - SPARE Mode d’emploi

Kranzle

Kranzle B 10 200 Manuel utilisateur

Stihl

Stihl RE 90 Manuel utilisateur

Husky

Husky HU80911 Manuel utilisateur

PowR-Quip

PowR-Quip PQ-2600 Manuel utilisateur
