4 CHANNEL digitAL vidEo

rECordEr

BUSINESS AND HOME SECURITY

SEE WHAT YOU’VE BEEN MISSING

• Four Channel digital video recorder

• Supports 2 disk drives (1 internal/1 removable)

• Password Security Protected

• Remote Control or Main Panel operation

• 4 camera inputs (4 BNC)

• Viewing options: Quad, Full Screen

• Quick Multiple Search Capability

• On Screen Display and Real Time Clock Function

• 3 Adjustable Video Quality Settings: High, Normal,

Basic

FEAtUrES

• High quality recording with modified MJPEG compression

(5~20Kbyte/frame)

• Alarm terminal block - integrated

L154-81 www.strategicvista.com

4 CHANNEL digitAL vidEo

rECordEr

SPECiFiCAtioNS

©2005 Strategic Vista International Inc.

As our product is subject to continuous improvement,

SVII & subsidiaries reserve the right to modify product

design, specifications & prices without notice and without

incurring any obligation. E&OE

3700 Koppers Street, Suite 100

Baltimore, Maryland 21227,

USA.

Strategic Vista International Inc.

300 Alden Road, Markham,

Ontario L3R 4C1

Canada.

BUSINESS AND HOME SECURITY

Hard Disk Storage: IDE Type, UTMA 66 above (supports 2 HDD - up to 250GB each)

Camera support: 4 analog CCTV

Video Compression: Modiﬁed MJPEG (5~20Kbyte/frame)

Video Resolution up to: 720 x 480

Recording Resolution up to: 640 x 224 (full screen)

Record Modes: Alarm External / Timer / Manual

Camera inputs: 4 BNC Video inputs

Video output: 2 RCA Video outputs

Alarm history log: 1000 events

Security Protection: Password protection

Display refresh rate: 30 FPS NTSC, 25 FPS PAL

Record refresh rate: 30 FPS NTSC, 25 FPS PAL

Video loss detection: Yes

On Screen display: Yes

HDD Key Lock: Yes

Playback Searching: Date & Time / Full list Searching

Alarm input: TTL input, High (5V), Low (GND)

Alarm output: COM / N.O / N.C

Power source: AC100-240V switching adaptor

Power consumption: 25W

Dimension: 385(W) X 73(H) X 290(D) mm

Weight: 5 kg

Operating temperature: 0°C - 50°C
