Carefully unwrap the roller blind and its associated brackets.
The brackets are universal and can be xed in a top, face or side
x position.
Note – System 32® has two differing brackets, an idle end and a control end that
should be installed for the operation of the blind.
Fitting the brackets.
To work out the distance required between each bracket you will need to rst
measure the fabric width, e.g 1500mm.
Add to this an allowance for the control and idle end of 35mm, e.g = 1535mm.
1535mm would be the measurement from the outside of one bracket to the
outside of the other bracket.
Roller System 32® Side Control
Fitting & Operating Instructions
(shown in top x position)
Control end bracket
Idle end bracket
Fabric Width = e.g 1500mm
Distance between outside edge of the brackets =
e.g 1500mm + 35mm = 1535mm
Control end Idle end
