LY International Electronics PM8006 Manuel utilisateur

P.A.SERIES

CDPLAYER/TUNER/CASSETTE/AMPLIFIER

PM8006

PM8012

PM8025

PM8035

OWNER’S MANUAL

Before operating, please read this manual completely．

FEATURES

 CD & MP3 Player, Digital Tuner, Full-logic Cassette and Amplifier all in one.

 Two Microphone inputs, one AUX input and one AUX output for linking.

 Chime function.

 Microphone input 1 and Chime out prior to other inputs.

 Low / high tone control and volume control available.

 Transformer isolated 100V, 70V and 4 Ohms outputs for speaker.

 A five-element LED level meter and protective indicator are provided for quick

and easy visual monitoring.

FFONT PANEL

1 Power switch 14 Protect indicator 27 CD-Repeat Play

2 Selector- CD 15 VFD 28 CD-Open / Close Door

3 Selector- TUNER 16 TUNER-Band 29 CD-Play

4 Selector- DECK 17 TUNER-Scan high→low 30 CD- Stop

5 Selector- AUX 18 TUNER- Scan low→high 31 CD- Door

6 Chime button 19 TUNER-Memory 32 DECK- Open / Close Door

7 Mic1,Mic2 jacks 20 TUNER-Memo 1→20 33 DECK- Door

8 Mic1,Mic2 volumes 21 TUNER-Memo 20→1 34 DECK- Rewind

9 Bass control 22 CD- Skip down 35 DECK- Fast forward

10 Treble control 23 CD- Skip up 36 DECK- Left Play

11 Main Volume 24 CD-Search down 37 DECK- Right Play

12 Output level meter 25 CD- Search up 38 DECK-Stop

13 Power indicator 26 CD-Pause 39 DECK-Record

Note:

When all the 5 LEDs of level meter remain lit, this indicates that sound is distorted. In such a case, adjust each

volume control so that LED 4 and 5 flash.

REAR PANEL

1 Mains 6 Mute control 11 AUX in Jack

2 AC fuse 7 Chime volume , 12 AUX out Jack

1 2 10 11 12

4 3 5 6 7

3 AC Power 8 FM antenna 13 Remoted controllor input

4 Fan 9 AM antenna

5 Output terminals 10 RS232 port link

CONNECTIONS

Note: Normally, use one pair of output terminals only.

220V

AM ANT

FM ANT

Console

PB Series Amp.

To another device

OPERATION

Press AC POWER button on the rear panel to connect power source and POWER OFF will display on the screen with

rolling form. Then press POWER button on the front panel to turn on the system and WELCOME appears on the screen.

The system will select the Mode the same as you turned off last time in 10 seconds.

1. Play CD / VCD / MP3

Press key CD of selector, and DISC appears on the screen. CD play will start in 1s. or NO DISC appears for indicating

none of CD here.

 Disk Load / Unload Press key to open the CD deck, put in or take out a disk and then press key again for

resetting the deck.

 Play in Order After the deck reset it will play in order automatically. Press selector key CD as well as the key ,

it will play in order too.

 Option Play Press or and or while play, we can select any song or any paragraph for

play.

 Play Repeatedly Press key REPEAT once, it will play the song repeatedly. Presses key REPEAT once again, it

will play repeatedly with whole disk. Press key REPEAT the 3rd time for terminating REPEAT.

 Pause Press key while play for pause. Press the key again for releasing.

 Stop Press key to stop in any time.

2. Radio Receiving

Press selector key TUNER the system will select the Receive Mode with the same frequency as that of the one you turned

off last time. The screen will show the Band and Frequency received.

 Band Selecting Press key BAND for switching the band between FM and AM alternatively.

 Auto Tune Press key DOWN or UP next to BAND for 1s. to search the radio stations automatically. The screen

will flash until you find a radio station, and shows the frequency digital of the radio station you found. The symbol

of STEREO appears while the radio signal is the form of stereo and the level is high enough.

 Fine Tune When the signal is very poor, we need to search the radio station by clicking the key DOWN or UP.

Every time you click, the frequency will be step up or down 50 kHz (FM) or 9 kHz (AM).

 Memory After selected a station, press key MEMO with symbol MEM flash. Press M-DOWN or M-UP for

location the memory from CH-01 to CH-20, then press key MEMO again for confirming with symbol MEM

disappears. Note that, in this case the previous value of the memory will be replaced. For call out the memory, just

press down M-DOWN or M-UP to select one of the memories through CH-01 to CH-20.

3. Tape Playing

Press key Tape of the selector to play tape. Clean the magnet head after 10 hours playing so that the voice quality is as

fidelity as possible. After playing for 20-30 hours should delete the magnet by playing magnet-deleting tape.

 Insert / Take out Tape Press the symbol OPEN/CLOSE to open the door of deck, insert or take out a cassette

tape and then close it.

 Rewinding Press to rewind the tape.

 Fast forward Press to forward the tape.

 Tape playing: Press or to play the tape, after playing one side the system will rewind automatically to

play another side. Press to have it stopped.

 Record: Only stop status, press ● to record the tape. you can record from the CD, tuner, AUX or MIC. adjust

the main volume controlling button, until LED element 3 (+6dB) and LED element 4 (+8dB) shall

flash .You can not record if tape is protected.

4. Using External Signal

Press key AUX for selecting external program from AUX port on rear panel.

5. Using Microphone

Volume down the Microphone Volume to avoid strong vibration when inserts a Microphone.

Insert the Microphone into socket MIC1 or MIC2 with a 6.35mm plug, and turn the relative Volume knob in a moderate

standard to avoid any damage. MIC1 have such a priority that when it is sound all others signal that is playing has to give

way to it. This MUTE function is for emergent speaking. We can also adjust the suppressing level with MUTE LEVEL

on the rear panel.

6. Built-in Chime

Pressing key CHIME and melody ‘ 1 3 5 i ’ is to be played with the priority function same as MIC1. We can also tune

the volume of it by CHIME controller on the rear panel.

6. Remote control

Remote control device can operate it by timer through the cable.

PRECAUTIONS

1 Does not block ventilation holes.

2 The set should not be placed areas:

1) with poor ventilation.

2) exposed to direct sunlight.

3) with high ambient temperature or adjacent to heat generating equipment.

4) with high humidity or dust levels.

5) susceptible to vibration.

3 Make sure the power outlet conforms to the plug of the unit.

4 Do not use this unit if the electrical power cord is frayed or broken.

5 Always operate the unit with the AC ground wire connected to the electrical system ground

SPECIFICATIONS

CD Section

Frequency response 20 Hz-20 kHz

Signal to Noise Ratio

98dB

Dynamic range 90 dB

THD 0.005%

Wow & Flutter Under the limited level

Tuner Section

Sensitivity 50 dBμ

Wave Band 525 ~ 1625 kHz

Band width 6 kHz

Signal to Noise Ratio

50 dB

Sensitivity 2 μV

Wave Band 87.5 ~ 108.0 MHz

Band width 15 kHz

Signal to Noise Ratio

75 dB

Cassette Section

Tape Speed 4.76 cm/sec

Wow & Flutter Less Than 0.1%

Frequency response 125 Hz ~ 6.3 kHz

Signal to Noise Ratio

50 dB

Amplifier Section

Model PM8006 PM8012 PM8025 PM8035

Output 60W 120W 250W 350W

Output Regulation Less than 5 %

Speaker Output Balanced 4Ω, 70V, 100V

AUX Out 600Ω, 1V ( 0 dBV )

Input MIC 1,2: 600Ω, 2.5 mV ( -52dBV ), unbalanced

AUX: 10 kΩ, 150 mV ( -17 dBV ), unbalanced

Frequency Response

MIC 100 Hz ~10 kHz; AUX 100 Hz ~ 16 kHz

Distortion Less than 0.5% at 1 kHz , 1/3 rated power

Signal to Noise Ratio

MIC 1,2: 66 dB

AUX: 70 dB

Tone Bass: ±10 dB at 100 Hz

Treble: ±10 dB at 10 kHz

Protection AC fuse, DC voltage, overload and short circuit

Muting Function MIC 1 overrides other input signals with 0 ~ -30 dB attenuation

Power Requirements

AC 220 ~240 V / 50 ~ 60 Hz

Power Consumption

120W 250W 500W 650W

Dimensions (mm) 420×400×132

Specifications are subject to change without notice

Caution

To reduce the risk of electric shock, do not remove the cover.

No user parts inside. Refer servicing to qualified service personnel.

LY INTERNATION ELECTRONICS CO., LTD

HTTP://WWW.LYINTLCORP.COM/
