OWNER’S MANUAL

0.7 cu. ft. Microwave Oven

MCD775W1

1.READ these instructions carefully before installing and operating the

oven. Keep them for future reference.

2.Record in the space below the SERIAL NO. found on the nameplate on

your oven and retain this information for future reference.

SERIAL NO.:



CONTENTS

CONTENTSCONTENTS

CONTENTS

PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE

MICROWAVE ENERGY………………….…………………………………………….…2

FEDERAL COMMUNICATIONS COMMISSION RADIO FREQUENCY

INTERFERENCE STATEMENT ………………………………………………………...2

IMPORTANT SAFETY INSTRUCTIONS……………….…………………….………...3

GROUNDING INSTRUCTIONS.…………………………….……………………..……4

UTENSILS GUIDE……………………………………………………………….......…...5

COOKING TECHNIQUES………………………………………………………..….. ....7

BEFORE YOU CALL FOR SERVICE……………………….…………………..………8

SPECIFICATIONS…………………………………………….……………………...…...8

PART NAMES… .……………………………………………………………...…..….…..8

CONTROL PANEL……………………………………………………………….….…….9

OPERATION INSTRUCTIONS…………………………………………………..……..10

ABOUT “QUICK COOK” SETTINGS……………………………………...…..………13

CLEANING AND CARE…………………………………………………………...…….15

PRECAUTIONS TO AVOID POSSIBLE EXPOSURE

TO EXCESSIVE MICROWAVE ENERGY

(a) Do not attempt to operate this oven with the door open since open-door

operation can result in harmful exposure to microwave energy. It is

important not to defeat or tamper with the safety interlocks.

(b) Do not place any object between the oven front face and the door or

allow food particle or cleaner residue to accumulate on sealed surfaces.

the oven door close properly and that there is no damage to the

Door (bent),

Hinges and latches (broken or loosened),

Door seals and sealed surfaces.

(d) The oven should not be adjusted or repaired by anyone except properly

qualified service personnel.

FEDERAL COMMUNICATIONS COMMISSION

RADIO FREQUENCY INTERFERENCE

STATEMENT

WARNING :

This equipment generates and uses ISM frequency energy and if not

installed and used properly, that is in strict accordance with the

manufacturer’s instructions, may cause interference to radio and television

reception. It has been type-tested and found to comply with limits for an ISM

Equipment pursuant to part 18 of FCC Rules, which are designed to provide

reasonable protection against such interference in a residential installation.

However, there is no guarantee that interference will not occur in a particular

installation. If this equipment does cause interference to radio or television

reception, which can be determined by turning the equipment off and on, the

user is encouraged to try to correct the interference by one or more of the

followings.

•Reorient the receiving antenna of radio or television.

•Relocate the Microwave oven with respect to the receiver.

•Move the microwave oven away from the receiver.

•Plug the microwave oven into a different outlet so that microwave

oven and receiver are on different branch circuits.

THE MANUFACTURER is not responsible for any radio or TV interference

caused by UNAUTHORIZED MODIFICATION to this microwave oven. It is

the responsibility of the user to correct such interference.

IMPORTANT SAFETY INSTR

IMPORTANT SAFETY INSTRIMPORTANT SAFETY INSTR

IMPORTANT SAFETY INSTRUCTIONS

UCTIONSUCTIONS

UCTIONS

When using electrical appliances, basic

safety precautions should be followed,

including the following:

WARNING - To reduce the risk of burns,

electric shock, fire, injury to persons or

exposure to excessive microwave energy:

1. Read all instructions before using the

appliance.

2. Read and follow the specific

“PRECAUTIONS TO AVOID POSSIBLE

EXPOSURE TO EXCESSIVE MICROWAVE

ENERGY” on page 2.

3. Select a level surface that provides

enough open space for the intake

and/or outlet vents. A minimum

clearance of 3 inches is required

between the oven and any adjacent

wall. One side must be open. Leave a

minimum clearance of 3 inches above

the oven. Do not cover or block any

openings on the appliance. Do not

remove feet from the bottom of the

oven. This

appliance must be

grounded and connected only to

properly grounded outlet. See

“GROUNDING INSTRUCTIONS” on

page 4.

Some products such as whole eggs

and sealed containers, for example,

closed glass jars may explode and

should not be heated in this oven.

Use this appliance only for its intended

use as described in this manual. Do not

use corrosive chemicals or vapors in

this appliance. This type of oven is

specifically designed to heat, cook or

dry food. It is not designed for industrial

or laboratory use.

As with any appliance, close

supervision is necessary when used by

children.

To reduce the risk of fire in the oven

cavity:

a. Do not overcook food. Carefully

attend appliance if paper, plastic or

other combustible materials are

placed inside the oven to facilitate

cooking.

b. Remove wire twist-ties from paper or

plastic bags before placing them in

the oven.

c. If materials inside the oven should

ignite, keep oven door closed, turn

oven off, and disconnect the

power cord or shut off power at

the fuse or circuit breaker panel.

d. Do not use the cavity for storage

purposes. Do not leave paper

products, cooking utensils or food in

the cavity when not in use.

SAVE THESE INSTRUCTIONS

Microwave heating of beverage can

result in delayed eruptive boiling,

therefore care has to be taken when

handling the container.

Do not deep fry food in the microwave.

It is difficult to control the fat which

could cause a fire hazard.

10.

Pierce foods with heavy skins such as

potatoes, whole squash, apples and

chestnuts before cooking.

11.

The contents of feeding bottles and

baby jars should be stirred or shaken

and the temperature should be

checked

before serving in order to avoid burns.

12.

Cooking utensils may become hot

because of heat transferred from the

heated food. Potholders may be

needed to handle the utensil.

13.

Do not cover or block any openings on

the appliance.

14.

Do not store or use this appliance

outdoors. Do not use this product near

water, for example, near a kitchen sink,

in a wet basement, or near a swimming

pool, etc.

15.

Do not operate this appliance if it has a

damaged cord or a plug, if it is not

working properly or if it has been

damaged or dropped.

16.

Do not immerse cord or plug in water.

Keep cord away from heated surface.

Do not let cord hang over edge of table

or counter.

17.

Use only thermometers which are

specifically designed for use in

microwave ovens.

18.

Do not operate any heating or cooking

appliance beneath this appliance.

19.

Be certain the glass tray and roller ring

are in place when you operate the

oven.

20.

WARNING: It is hazardous for anyone

other than a trained person to carry out

any service or repair operation which

involves the removal of any cover which

gives protection against exposure to

microwave energy. If there is any

damage, do not operate the oven and

contact MC Appliance Corp. for service.

GROUNDING INSTRUCTIONS

GROUNDING INSTRUCTIONSGROUNDING INSTRUCTIONS

GROUNDING INSTRUCTIONS

This appliance must be grounded. In the event of an electrical short circuit, grounding

reduces risk of electric shock by providing an escape wire for the electric current.

WARNING: Improper use of the grounding plug can result in a risk of electric shock.

SAVE THESE INSTRUCTIONS

Electrical Requirements

The electrical requirements are a 120 volt 60 Hz, AC only, 15 amp. It is recommended that

a separate circuit serving only the oven be provided. The oven is equipped with a 3-prong

grounding plug. It must be plugged into a wall receptacle that is properly installed and

grounded.

Extension Cord

If it is necessary to use an extension cord, use only a 3-wire extension cord that has a 3

blade grounding plug and a 3-slot receptacle that will accept the plug on the microwave

oven. The marked rating of the extension cord shall be equal to or greater than the

electrical rating of the appliance.

Notes: 1. If you have any questions about the grounding or electrical instructions, consult

a qualified electrician or a service person.

2. Neither MC Appliance Corp nor the dealer can accept any liability for damage to

the oven or personal injury resulting from failure to observe the electrical

connection procedures.

Radio or TV Interference

Should there be any interference caused by the microwave oven to your radio or TV, check

that the microwave oven is on a different circuit, relocated the radio or TV as far away from

the oven as feasible or check position and signal of receiving antenna.

UTENSILS GUIDE

UTENSILS GUIDEUTENSILS GUIDE

UTENSILS GUIDE

This section lists which utensils can be used in the microwave, which ones have limited

use for short periods, and which ones should not be used in the microwave.

Recommended

·Microwave browning dish — Use to brown the exterior of small items such as steaks,

chops, or pancakes. Follow the directions provided with your browning dish.

Microwaveable plastic wrap — Use to retain steam. Leave a small opening for some

steam to escape and avoid placing it directly on the food.

·Paper towels and napkins —Use for a short-term heating and covering; these absorb

excess moisture and prevent spattering. Do not use recycled paper towels, which may

contain metal and could ignite.

SAVE THESE INSTRUCTIONS

·Glass and glass-ceramic bowls and dishes — Use for heating or cooking.

·Paper plates and cups — Use for short-term heating at low temperatures. Do not use

recycled paper, which may contain metal and could ignite.

·Wax paper — Use as a cover to prevent spattering.

·Thermometers — Use only those labeled “Microwave Safe” and follow all directions.

Check the food in several places. Conventional thermometers may be used on

microwave food once the food has been removed from the oven.

Limited Use

Aluminum foil — Use narrow strips of foil to prevent overcooking of exposed areas.

Using too much foil can damage your oven, so be careful. You should keep distance of 1

inch (2.54cm) between aluminum foil and cavity.

·Ceramic, porcelain, and stoneware — Use these if they are labeled “Microwave Safe”.

If they are not labeled, test them to make sure they can be used safely.

·Plastic — Use only if labeled “Microwave Safe”. Other plastics can melt.

·Straw, wicker, and wood — Use only for short-term heating, such as warming dinner

rolls for a few seconds; baskets and bowls may be flammable.

Not Recommended

·Glass jars and bottles — Regular glass is too thin to be used in a microwave. It can

shatter and cause damage and injury.

·Paper bags — These are a fire hazard, except for popcorn bags that are designed for

microwave use.

·Styrofoam plates and cups — These can melt and leave an unhealthy residue on food.

·Plastic storage and food containers — Containers such as margarine tubs can melt in

the microwave.

·Metal utensils — These can damage your oven. Remove all metal before cooking.

Note: Should you wish to check if a dish is safe for microwaving, place the empty dish in

the oven and microwave on HIGH for 30 seconds. A dish which becomes very hot

should not be used.

SAVE THESE INSTRUCTIONS

COOK

COOKCOOK

COOKING TECHNIQUES

ING TECHNIQUESING TECHNIQUES

ING TECHNIQUES

Stirring

Stir foods such as casseroles and

vegetables while cooking to distribute heat

evenly. Food at the outside of the dish

absorbs more energy and heats more

quickly, so stir from the outside to the

center. The oven will turn off when you

open the door to stir your food.

Arrangement

Arrange unevenly shaped foods, such as

chicken pieces or chops, with the thicker,

meatier parts toward the outside of the

turntable where they receive more

microwave energy. To prevent overcooking,

place delicate areas, such as asparagus

tips, toward the center of the turntable.

Shielding

Shield food with narrow strips of aluminum

foil to prevent overcooking. Areas that

need shielding include poultry wing-tips,

the ends of poultry legs, and corners of

square baking dishes. Use only small

amounts of aluminum foil. Larger amounts

can damage your oven.

Turning

Turn foods over midway through cooking

to expose all parts to microwave energy.

This is especially important with large

foods such as roasts.

Standing

Foods cooked in the microwave build up

internal heat and continue to cook for a few

minutes after heating stops. Let foods

stand to complete cooking, especially

foods such as cakes and whole vegetables.

Roasts need this time to complete cooking

in the center without overcooking the outer

areas. All liquids, such as soup or hot

chocolate, should be shaken or stirred

when cooking is complete. Let liquids

stand a moment before serving. When

heating baby food, stir well at removal and

test the temperature before serving.

Adding moisture

Microwave energy is attracted to water

molecules. Food that is uneven in moisture

content should be covered or allowed to

stand so that the heat disperse evenly. Add

a small amount of water to dry food to help

it cook.

SAVE THESE INSTRUCTIONS

BEFORE YOU CALL FOR SER ICE

BEFORE YOU CALL FOR SER ICEBEFORE YOU CALL FOR SER ICE

BEFORE YOU CALL FOR SER ICE

If the oven fails to operate:

A) Check to ensure that the oven is

plugged in securely. If it is not, remove the

plug from the outlet, wait 10 seconds and

plug it in again securely.

B) Check for a blown circuit fuse or a

tripped main circuit breaker. If these

seem to be operating properly, test the

outlet with another appliance.

C) Check to ensure that the control panel

is programmed correctly and the timer

is set.

D) Check to ensure that the door is

securely closed engaging the door

safety lock system. Otherwise, the

microwave energy will not flow into

the oven.

IF NONE OF THE ABOVE RECTIFY THE SITUATION, THEN CONTACT MC APPLIANCE

CORPORATION TO OBTAIN SERVICE.

DO NOT TRY TO ADJUST OR REPAIR THE OVEN YOURSELF.

SPECIFICATIONS

SPECIFICATIONSSPECIFICATIONS

SPECIFICATIONS

Power Consumption:

Output:

Operation Frequency:

Unit Dimensions(H×W×D):

Oven Capacity:

Net Weight:

120V~60Hz, 1050W

700W

2450MHz

10 5/16×17 13/16×14 5/16 in.

0.7 cu.ft.

Approx. 23.8 lbs.

PART NAMES

PART NAMESPART NAMES

PART NAMES

Door Safety Lock System

Oven Window

Wave Guide

Turntable roller

Glass Tray

Control Panel

Door Release Button

CONTROL PANEL

CONTROL PANELCONTROL PANEL

CONTROL PANEL

(Also see following pages for more detail.)

DISPLAY

Cooking time, power, indicators and

present time are displayed.

BAKED POTATO/POPCORN

PIZZA/BEVERAGE

FROZEN DINNER/REHEAT

Allows you to reheat or cook food

automatically without entering power level

or time.

POWER

Use to set power level. To check power

level during time cooking, touch POWER

pad.

TIMER

Timer functions independently, even while

a cooking program is in process.

COOK

Use for multi-stage cooking. Enables

cooking at multiple power and time

settings automatically.

COOK BY WEIGHT

Touch to enter weight of meat accurately.

The oven automatically sets the cooking

time and power level.

DEFROST BY WEIGHT

Touch to set the weight of the food to be

defrosted; the oven automatically sets the

defrosting time and power level.

DEFROST BY TIME

Touch to set defrosting time; the oven

automatically divides the defrosting time

into periods of alternating defrost and

stand times by cycling on and off.

Table des matières

Autres manuels Magic Chef Four à micro-ondes

Magic Chef

Magic Chef MCD790W Manuel d'utilisation et d'entretien

Magic Chef

Magic Chef MCM990W Manuel utilisateur

Magic Chef

Magic Chef MCD1611ST Manuel utilisateur

Magic Chef

Magic Chef HMM990W Manuel utilisateur

Magic Chef

Magic Chef MCD991R Manuel utilisateur

Magic Chef

Magic Chef KOT-172S Manuel utilisateur

Magic Chef

Magic Chef MCD770CW Manuel utilisateur

Magic Chef

Magic Chef MCD992R Instructions de montage

Magic Chef

Magic Chef D760W Manuel d'utilisation et d'entretien

Magic Chef

Magic Chef MCM991RSL Manuel utilisateur

Magic Chef

Magic Chef MCO160S Manuel utilisateur

Magic Chef

Magic Chef MCD1110ST Manuel d'utilisation et d'entretien

Magic Chef

Magic Chef MCD991ARB Manuel utilisateur

Magic Chef

Magic Chef MCM7950SW Manuel utilisateur

Magic Chef

Magic Chef D1311 Manuel d'utilisation et d'entretien

Magic Chef

Magic Chef MCM991B Manuel utilisateur

Magic Chef

Magic Chef MCD1811ST Manuel utilisateur

Magic Chef

Magic Chef MCM1310ST Manuel utilisateur

Magic Chef

Magic Chef MCM1310SB Manuel utilisateur

Magic Chef

Magic Chef MCD1310ST Manuel utilisateur

Magic Chef

Magic Chef MCD770ST1 Manuel utilisateur

Magic Chef

Magic Chef MC110AMST Manuel utilisateur

Magic Chef

Magic Chef MCD1311W Manuel d'utilisation et d'entretien

Magic Chef

Magic Chef MCM1110WF/BF Manuel utilisateur

Manuels Four à micro-ondes populaires d'autres marques

Daewoo

Daewoo KOG-574R0S Manuel utilisateur

LG MH7040SS Manuel utilisateur

Sharp

Sharp R-895(AL)M Manuel utilisateur

Dometic

Dometic DOTRM13W Manuel utilisateur

Sanyo

Sanyo EM-X680 Manuel utilisateur

Sharp

Sharp R-393M Manuel utilisateur

KitchenAid

KitchenAid KMCX4510 Instructions d'installation

Smeg

Smeg S45MCX1 Manuel utilisateur

Russell Hobbs

Russell Hobbs RHM2044 Manuel utilisateur

Sunbeam

Sunbeam SMW759 Manuel utilisateur

Gallet

Gallet FMOE230S Manuel utilisateur

Bosch

Bosch CEG732X.1B Manuel utilisateur

Dometic

Dometic Roadmate 230 Manuel utilisateur

Samsung

Samsung SJ0396W Manuel utilisateur

Sanyo

Sanyo EM-P494WS Manuel utilisateur

Sharp

Sharp R-240 Manuel utilisateur

Electrolux

Electrolux EMS2840 Manuel utilisateur

Daewoo

Daewoo KOC-984T2S13 Manuel utilisateur
