Maestro MR068 Manuel utilisateur
Модель/Model: MR068
Сerticated in Ukraine
Виріб сертифіковано в Україні
091
Owners manual. Electric kettle
Bedienungsanleitung. Wasserkocher
Instrukcji obsługi. Сzajnik elektryczny
Manualul proprietarului. Ceainic electric
Руководство по эксплуатации. Электрический чайник
Керівництво з експлуатації. Електричний чайник
EN
DE
PL
UA
RU
RO
2
Pictures/ Bilder/Rysunki/ Figuri/ Рисунки/ Малюнки 1
B
D
C
E
F
А
Description of the appliance___________________________________________4
Gerät_______________________________________________________________11
Konstrukcja urządzenia_______________________________________________22
Structura produsului____________________________________________________31
Устройство прибора____________________________________________________40
Склад приладу________________________________________________________49
EN
DE
PL
UA
RU
RO
3
Dear customer, we thank you for purchase of goods
Functionality, design and conformity to the quality standards
guarantee to you reliability and convenience in use of this device.
Please read and comply with these original instructions prior to the
initial operation of your appliance and store them for later use of
subsequent owners.
The kettle is designed only for warming and boiling water
for home use.
Under condition of observance of user regulations and a special-
purpose designation, a parts of appliance do not contain unhealthy
substances.
Technical specications
Model: MR068
Capacity: 1,5 L
Electrical supply:
Alternating current- AC;
Rated voltage 220-240V;
Rated frequency 50Hz;
Power consumption 1200W
Protective class I
Protection class IPX0
EN
4
Description of the appliance
Picture1 (page 2)
A- Cover;
В- Handle for cover opening;
C- Switch button with indicator light;
Position «0» - OFF
Position «I» - ON
D- Handle;
E- Kettle case;
F- Base.
Safety instructions
When using your appliance, basic safety precautions should
always be followed,
including the following:
SPECIAL INSTRUCTIONS
ATTENTION!
- Do not allow the ingress of water and moisture on the support and
internal electric parts of the device located outside the container for
water.
- Always remove the kettle from the support to ll it with water or to
clean.
- Do not touch the water in the kettle when it is on the support.
Failure to observe these rules may result in electric shock!
Only plug the appliance into an outlet with an earthed (ground)
contact.
- DO NOT let children or untrained persons use the appliance
without supervision.
- DO NOT leave the appliance unnecessarily plugged in.
5
Disconnect the plug from the mains when the appliance is
not being used.
- DO NOT use the power cord or the appliance in order to pull the
plug out of the socket.
- DO NOT leave the appliance exposed to the weather (rain, sun,
etc. ).
- DO NOT leave the appliance without supervision when it is
connected to the power supply.
- Close supervision is necessary when the appliance is used near
children.
- Always use the appliance on a dry, level surface.
- Do not put on and take off the kettle from the support when it is
switched on. First, turn it off with a switch.
- Always unplug from the plug socket when not in use and before
cleaning.
- Do not operate the appliance if damaged, after an appliance
malfunctions or it has been damaged in any manner, return to at
authorized service engineer for repair.
- In the interest of safety, regular periodic close checks should be
carried out on the supply cord to ensure no damage is evident.
Should there be any signs that the cord is damaged in the slightest
degree, the entire appliance should be returned be authorized
service engineer.
- Do not let the cord hang over the edge of a table or counter or
touch hot surfaces. Allow unit to cool before storage.
- Do not touch any hot surfaces, do not store or cover the appliance
until it has full cooled down.
- Do not use harsh abrasives, caustic cleaners or oven cleaners
when cleaning this appliance.
- This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities, or
EN
6
lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a
person responsible for their safety.
- Children should be supervised to ensure that they do not play with
the appliance.
- Do not leave the kettle switched on if the temperature in the room
may fall below zero. When the temperature is below zero, the
thermostat of the device may spontaneously turn on and switch on
the device.
ATTENTION!
- The surface of the device becomes very hot during operation.
Be careful because you may burn yourself greatly by touching the
surfaces of the cover, case, water of vapor.
- Do not open the cover of the kettle during boiling.
- Do not lift the kettle by its cover.
- Take and lift the kettle only keeping it for the handle, touch only the
buttons of the device.
- Do not ll the kettle with the water level higher than the mark
«MAX».
- Place the kettle only on a dry, stable, even, slip-resistant surface.
- Lift the kettle full with hot water with special care!
In case of failure to observe the above mentioned rules there
arises the danger of burning!
- To avoid possible damages by vapor turn the kettle nose away
from walls and furniture when it is boiling. Use the support to save
the sensitive cover of furniture from damages.
- Do not place the kettle and its support on heating devices.
- Do not close the opening for the exit of vapor near the switch.
- Do not use the kettle without a cover.
7
- Do not switch the kettle on without water or when the water
level is below the mark «MIN». If the kettle is empty or there
is not enough water in it, it is automatically turned off by safety
device. In such case, disconnect the device from the mains, let it
cool down and then ll it with water again and turn it on; the kettle
will begin to boil water and after the end of this process it will turn
off in the regular regime.
- THIS APPLIANCE IS FOR HOUSEHOLD USE ONLY. DO NOT
USE THE APPLIANCE FOR ANYTHING OTHER THAN INTENDED
USE.
Purchase industrial devices for commercial use.
Actions in extreme situations:
- If a device tumbled into water, immediately, unplug the device, not
touching to the device or water.
- In case of appearance from appliance of smoke, sparkling, strong
smell of a burn isolation, immediately stop use the device, unplug
the device, appeal to the nearest service center.
Operation
Before the rst use:
- Remove packing and advertising materials and stickers.
- Inspect the kettle and make sure that there are no damages to the
kettle, power line cord, plug and support.
- Unwind the power line cord completely.
- Place the support on a dry, even, stable surface.
CAUTION! Is required on surfaces where heat may cause a
problem – an insulated heat pad is recommended.
- Connect the plug to the mains.
- Remove the kettle from the support.
- Open the cover, ll the kettle with cold water up to the mark
EN
8
«MAX» (the water level scale with «MIN» and «MAX» marks is
inside). Close the cover.
- Place the kettle on the support.
- Turn the switch (C/ Fig.1) to the position «I». The indicator will
light signaling that the device has turned on, and the kettle shall
begin warming the water.
- When the water begins to boil, the switch will be turned to
the position «О» (off), the light will fade and the kettle will be
automatically turned off.
- You must pour out the rst portion of water and repeat the boiling
procedure again.
- Now the kettle is ready for use.
ATTENTION! Do not ll the kettle with cold water until cools down;
let it get cool before lling with cold water.
Failure to observe this rule may result in the damage to the
ceramic case.
Further boil water as specied above.
The level of water in the kettle must be somewhere between the
marks «MIN» and «MAX».
The process of warming the water can be interrupted at any
moment by pressing on the switch.
ATTENTION! If your kettle switches off before the water begins to
boil, you should clean it of scale (see cleaning and maintenance).
The kettle can continue operation if its cover is open.
Cleaning and maintenance
Regular cleaning improves the performance of the device.
The quantity and the speed of forming the scale, and consequently,
the necessity of cleaning depend on the water hardness in your
region and the intensity of the device usage. All over fur of scale in
9
your kettle is not allowed!
It is recommended to clean the kettle at least 2 times a year
but however until the appearance of all over scale.
ATTENTION!
- Never clean a kettle connected to mains.
- Before cleaning, disconnect the kettle and let it cool down.
- Do not use abrasive and aggressive detergents.
- Never submerge the kettle, its support, power line cord and plug in
water or other liquids.
Cleaning the kettle from scale
Clean the kettle from scale with special agents sold in the open
market. Cleaning from scale can be also performed by the methods
described below:
METHOD 1
- Fill the kettle to maximal level with a mixture consisting of 1 part
of usual vinegar and 2 parts of water. Switch on the kettle and let is
boil and automatically switch off.
- Let the mixture settle during 10-12 hours and pour it out.
- Fill the kettle with fresh water up to maximal level and boil it again.
Pour out this water too to remove the smell of vinegar.
-Wash the internal part of the device with clean water, wipe it and
dry the kettle.
METHOD 2
- Fill the kettle with the above mentioned mixture of water and
vinegar and boil it 2 or 3 times running. Rinse it with water and rub
it dry.
- For usual cleaning wipe the kettle case from the inside and outside
EN
10
with a soft wet sponge or cloth. Soapy water can be used.
- Rinse the kettle and wipe it dry.
- Let the device get fully dry before using.
- Any other kinds of maintenance should be performed by qualied
personnel in a servicing center.
Storage
- Switch off the kettle and let it completely cool before storage.
- Wipe and dry the kettle before storage.
- Do not wind the power line cord around the kettle until it is
completely cooled down.
- Store the kettle in a cool, dry and clean place beyond the assess
of children and people with limited physical and mental abilities.
Environmental protection
Old appliances contain valuable materials that can be recycled.
Please arrange for the proper recycling of old appliances. Please
dispose your old appliances using appropriate collection systems.
Subject to technical modications!
Ce manuel convient aux modèles suivants
1
Table des matières
Langues :
Autres manuels Maestro Bouilloire
Maestro
Maestro MR062 Manuel utilisateur
Maestro
Maestro MR056 Manuel utilisateur
Maestro
Maestro MR012 Manuel utilisateur
Maestro
Maestro MR071 Manuel utilisateur
Maestro
Maestro MR058 Manuel utilisateur
Maestro
Maestro MR027 Manuel utilisateur
Maestro
Maestro MR-076 Manuel utilisateur
Maestro
Maestro MR-049 Manuel utilisateur
Maestro
Maestro MR-061-BLACK Manuel utilisateur
Maestro
Maestro MR072 Manuel utilisateur
Maestro
Maestro MR032 Manuel utilisateur
Maestro
Maestro MR-036 Manuel utilisateur
Maestro
Maestro MR035 Manuel utilisateur
Maestro
Maestro MR037 Manuel utilisateur
Maestro
Maestro MR031 Manuel utilisateur
Maestro
Maestro MR059 Manuel utilisateur
Maestro
Maestro MR066 Manuel utilisateur
Maestro
Maestro MR013 Manuel utilisateur
Maestro
Maestro MR-030 Manuel utilisateur
Maestro
Maestro MR-039 Manuel utilisateur
