Lumiscope 2000-T Manuel utilisateur
Transcutaneous Electrical Nerve
Stimulation (TENS)
Model 2000-T
Operation Manual
Read this manual before operating your 2000-T.
Save this manual for future use.
The most current version of this manual can be found online at
www.grahamfield.com.
2000-T-INS-LAB-RevC14
2000-T-INS-LAB-RevC14 2
CONTENTS
INTRODUCTION TO TENS .......................................................................... 3
INDICATIONS AND CONTRAINDICATIONS ................................................. 3
SAFETY ...................................................................................................... 4
WARNINGS................................................................................................. 4
PRECAUTIONS / ADVERSE REACTIONS ..................................................... 5
ABOUT THIS DEVICE.................................................................................. 6
SYSTEM COMPONENTS ............................................................................. 6
UNIT CONTROLS........................................................................................ 7
ATTACHING THE LEAD WIRES .................................................................... 8
ELECTRODE SELECTION AND CARE........................................................... 8
TIPS FOR SKIN CARE ................................................................................. 9
CONNECTING THE TENS DEVICE............................................................. 10
BATTERY INFORMATION .......................................................................... 11
CARING FOR YOUR TENS DEVICE ............................................................ 12
TROUBLESHOOTING ................................................................................ 13
TECHNICAL SPECIFICATIONS .................................................................. 14
OUTPUT SPECIFICATIONS ....................................................................... 14
LIMITED WARRANTY ................................................................................ 15
GF Health Products, Inc. is not responsible for typographical errors. For the
most updated and current information on packaging, warranties, products
and specifications, including the most current version of these instructions,
please visit our website at www.grahamfield.com.
Graham-Field, Lumiscope, and Lumiscope for the Quality of Life are
registered trademarks of GF Health Products, Inc.
2000-T-INS-LAB-RevC14 3
INTRODUCTION TO TENS
What is Pain?
Pain is the body’s warning system. Pain is important because it signals an
unusual condition in the body and alerts us before additional damage or
injury can occur. TENS was developed to help relieve some types of chronic
and acute pain.
How Does TENS Work?
TENS, Transcutaneous Electrical Nerve Stimulation, is a method of treating
pain that is non-invasive and does not use pharmaceuticals. The TENS
device sends impulses through the skin that stimulate the nerve (or nerves)
in the treatment area. In many cases this stimulation will greatly reduce or
eliminate the pain sensation felt by masking the original pain message sent
to the brain.
It is also believed that TENS stimulation helps release endorphins into the
blood stream thereby further reducing pain.
TENS devices are clinically proven to be useful in pain management for
many patients. By reading this manual and carefully following the treatment
instructions given to you by your clinician, you can attain the maximum
benefit from your TENS device.
INDICATIONS AND CONTRAINDICATIONS
Read the operation manual before using this TENS device.
Federal law (USA) restricts this device to sale by or on the order of a
physician.
Indications
TENS is indicated to be used under a physician’s prescription for the
symptomatic relief of chronic (long term) pain and for the treatment of
postoperative or posttraumatic pain.
2000-T-INS-LAB-RevC14 4
Contraindications
• Patientswithimplantedelectronicdevices(forexample,apacemaker)
or metallic implants should not undergo TENS treatment without first
consulting a physician.
• Anyelectrodeplacementwhichappliescurrenttothecarotid(neck)
region.
• Anyelectrodeplacementwhichcausescurrenttoflowtranscerebrally
(through the head).
• Theuseof TENSwheneverpainsymptomsareundiagnosedandthe
etiology is unknown.
SAFETY
Always follow basic safety precautions, including the following:
WARNING: Indicates a potential hazard situation or unsafe practice
that, if not avoided, could result in death or serious personal injury.
sCAUTION: Indicates a potential hazard or unsafe practice that, if not
avoided, could result in minor personal injury or product / property
damage.
WARNINGS
WARNING: TENS devices must be kept out of reach of children.
WARNING: The safety of TENS devices for use during pregnancy or
delivery has not been established.
WARNING: TENS is not effective for pain of central origin (headaches).
WARNING: If TENS treatment becomes ineffective or unpleasant,
stimulation should be discontinued until evaluated by a physician.
WARNING: Avoid adjusting controls while operating machinery or
vehicles.
WARNING: Always turn the TENS device OFF before applying or
removing electrodes.
2000-T-INS-LAB-RevC14 5
WARNING: TENS may interfere with electronic monitoring equipment
(ECG monitors / alarms).
WARNING: Electrodes should not be placed over the eyes, in the mouth,
or internally.
WARNING: TENS devices have no curative value.
WARNING: TENS is a symptomatic treatment and as such suppresses
the sensation if pain which would otherwise serve as a protective
mechanism.
WARNING: Notice for California Customers- California Proposition
65 WARNING: This product contains a chemical known to the State of
California to cause cancer and reproductive or developmental harm.
PRECAUTIONS / ADVERSE REACTIONS
sCAUTION: Isolated cases of skin irritation may occur at the site of
electrode placement during long-term application.
sCAUTION: Effectiveness is highly dependent upon patient selection of a
doctor qualified in the management of pain patients.
sCAUTION: Skin irritation and electrode burns are potential adverse
reactions.
2000-T-INS-LAB-RevC14 6
ABOUT THIS DEVICE
Your TENS device is a battery operated device that includes two controllable
output channels. This TENS device creates electrical impulses whose
amplitude, duration, and modulation can be altered with the controls or
switches. The TENS intensity controls are very easy to use, and the slide
cover protects accidental changes in settings.
MODE
(uS)
PULSE WIDTH
(Hz)
PULSE RATE
Lead Connector
Intensity Controls
Indicator Light
Pulse Width Control
Mode Selector
Pulse Rate Control
Battery Compartment
Battery Strip
0
100
180
230
260 2
60
115
120
10
SYSTEM COMPONENTS
Your device may include the following components or accessories:
• TENSunit
• Carryingcase
• Leadwires
• Operationmanual
• Electrodes
Alsorequired(notincluded):One9-Voltalkalinebattery.
2000-T-INS-LAB-RevC14 7
UNIT CONTROLS
Panel Cover: A cover which conceals the controls for the Pulse Width, Pulse
Rate, and Mode Selector. Press the top portion of the cover and pull down in
order to open the cover.
Intensity: The intensity knobs located on the top of the unit affect the
strengthof thestimulationandalsofunctionasON/OFFcontrols.
Mode: The Mode switch is used to select the type of treatment utilized. The
three modes are Burst (B), Continuous (C), and Modulation (M).
Pulse Width: The Pulse Width knob regulates the pulse width for both
channels.
Pulse Rate: The Pulse Rate knob regulates the number of pulses per second
for both channels.
Mode Functions:
Burst (B) releases individual bursts twice per second, pulse width is
adjustable and the pulse rate is set at 100Hz per second.
Continuous (C) stimulation is delivered continuously at the settings
determined by intensity, rate, and width knobs.
Modulation (M) pulse width decreases the pulse width down to 60% of the
original width setting. This decreased pulse width is maintained for 1.5
seconds before returning to the original width setting, which is maintained
for 3.5 seconds. The cycle is then repeated. The intensity and pulse rate are
adjustable.
2000-T-INS-LAB-RevC14 8
ATTACHING THE LEAD WIRES
WARNING: Ensure the device is OFF before connecting the lead wires.
WARNING: Never insert the lead wire plug into an AC power supply
socket. Personal injury and/or damage to the TENS unit could occur.
sCAUTION: Use care when you plug and unplug the wires. Pulling on the
lead wire instead of its insulated connector may cause wire breakage.
The lead wires provided with the TENS device insert into the ports located
on top of the unit. Holding the insulated portion of the connector, push the
plug end of the wire into one of the ports; one or two sets of the wires may
be used. After connecting the wires to the stimulator, attach each wire to an
electrode.
Lead wires provided with the TENS device are compliant with mandatory
compliance standards set forth by FDA.
ELECTRODE SELECTION AND CARE
Using Electrodes
Use the electrodes as prescribed. Follow application procedures outlined in
electrode packaging to maintain stimulation and prevent skin irritation. The
electrode packaging provides instructions for care, maintenance, and proper
storage of electrodes.
2000-T-INS-LAB-RevC14 9
TIPS FOR SKIN CARE
Good skin preparation is important for effective and comfortable use of your
TENS device.
• Alwayscleantheelectrodesitewithmildsoapandwatersolution,rinse
well, and dry thoroughly prior to any electrode application.
• Anyexcesshairshouldbeclipped,notshaved,toensuregoodelectrode
contact with the skin.
• If askintreatmentorpreparationisrecommendedbyyourphysician
/clinician,applytheskintreatmentasrecommended,letdry,and
apply electrodes as directed. Following these recommendations will
both reduce the chance of skin irritation and extend the life of your
electrodes.
• Avoidexcessivestretchingof theskinwhenapplyingelectrodes.Proper
application is best accomplished by applying the electrode, then
smoothly pressing it in place from the center outward.
• Whenremovingelectrodes,alwaysremovebypullinginthedirectionof
hair growth.
• Itmaybehelpfultorubskinlotiononelectrodeplacementareawhennot
wearing electrodes.
2000-T-INS-LAB-RevC14 10
CONNECTING THE TENS DEVICE
Insert battery
TurnthedevicetotheOFFpositionbeforeinsertingorremovingthebattery.
When inserting the battery, ensure the battery polarity (+ and –) markings
match the markings on the device.
Prepare the Skin
Prepare the skin as previously described and according to the instructions
provided with your electrodes. Before attaching the electrodes, identify the area
thatyourphysician/clinicianhasrecommendedforelectrodeplacement.
1. Connect the lead wires to the electrodes: connect the lead wires to the
electrodes before applying the electrodes to the skin.
WARNING: Ensure both Intensity Control Knobs for Channel 1 and 2
are turned to the OFF Position (counterclockwise) before applying the
electrodes.
2. Place electrodes on the skin: place the electrodes on the skin as
recommendedbyyourphysician/clinician.
3. Insert lead wire connector into the device: plug end of lead wire into the
channel output port (jack) to be used; push the plug in as far as it will go.
4. Select treatment settings: ensure your unit is still set to the proper
settingsrecommendedbyyourphysician/clinician.
5. Adjusting Channel Intensity Control: locate the Intensity Control Knob
(Channel 1 or 2) at the top of the unit. Slowly turn the Intensity Control
Knob clockwise until the stimulation is at the level recommended by your
physician/clinician(if youdon’tfeelanything,turntheKnobOFFthen
ONagainandcarefullyturntheControlKnobuntilyoufeelatingling
or slight twitch under or around the electrodes). The indicator light will
illuminate when unit is in operation. Always start with the lowest setting
and increase the intensity slowly.
If the stimulation levels are uncomfortable or become uncomfortable, reduce
the stimulation intensity to a comfortable level; or cease stimulation and
contact your physician.
Table des matières
