Thermal Detector
5251EM
Description
The addressable Thermal Detector 5251EM is based
on the heat principle and was developed for the indoor
temperature supervision in a wide range of fi re detec-
tion applications.
When used with a Fire Detection Control Panel Series
BC216, the detector can operate either as maximum
heat detector with alarm temperature 58°C (EN 54-5
Class A1S) or alarm temperature 78°C (EN 54-5 Class
BS), or as rate-of-rise heat detector with a maximum
temperature of 58°C (EN 54-5 Class A1R).
The proven ADM loop technology with System Sen-
sor/200 protocol establishes a permanent communi-
cation between the fi re detection control panel and the
detector. That ensures a periodical function testing of
the detector. Fires are safely detected in the control
panel by continuously analysing the measured values.
The two LEDs with 360° visibility indicate the activated
condition of the detector. The detector address is se-
lected with two decadic rotary switches, thus allowing
to change the detector without additional tools.
A detector function test can be conveniently conducted
using a magnet or a detector test device. The detector
can be attached to various bases and it can be protec-
ted against theft.
• ADM loop technology with
System Sensor/200 protocol
• For use as maximum heat or
rate-of-rise heat detector
• Alarm temperature 58°C or 78°C
software selectable
• Optional connection of remote
indicator
• Function testable with magnet
© LABOR STRAUSS SICHERUNGSANLAGENBAU GMBH • A-1231 WIEN • WIEGELESTRASSE 36 • TEL +43 1 52114-0 • FAX +43 1 52114-27
[email protected] • WWW.LST.AT • ALL RIGHTS RESERVED
5251EM_DBL_LST_EN_0804.PDF • PAGE 2
ABuilding Safety. Building Security.
Specifi cations
Operating voltage Supply through loop voltage
Current consumption max. 200µA (quiescent)
Alarm temperature
Class A1S typ. 58°C (maximum principle), max. room height 7.5m
Class A1R typ. 58°C (rate-of-rise principle), max. room height 7.5m
Class BS typ. 78°C (maximum principle), max. room height 6m
Operating temperature
Classes A1S and A1R max. +45°C
Class BS max. +68°C
Ambient temperature -20°C to +60°C (continuous operation)
Relative humidity 10 – 93% (no condensation)
Dimensions ø × H 102 × 51 (mm)
Colour cream
Weight 102g
Approval VdS G200094
Order number 242002
Order name Thermal Detector/Anal./200/SS 5251EM
