November 2000 1

LSI22902/22903 Host Adapter

to Intel ISP1100 Internet Server

Quick Installation Guide

The LSI Logic LSI22902/22903 PCI to Dual Channel Ultra2 SCSI Low

Profile Host Adapter is ideally suited for installation into the Intel ISP1100

Internet Server Platform. In this application, the host adapter provides

one internal LVD only channel and one LVD or SE external channel.

1Overview

This document describes installing the LSI22902/22903 into the Intel

ISP1100 Internet Server Platform. The host adapter kit includes the

following items. Refer to Figure 1 for a picture of the complete kit.

•LSI22902 or LSI22903 Host Adapter.

•Host Adapter user’s guide.

This manual contains detailed engineering documentation for the

LSI22902/22903.

•PCI Storage Device Management SDMS 4.0 CD.

This CD contains software and associated documentation for the

LSI22902.

•Internal SCSI cable with attached Ultra2 LVD terminator.

•High Density (HD) LED connector.

•An additional card guide for a standard PC chassis.

2 LSI22902/22903 Host Adapter to Intel ISP1100 Internet Server

Figure 1 LSI22902 Host Adapter Kit

2 Installation

The installation process contains the following four major sections:

•Section 2.1, “Setting up the Installation”

•Section 2.2, “Installing the Host Adapter Board”

•Section 2.3, “Installing New Drives”

•Section 2.4, “Completing the Installation”

LSI22902/22903 Host Adapter to Intel ISP1100 Internet Server 3

2.1 Setting up the Installation

Important: Make sure the ISP1100 server is turned off and is not

plugged into an electrical outlet. Take all precautions to

minimize ESD. A ground strap is recommended.

Step 1. Identify the parts listed below on the LSI22902/22903. Refer to

Figure 2 for a photograph of the board.

•Internal Channel B, 68-pin HD connector, J4.

•Hard drive activity LED connector, J3.

•External Channel A, VHDCI 68-pin connector, J2.

Note: Detailed specifications for both boards are contained in the

host adapter user’s guide.

Figure 2 LSI22902/22903 Close-up

Step 2. Remove the top cover of the Intel ISP1100 server by removing

the top plate screw.

Step 3. Carefully slide the top cover plate back until the beveled front

edge clears the chassis.

4 LSI22902/22903 Host Adapter to Intel ISP1100 Internet Server

Step 4. Lift the cover using the notch in the front of the cover and

remove.

Refer to Figure 3 for a photograph of the ISP1100.

Figure 3 Intel ISP1100 Internet Server

Step 5. Locate the components of the ISP1100. Refer to Figure 4 for a

photograph of an opened unit.

a. Retention bracket.

b. PCI bus riser card.

c. Area for mounting the LSI22902/22903.

Theslotontherightsideoftherisercard.

d. Slimline floppy cable.

White cable approximately 1 inch wide.

e. IDE cables for hard drives and CD-ROM.

Gray cables approximately 2 inches wide.

LSI22902/22903 Host Adapter to Intel ISP1100 Internet Server 5

f. Slimline floppy and CD-ROM assembly.

g. Two hard drive bays.

The ISP1100 is provided with a floppy cable for hard drives,

but no drives are installed or included.

h. IDE cable with hard drive connectors.

The cables are routed under the drive bays and the

CD-ROM/floppy assembly.

i. SCSI hard drive activity LED connector .

J11 on the mainboard.

Figure 4 Intel ISP1100 Server, Cover Removed

2.2 Installing the Host Adapter Board

This section of the manual describes setting up the Intel ISP1100 server

and installing the LSI22902/22903 and other system hardware.

Step 1. Identify the PCI low profile slot for the host adapter board.

6 LSI22902/22903 Host Adapter to Intel ISP1100 Internet Server

Refer to Figure 5.

Step 2. On the back of the chassis, remove the two screws holding the

expansion bays retention bracket.

Step 3. Remove the retention bracket and the expansion slot cover.

Figure 5 PCI Slot Location

You can use one of two methods to install the SCSI card in the ISP1100.

Both methods install the board in the same location but use a different

sequence of steps. You might want to review both methods to see which

you prefer. The LSI22902/22903 provides the best performance in a

64-bit PCI SCSI host adapter card, but it provides full functionality in the

32-bit slots of the ISP1100.

2.2.1 LSI22902 Installation Method 1

Follow these steps to install the LSI22902/22903 into the ISP1100. Refer

to Figure 6 for a photograph of the Method 1 installation.

LSI22902/22903 Host Adapter to Intel ISP1100 Internet Server 7

Step 1. Attach the hard drive LED cable to the SCSI host adapter card.

Use either pin pairs 1-2 or 3-4, as shown in the inset in

Figure 6.

Step 2. With the host adapter board bracket facing the rear of the

computer, insert the host adapter card in the expansion slot by

carefully pressing the PCI bus edge connector into the PCI slot.

TheSCSIcardalignsitselfproperlytothePCIslotifthecard

guide bracket is in the proper position.

With the card properly inserted, the SCSI card bracket rests in

the tab on the back of the chassis. There is no screw securing

the card guide bracket in place as in a PC.

Step 3. Secure the expansion bay retention clip with the two previously

removed screws.

Figure 6 Method 1 Installation

8 LSI22902/22903 Host Adapter to Intel ISP1100 Internet Server

2.2.2 LSI22902 Installation Method 2

Method 2 is different from the first method in that you remove the riser

card from the ISP1100 to insert the LSI22902/22903, rather than doing

it in place as in Method 1. Refer to Figure 7 for a photograph showing

the host adapter installed in the riser card.

Step 1. Attach the hard drive LED cable to the SCSI host adapter card.

Use either pin pairs 1-2 or 3-4, as shown in the inset in

Figure 7.

Step 2. Gently remove the riser card from the server board connector.

Step 3. Plug the SCSI card in the right slot on the riser card.

Step 4. Press the riser with the installed SCSI card straight down into

the mating connector on the server board.

With the card properly inserted, the SCSI card bracket rests in

the tab on the back of the chassis. There is no screw securing

the card guide bracket in place as in a PC.

Step 5. Secure the expansion bay retention clip with the two previously

removed screws.

LSI22902/22903 Host Adapter to Intel ISP1100 Internet Server 9

Figure 7 Method 2 Installation

At this point in the installation process, you should be at the same point,

regardless of the installation method chosen. Proceed with the next step.

Step 6. Remove the floppy drive cable as shown in Figure 8 by gently

lifting the cable retainer on the connector, pulling the cable from

under the fan assembly bracket, and laying it back to the side.

Do not disconnect this cable from the mainboard.

Step 7. Remove the CD-ROM cable and power cable as shown in

Figure 9.

Press the cable ejector tabs on both sides of the cable and

disconnect the CD-ROM power cable.

10 LSI22902/22903 Host Adapter to Intel ISP1100 Internet Server

Figure 8 Floppy Cable Location
