MAJORITY BEN NEVIS Manuel
BEN-BAR-BLK
MAJORITY
BEN NEVIS
Audio Soundbar & Subwoofer
Instrucons Guide
Controls And Funcons���������������������������������������������� 1
What’s In The Box?��������������������������������������������������� 6
Instrucons Guide �����������������������������������������������������7
Connecons�������������������������������������������������������������� 8
Oponal: Using a Opcal Input��������������������������������� 9
Bluetooth Operaon������������������������������������������������ 10
AUX-In�����������������������������������������������������������������������11
FM Mode ����������������������������������������������������������������� 12
Troubleshoong ������������������������������������������������������ 13
Warranty ����������������������������������������������������������������� 14
Safety Informaon����������������������������������������������������15
Watch video tutorials and register
your product for a FREE 3-year warranty
at www.majorityradios.co.uk
Contents
3YEAR
WARRANTY
1
Controls And Funcons
Side View / Control Buttons
1. Power
2. Mode
3. Volume +/Next
4. Volume-/previous
5. USB Function
POWER
Mode
VOL +/ NEXT
VOL -/ PREV
USB
LINE IN
2
1
3
4
BEN NEVIS
5
6
2
Sub Woofer
1. Bluetooth Receiver
2. DC adapter input
3. Power Switch
Controls And Funcons
BEN NEVIS
Wireless Bluetooth Surround Bar & Subwoofer
Technical Specications
Bluetooth 2.1 + EDA
Wireless Subwoofer 70w
Power Source: External DC adaptor 12V/1A
ANT
POWER
OFF ON
DC IN 12V
1
2
3
3
Remote Control
1. Power On/O
2. Bluetooth Mode
3. USB/SD Mode
4. Play/Pause
5. Movie Mode
6. Bass Adjustment
7. Mode Select
8. Aux Mode
9. Line in
10. Optical Audio Port
11. FM Radio
12. Previous/Next
13. Voice
14. Adjustment
15. Treble Adjustment
16. Volume Adjustment
Controls And Funcons
MODE
LINE
FM
ADJ.
AUX
OPT
VOICE
USB
SD
MOVIE
BASS TREBLE
BEN NEVIS
VOLUME
17
8
10
13
15
9
11
12
14
16
2
3
4
5
6
4
Remote Control Operation
To use the remote control, point the remote at the remote
sensor on the front panel. You will be able to view any setting
changes via the remote on the front right of the soundbar.
The remote control works within a distance of approximately 8
meters from the sensor and within an angle of 30 degrees from
the left and ride side.
Sound Functions
MOVIE - Recommended setting for lm viewing and for audio
that requires a punchy and bass-like sound
VOICE - Recommended for TV viewing when cinematic sound
experience is not required.
ADJ - Setting to adjust bass and treble sound of the sound bar
and sub-woofer
BASS - Adjust the bass
Treble - Adjust the treble
Controls And Funcons
Remote Control Functions
5
Please Note:
Remove the batteries when you don’t intend to use the remote
control for a long time.
Weak batteries can leak and severely damage the remote
control.
Be environmentally friendly and dispose of batteries according
to government regulations.
Changing the battery
The battery compartment is at the back of the remote.
Pinch the left side of the battery compartment and pull the
compartment towards you to release from the remote.
Insert a Lithium cell CV2025 3V battery within the compartment
and push the compartment back into the remote.
Controls And Funcons
6
What’s In The Box?
1. Ben Nevis Surround Sound Bar
2. Ben Nevis Wireless Subwoofer
3. Remote Control
4. 2 x DC-in Power Cables
5. AUX Line In TV Connection Cable
6. Mounting parts
Box Contents
7
Instrucons Guide
Getting Started
Plug the sound bar and subwoofer into the mains via the power
cables provided. The sound bar will now light up on the front
panel.
Ensure that the subwoofer is also switched to ‘on’ at the back of
the unit.
After a few seconds, the sound bar and the subwoofer will
wirelessly connect to each other.
As the sound bar are now set up, you can now connect them to
the following audio: TV Connection, Bluetooth, AUX-in and FM.
Ensure that the power supply voltage is in the voltage of
100V~240V.
Please note:
This unit is designed to use adapter.
Connecting the unit to any other power source may cause
damage to the unit.
Unwind the mains cable to its full length. Connect the mains
plug to a mains socket. Make sure the mains plug is fully inserted
into the mains socket.
The mains plug/appliance coupler is used as the disconnect
device, the disconnect device must remain readily operable.
Connect the Adapter to the unit and AC Socket.
8
Instrucons Guide
Using the AUX ‘Line In’ Connection
Use the RCA Stereo Audio Cable to connect the TV’s stereo
RCA(L/R).
Connect the audio output socket to the side of the Sound bar via
the ‘LINE IN’ input sockets of the unit.
Once your TV and Ben Nevis are connected, press the AUX
button on the remote control or press the source button on the
unit to choose the AUX function.
Turn on your television set to use the Majority Ben Nevis.
Connections
Wall BracketDC INOptical Input
S. W Out
