S512 / S515

S525 / S518S

S500 Series

Passive Loudspeakers

S518S SUBWOOFER FEATURES:

■Class-leading power handling

 •900W program / 1800W peak at 8

■18" high-output woofer

■Rugged, professional wood enclosure with

high-durability, textured paint

■Integrated low-pass ﬁlter focuses power to low

frequencies for maximum punch

■NL4 and 1/4" input and thru connections for

connecting multiple units on a single amp channel

■Pole receptacle for mounting full-range loudspeaker

S500 Series Passive

Loudspeakers

S500 Series Passive Loudspeakers are the perfect voice

for your passive system, with proven performance that is

as professional as it is affordable. They feature high-output

transducers that sound great and the full-range boxes

deliver ultra-wide 90˚ x 50˚ dispersion.

Road ready, the rugged, PVC vinyl-covered wood

enclosures also include protective edge bumpers,

keeping your investment safe during transport.

S500 speakers are the perfect complement to Mackie’s

PPM Series Powered Mixers. Or integrate them with

Mackie FRS Series Power Ampliﬁers and an SP260

Speaker Processor for a completely optimized passive

system with the ﬂexibility and performance you need.

Four models available:

S512 – 12" 2-way loudspeaker

S515 – 15" 2-way loudspeaker

S525 – Dual 15" 2-way loudspeaker

S518S – 18" subwoofer

S500 FULL-RANGE MODELS FEATURES:

■Class-leading power handling for professional shows

 •S512 – 500W program / 1000W peak at 8

 •S515 – 600W program / 1200W peak at 8

 •S525 – 1200W program / 2400W peak at 8

■Precision, high-output transducers:

 •S512 – 12" woofer / 1" HF driver

 •S515 – 15" woofer / 1" HF driver

 •S525 – Dual 15" woofers / 1" HF driver

■Rugged, professional PVC vinyl covered wood

enclosures with protective edge bumpers

■Wide-dispersion 90˚ x 50˚ high-frequency horn

for maximum audience coverage

■HF protection circuitry reduces high-frequency

output to protect against driver damage

■NL4 and 1/4" input and thru connections for

connecting multiple units on a single amp channel

■Stand / Pole-mountable [S512 and S515]

2/6 PAGES

S512 / S515

S525 / S518S

S500 Series

Passive Loudspeakers

S512 TECHNICAL SPECIFICATIONS

System

Type: Two-way, full-range loudspeaker

Frequency Range (-10 dB): 49 Hz - 18 kHz

Horizontal Coverage Angle: 90˚

Vertical Coverage Angle: 50˚

Sensitivity (1W @ 1m): 99.9 dB SPL

Nominal Impedance: 8

Power Handling: 250 watts continuous

500 watts program

1000 watts peak

Crossover Frequency: 3600 Hz

Transducers

Low Frequency: 12" / 305 mm woofer, vented

High Frequency: 1" / 25 mm tweeter

Physical

Input Connectors: Two 1/4" TS jacks

Two NL4 jacks, paralleled

Enclosure: Wood with textured black

PVC vinyl covering

Mounting: Pole-mountable

Physical Properties (packaged product)

Height: 27.0 in / 686 mm

Width: 18.0 in / 457 mm

Depth: 20.0 in / 508 mm

Weight: 53 lb / 24 kg

Physical Properties (product)

Height: 25.6 in / 650 mm

Width (Front): 17.8 in / 452 mm

Width (Rear): 13.8 in / 351 mm

Depth: 15.6 in / 396 mm

Weight: 49 lb / 22 kg

Ordering Information

S512 12" 2-Way Passive SR Loudspeaker:

P/N 2038505-00

S515 TECHNICAL SPECIFICATIONS

System

Type: Two-way, full-range loudspeaker

Frequency Range (-10 dB): 47 Hz - 18 kHz

Horizontal Coverage Angle: 90˚

Vertical Coverage Angle: 50˚

Sensitivity (1W @ 1m): 101.1 dB SPL

Nominal Impedance: 8

Power Handling: 300 watts continuous

600 watts program

1200 watts peak

Crossover Frequency: 3400 Hz

Transducers

Low Frequency: 15" / 381 mm woofer, vented

High Frequency: 1" / 25 mm tweeter

Physical

Input Connectors: Two 1/4" TS jacks

Two NL4 jacks, paralleled

Enclosure: Wood with textured black

PVC vinyl covering

Mounting: Pole-mountable

Physical Properties (packaged product)

Height: 29.8 in / 757 mm

Width: 18.0 in / 457 mm

Depth: 20.3 in / 516 mm

Weight: 55 lb / 24.9 kg

Physical Properties (product)

Height: 28.1 in / 714 mm

Width (Front): 17.8 in / 452 mm

Width (Rear): 13.8 in / 351 mm

Depth: 15.6 in / 396 mm

Weight: 51 lb / 23 kg

Ordering Information

S515 15" 2-Way Passive SR Loudspeaker:

P/N 2038507-00

3/6 PAGES

S512 / S515

S525 / S518S

S500 Series

Passive Loudspeakers

S525 TECHNICAL SPECIFICATIONS

System

Type: Two-way, full-range loudspeaker

Frequency Range (-10 dB): 51 Hz - 18 kHz

Horizontal Coverage Angle: 90˚

Vertical Coverage Angle: 50˚

Sensitivity (1W @ 1m): 102.9 dB SPL

Nominal Impedance: 8

Power Handling: 600 watts continuous

1200 watts program

2400 watts peak

Crossover Frequency: 2800 Hz

Transducers

Low Frequency: Two 15" / 381 mm woofers, vented

High Frequency: 1" / 25 mm tweeter

Physical

Input Connectors: Two 1/4" TS jacks

Two NL4 jacks, paralleled

Enclosure: Wood with textured black

PVC vinyl covering

Physical Properties (packaged product)

Height: 45.0 in / 1143 mm

Width: 18.0 in / 457 mm

Depth: 19.0 in / 483 mm

Weight: 79 lb / 35.8 kg

Physical Properties (product)

Height: 43.9 in / 1115 mm

Width (Front): 16.8 in / 427 mm

Width (Rear): 13.3 in / 338 mm

Depth: 15.6 in / 396 mm

Weight: 75 lb / 34 kg

Ordering Information

S525 Dual 15" 2-Way Passive SR Loudspeaker:

P/N 2038509-00

S518S TECHNICAL SPECIFICATIONS

System

Type: Subwoofer

Frequency Range (-10 dB): 37 Hz - 220 Hz

Sensitivity (1W @ 1m): 98.3 dB SPL

Nominal Impedance: 8

Power Handling: 450 watts continuous

900 watts program

1800 watts peak

Internal Low Pass Filter: 120 Hz, 12 dB/octave

Transducers

Low Frequency: 18" / 457 mm woofer, vented

Physical

Input Connectors: Two 1/4" TS jacks

Two NL4 jacks, paralleled

Enclosure: Wood with durable black paint

Mounting: Pole-mount on top

Physical Properties (packaged product)

Height: 25.0 in / 635 mm

Width: 23.0 in / 584 mm

Depth: 23.0 in / 584 mm

Weight: 74 lb / 33.6 kg

Physical Properties (product)

Height: 23.9 in / 607 mm

Width (Front): 20.3 in / 516 mm

Width (Rear): 15.5 in / 394 mm

Depth: 21.3 in / 541 mm

Weight: 70 lb / 32 kg

Ordering Information

S518S 18" Passive SR Subwoofer:

P/N 2038511-00

4/6 PAGES

S512 / S515

S525 / S518S

S500 Series

Passive Loudspeakers

THE INFORMATION CONTAINED

HEREIN IS PROPRIETARY AND

CONFIDENTIAL PROPERTY OF

LOUD TECHNOLOGIES, INC.

UNLESS OTHERWISE SPECIFIED:

ALL DIMENSIONS ARE IN INCHES

DUAL [MM] DIMENSIONS

FOR REF ONLY

TOLERANCE IN INCHES

LINEAR ± 0.13 in / ± 3.3 mm

ANGLES ± 1°

(X.XX) = REF DIMS

NO TOLERANCE IMPLIED

TSC = THEORETICAL SHARP CORNER

DIMENSIONS ACROSS CENTERLINES

TO BE SYMMETRICAL

THIRD ANGLE PROJECTION

S512 NOTES:

1. WEIGHT APPROX. 49 lb [22 kg].

2. SHIPPING WEIGHT APPROX. 53 lb [24 kg].

S515 NOTES:

1. WEIGHT APPROX. 51 lb [23 kg].

2. SHIPPING WEIGHT APPROX. 55 lb [24.9 kg].

25.6

[650]

13.8

[351]

17.8

[452]

28.1

[714]

15.6

[396]

13.8

[351]

17.8

[452]

15.6

[396]

S512 DIMENSIONS

S515 DIMENSIONS

5/6 PAGES

S512 / S515

S525 / S518S

S500 Series

Passive Loudspeakers

S525 NOTES:

1. WEIGHT APPROX. 75 lb [34 kg].

2. SHIPPING WEIGHT APPROX. 79 lb [35.8 kg].

S515 NOTES:

1. WEIGHT APPROX. 70 lb [32 kg].

2. SHIPPING WEIGHT APPROX. 74 lb [33.6 kg].

43.9

[1115] 13.3

[338]

16.8

[427]

23.9

[607]

15.6

[396]

15.5

[394]

20.3

[516]

21.3

[541]

S525 DIMENSIONS

S518S DIMENSIONS

6/6 PAGES

S512 / S515

S525 / S518S

S500 Series

Passive Loudspeakers

Part No. SW0962 Rev. A 12/12

S512

2-WAY PASSIVE LOUDSPEAKER

SERIAL NUMBER / REVISION

INPUT THRU

PARALLEL

IMPEDANCE

8 OHMS

POWER

500 WATTS

PROGRAM

S525

2-WAY PASSIVE LOUDSPEAKER

SERIAL NUMBER / REVISION

INPUT THRU

PARALLEL

IMPEDANCE

8 OHMS

POWER

1200 WATTS

PROGRAM

S515

2-WAY PASSIVE LOUDSPEAKER

SERIAL NUMBER / REVISION

INPUT THRU

PARALLEL

IMPEDANCE

8 OHMS

POWER

600 WATTS

PROGRAM

S518S

PASSIVE SUBWOOFER

SERIAL NUMBER / REVISION

INPUT THRU

PARALLEL

IMPEDANCE

8 OHMS

POWER

900 WATTS

PROGRAM

S512 REAR PANEL

S525 REAR PANEL

S515 REAR PANEL

S518S REAR PANEL

Electronic ﬁles for this product are available at:

www.mackie.com

Speciﬁcation Sheet S500_Series_Loudspeakers_SS.PDF

Owner’s Manual S500_Series_Loudspeakers_OM.PDF

www.mackie.com

16220 Wood-Red Road NE

Woodinville, WA 98072 USA

800-898-3211, Fax 425-487-4337, [email protected]

LOUD Technologies Inc. is always striving to improve our products

by incorporating new and improved materials, components, and

manufacturing methods. Therefore, we reserve the right to

change these speciﬁcations at any time without notice.

“Mackie” and the “Running Man” ﬁgure are registered trademarks of

LOUD Technologies Inc. All other brands mentioned are trademarks

or registered trademarks of their respective holders, and are hereby

acknowledged.
