PLANNING INSTRUCTIONS

EZG 35/4 B

Version: 2019-05-22 - MAICO VENTILATOREN, www.maico-fans.com - We are not responsible for mistakes or printing errors and retain the

right to make technical modifications without giving prior notice Page 1

Fans for air circulation in greenhouses

Small greenhouse with one fan

You will find the right fan for your greenhouse in the table below. The details apply to greenhouses up to 20 m long and 9 m

wide.

Greenhouse width [m] Greenhouse length [m] Recommended fan

3 10 - 20 EZG 30/4 B

6 10 EZG 30/4 B

6 15 EZG 30/4 B

6 20 EZG 35/4 B

Wider greenhouse with two fans

You will find the right fans for your greenhouse in the table below. The details apply to wide greenhouses up to 20 m long and

9 m wide.

Greenhouse width [m] Greenhouse length [m] Recommended fan

9 20 1 x EZG 40/4 B

12 20 2 x EZG 35/4 B

PLANNING INSTRUCTIONS

EZG 35/4 B

Version: 2019-05-22 - MAICO VENTILATOREN, www.maico-fans.com - We are not responsible for mistakes or printing errors and retain the

right to make technical modifications without giving prior notice Page 2

Long greenhouse with two to three fans

You will find the right fans for your greenhouse in the table below. The details apply to long greenhouses over 20 m long and

up to 9 m wide.

Greenhouse width [m] Greenhouse length [m] Recommended fan

6 25 - 30 2 x EZG 30/4 B

9 25 2 x EZG 35/4 B

9 30 - 40 2 x EZG 30/4 B

Large greenhouse with four fans

You will find the right fans for your greenhouse in the table below. The details apply to large greenhouses over 20 m long and

over 9 m wide.

Greenhouse width [m] Greenhouse length [m] Recommended fan

12 25 4 x EZG 30/4 B

12 30 - 40 4 x EZG 30/4 B

larger larger on request

PLANNING INSTRUCTIONS

EZG 35/4 B

Version: 2019-05-22 - MAICO VENTILATOREN, www.maico-fans.com - We are not responsible for mistakes or printing errors and retain the

right to make technical modifications without giving prior notice Page 3

Fans for forced air extraction in greenhouses

Recommended greenhouse fans

The suitable fan for greenhouses with forced air extraction can be found in the following table. Data given is valid for green-

houses up to 40 m long and 12 m wide.

Greenhouse width [m] Greenhouse length [m] Recommended fan

3 10 1 x EZQ 40/4 B or 2 x EZQ 30/4 B

3 10 - 15 1 x EZQ 50/6 A or 2 x EZQ 50/6 B

3 10 - 20 1 x EZQ 40/4 B or 2 x EZQ 50/8 B

6 10 2 x EZQ 40/4 B or 2 x EZQ 50/8 B

6 15 2 x EZQ 50/6 A or 4 x EZQ 35/4 B

6 20 3 x EZQ 50/6 A or 4 x EZQ 40/4 B

6 25 - 30 4 x EZQ 50/6 A or 5 x EZQ 40/4 B

9 20 4 x EZQ 50/6 A or 5 x EZQ 40/4 B

9 25 5 x EZQ 50/6 B

9 30 - 40 8 x EZQ 50/6 B

12 20 - 25 7 x EZQ 50/6 B

12 30 - 40 11 x EZQ 50/6 B
