Maestro MR-039 Manuel utilisateur
Модель/Model: MR-039
Сerticated in Ukraine
Виріб сертифіковано в Україні
091
Owners manual. Electric kettle
Bedienungsanleitung. Wasserkocher
Instrukcji obsługi. Сzajnik elektryczny
Manualul proprietarului. Ceainic electric
Руководство по эксплуатации. Электрический чайник
Керівництво з експлуатації. Електричний чайник
EN
DE
PL
UA
RU
RO
2
Pictures/ Bilder/Rysunki/ Figuri/ Рисунки/ Малюнки 1
G
B
D
E
F
C
А
Description of the appliance___________________________________________4
Gerät_______________________________________________________________14
Konstrukcja urządzenia_______________________________________________26
Structura produsului____________________________________________________37
Устройство прибора____________________________________________________48
Склад приладу________________________________________________________59
EN
DE
PL
UA
RU
RO
3
Dear customer, we thank you for purchase of goods
Functionality, design and conformity to the quality standards
guarantee to you reliability and convenience in use of this device.
Please read and comply with these original instructions prior to the
initial operation of your appliance and store them for later use of
subsequent owners.
The kettle is designed only for warming and boiling water
for home use.
Under condition of observance of user regulations and a special-
purpose designation, a parts of appliance do not contain unhealthy
substances.
Technical specications
Model: MR-039
Capacity: 1,7 L
Electrical supply:
Alternating current- AC;
Rated voltage 220-240V;
Rated frequency 50Hz;
Power consumption 1850-2200 W
Protective class I
Protection class IPX0
EN
4
Description of the appliance
Picture1 (page 2)
A- Cover
В- Button for cover opening
С- Control Panel
D- Handle
E- Kettle case
F- Base
G- Scale of water level
Safety instructions
When using your appliance, basic safety precautions should
always be followed, including the following:
SPECIAL INSTRUCTIONS
ATTENTION!
- Do not allow the ingress of water and moisture on the support and
internal electric parts of the device located outside the container for
water.
- Always remove the kettle from the support to ll it with water or to
clean.
- Do not touch the water in the kettle when it is on the support.
- Only plug the appliance into an outlet with an earthed (ground)
contact.
Failure to observe these rules may result in electric shock!
Only plug the appliance into an outlet with an earthed (ground)
contact.
- DO NOT let children or untrained persons use the appliance
without supervision.
5
- DO NOT leave the appliance unnecessarily plugged in.
Disconnect the plug from the mains when the appliance is
not being used.
- DO NOT use the power cord or the appliance in order to pull the
plug out of the socket.
- DO NOT leave the appliance exposed to the weather (rain, sun,
etc. ).
- DO NOT leave the appliance without supervision when it is
connected to the power supply.
- Close supervision is necessary when the appliance is used near
children.
- Always use the appliance on a dry, level surface.
- Do not put on and take o the kettle from the support when it is
switched on. First, turn it o with a switch.
- Always unplug from the plug socket when not in use and before
cleaning.
- Do not operate the appliance if damaged, after an appliance
malfunctions or it has been damaged in any manner, return to at
authorized service engineer for repair.
- In the interest of safety, regular periodic close checks should be
carried out on the supply cord to ensure no damage is evident.
Should there be any signs that the cord is damaged in the slightest
degree, the entire appliance should be returned be authorized
service engineer.
- Do not let the cord hang over the edge of a table or counter or
touch hot surfaces. Allow unit to cool before storage.
- Do not touch any hot surfaces, do not store or cover the appliance
until it has full cooled down.
- Do not use harsh abrasives, caustic cleaners or oven cleaners
when cleaning this appliance.
- This appliance is not intended for use by persons (including
EN
6
children) with reduced physical, sensory or mental capabilities, or
lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a
person responsible for their safety.
- Children should be supervised to ensure that they do not play with
the appliance.
- Do not leave the kettle switched on if the temperature in the room
may fall below zero. When the temperature is below zero, the
thermostat of the device may spontaneously turn on and switch on
the device.
ATTENTION!
- The surface of the device becomes very hot during operation.
Be careful because you may burn yourself greatly by touching the
surfaces of the cover, case, water of vapor.
- Do not open the cover of the kettle during boiling.
- Do not lift the kettle by its cover.
- Take and lift the kettle only keeping it for the handle, touch only the
buttons of the device.
- Do not ll the kettle with the water level higher than the mark
«MAX».
- Place the kettle only on a dry, stable, even, slip-resistant surface.
- Lift the kettle full with hot water with special care!
In case of failure to observe the above mentioned rules there
arises the danger of burning!
- To avoid possible damages by vapor turn the kettle nose away
from walls and furniture when it is boiling. Use the support to save
the sensitive cover of furniture from damages.
- Do not place the kettle and its support on heating devices.
- Do not close the opening for the exit of vapor near the switch.
- Do not use the kettle without a cover.
7
- Do not switch the kettle on without water or when the water
level is below the mark «MIN». If the kettle is empty or there
is not enough water in it, it is automatically turned o by safety
device. In such case, disconnect the device from the mains, let it
cool down and then ll it with water again and turn it on; the kettle
will begin to boil water and after the end of this process it will turn
o in the regular regime.
- THIS APPLIANCE IS FOR HOUSEHOLD USE ONLY. DO NOT
USE THE APPLIANCE FOR ANYTHING OTHER THAN INTENDED
USE.
Purchase industrial devices for commercial use.
Actions in extreme situations:
- If a device tumbled into water, immediately, unplug the device, not
touching to the device or water.
- In case of appearance from appliance of smoke, sparkling, strong
smell of a burn isolation, immediately stop use the device, unplug
the device, appeal to the nearest service center.
Control Panel
EN
8
1. Temperature Icon
2. White (tea)
3. Green (tea)
4. Oolong (Tea)
5. Boil button
6. Temperature Increase/Decrease button
7. Keep warm
8. Power
Operation Instruction
Please check whether your socketand power is suitable for this
product before use
Do not exceed the maximum line of the mark(1700ml)
It is suggested to boil twice to clean the inner pot when rst use
1. Place the the kettle on a horizontal surface for use.
2. Openthe lid and pour water into the kettle.
3. Connect with power, enter the setting interface, and press the
button for boiling water (you can select the setting temperature you
need under the setting interface).
4. Take o the kettle for brewing.
Basic Operation:
1. Temperature Icon: Show the real-time and setting temperature.
2. White: Under setting interface, Press shortly ,enter the
mode of white tea and relevant temperatuure 70 °C.
3. Green: Under setting interface, Press shortly ,enter the
mode of Green tea and relevant temperatuure 80°C.
9
4. Oolong: Under setting interface, Press shortly
,enter the mode of Oolong tea and relevant temperatuure 90°C.
5. Boil button: Under Setting interface , press shortly.
And the buzzer sound “DI”, and the temperature show 100°C , the
three buttons all light on.
The temperature icon show the current real time temperature and
enter boiling status . After boiled, The buzzer sounds”DI DI”.
These two buttons
lights o , and the
temperature show will be o after 30 seconds.
The power button switch to breath light .
6. Temperature Increse/Decrease button: Single press
setting from 40-100°C in every 5°C as level.
7. Keep Warm Key: Under setting interface, press the
key once and the buzzer will sound «di» light in twinkle
status.
At the same time, after selecting the required setting temperature
by pressing the increase/decrease button or directly selecting the
white tea, green tea and oolong tea button on the setting interface,
it will automatically enter the keep warm state. The keep warm time
is 2 hours. When the water temperature is lower than the set value
of about 5 degrees, the heat will be resumed until 2 hours. (On
the setting interface, press the WARM button by mistake without
EN
10
performing any other operation, and the system returns to the
setting interface in 3 seconds later.)
8. Power button: in the power state, the power button indicator
will light up. If there is no operation within 1 minute, the kettle will
automatically enter the standby state, and the power button light will
be changed into the breathing light (in the standby state, only press
the power button is eective, other keys are invalid, and enter the
setting state; To switch function, you need to press the power button
again to switch to the setting interface; Under the setting interface,
press it for 5 seconds and the kettle will enter the standby state)
9. In the state of keep warm, after boiling water to the set
temperature, the function of memory starts. Within ten times of
kettle lifting, the water temperature of the kettle should not be less
than 8 degrees below the set value for each time, and the memory
is eective, that is, the keep warm continues to work and the time
of keep warm continues to the last time. Otherwise exit the keep
warm.
Cleaning and maintenance
Regular cleaning improves the performance of the device.
The quantity and the speed of forming the scale, and consequently,
the necessity of cleaning depend on the water hardness in your
region and the intensity of the device usage. All over fur of scale in
your kettle is not allowed!
It is recommended to clean the kettle at least 2 times a year but
however until the appearance of all over scale.
ATTENTION!
- Never clean a kettle connected to mains.
- Before cleaning, disconnect the kettle and let it cool down.
Table des matières
Langues :
Autres manuels Maestro Bouilloire
Maestro
Maestro MR-076 Manuel utilisateur
Maestro
Maestro MR041 Manuel utilisateur
Maestro
Maestro MR063 Manuel utilisateur
Maestro
Maestro MR071 Manuel utilisateur
Maestro
Maestro MR072 Manuel utilisateur
Maestro
Maestro MR070 Manuel utilisateur
Maestro
Maestro MR010 Manuel utilisateur
Maestro
Maestro MR037 Manuel utilisateur
Maestro
Maestro MR042 Manuel utilisateur
Maestro
Maestro MR011 Manuel utilisateur
Maestro
Maestro MR040 Manuel utilisateur
Maestro
Maestro MR068 Manuel utilisateur
Maestro
Maestro MR047 Manuel utilisateur
Maestro
Maestro MR067 Manuel utilisateur
Maestro
Maestro MR-061-BLACK Manuel utilisateur
Maestro
Maestro MR-036 Manuel utilisateur
Maestro
Maestro MR069 Manuel utilisateur
Maestro
Maestro MR054 Manuel utilisateur
Maestro
Maestro MR-075 Manuel utilisateur
Maestro
Maestro MR-073 Manuel utilisateur
