Longevity Forcecut 40D Manuel utilisateur

Operating Manual

For

FORCECUT 40D

40AMP Plasma Cutter 110v/220v

FORCECUT40-40AMPPlasmacutter110v/220v

2 | P a g e

Table of Contents:

PG. 3: Thank you From LONGEVITY

PG. 4-6: Warranty/Shipping Damage/Order Information

PG 7: General Description

PG. 8-9: Warning and Safety Information

PG. 10: Safety Tips

PG. 11:

Technical Data/ Specifications

PG. 12: Front Panel

PG. 13: Basic Installation

PG. 14-15: Basic Operation

PG. 16: Troubleshooting

PG. 17: Enjoy your new plasma cutter machine from LONGEVITY

FORCECUT40-40AMPPlasmacutter110v/220v

3 | P a g e

THANK YOU!

We, at LONGEVITY, want to thank you for purchasing our product. You are almost ready to

experience Longevity Welding first hand. Longevity definitely appreciates your business and

understand that this equipment may be overwhelming to setup and operate so we have prepared a

manual that will assist you in understand your new plasma cutter/welder. If you have any

questions during or after reading this manual, please feel to contact us! Please take a moment to

Once again, thank you for choosing Longevity as your main welding supplier!

FORCECUT40-40AMPPlasmacutter110v/220v

4 | P a g e

Longevity Global, Inc.

23591 Foley St

Hayward, CA 94545

Toll-Free Customer Support: 1-877-LONG-INC / 1-877-566-4462

Website: www.longevity-inc.com

Sales: [email protected]

Customer Service: [email protected]

Dealers: [email protected]

Complaints: [email protected]

Please join our welding forums to share welding tips and tricks, to receive useful information

from customers who also use our products, and to be a part of the Longevity™ welding

community at www.freeweldingforum.com

Check out LONGEVITY Racing at www.longevity-racing.com

FORCECUT40-40AMPPlasmacutter 110v/220v

5 | P a g e

arranty

LONGEVITY Plasma Cutters, Welders, and Multi-Purpose Welders are covered for specific

Parts and Labor warranty at our facility. For detailed information regarding your specific

LONGEVITY welder or cutter, please view our Terms and Policies page on our website at the

following website link: http://www.longevity-inc.com/terms/

Shipping Damage

Your machine is insured against damage during shipping. Keep all packing materials and

containers in case machine must be returned. We will initiate a claim with the shipping company

to cover damage or loss. If there is shipping damage upon opening your package, our customer

service team will work with you to get the matter resolved.

FORCECUT40-40AMPPlasmacutter 110v/220v

6 | P a g e

In Warranty Service

Customers, who own machines that are in warranty and require service, should contact our

Warranty Department by email at [email protected] to obtain a return authorization code.

In addition to the warranty we offer, we would like for you to register your product on our

website at www.longevity-inc.com/resources. Remember, warranty starts from the date of

purchase. For your convenience, write your order information below so you can track your order

in case you need warranty work.

Order No.: _________________________________

Date of Purchase: _____________________________

Warranty Period: ______________________________

Out-of-Warranty Service

Customers, who own machines that are out of warranty and require service, should contact us for

an estimate. Longevity offers an exchange program on out of warranty units. We also help non

LONGEVITY customers with repairs, replacement, and service.

If your unit is not manufactured by Longevity and you cannot receive service from your

manufacturer or seller, Longevity will lend out hand. Our warranty policy is also available for all

plasma cutters and welders. For more information, please email us at [email protected]

FORCECUT40-40AMPPlasmacutter 110v/220v

7 | P a g e

General Description:

The FORCECUT Series plasma cutters offer a revolutionary new approach to plasma cutting

technology. LONGEVITY® plasma cutters use the newest technology available in the welding

industry with the help of IGBT internal components. By producing the units with inverter

technology, we are able to produce smaller and more efficient units. During the manufacturing

process, we keep maintenance and repair in mind by enabling the internal components of the

machine to be simple plug and operate circuitry enabling all mother boards to be simply replaced

and swapped out. The ForceCut™ series plasma cutters use special safety-redundant circuitry

with built in auto-protection and self-adjusting circuitry to keep the machine running at a safe

threshold. This helps protect the machine from over-voltage, power spikes, tip blowouts and

shorting.

We hope you enjoy your LONGEVITY® ForceCut™ series plasma cutter!

FORCECUT40-40AMPPlasmacutter 110v/220v

8 | P a g e

Warnings and Safety

Welding and plasma cutting may be dangerous to the operator and to bystanders, if the

equipment is not operated properly. Welding or cutting must be performed in accordance with

all relevant safety regulations. Carefully read and understand this instruction manual before

installing and operating this equipment.

Changing function modes during welding may damage

equipment.

Before welding, disconnect the electrode-holder cable from the

equipment.

A circuit breaker is required to prevent electrical overload of the

equipment.

Only high quality welding tools should be used.

Electric Shock can be fatal.

Ensure that ground cable is connected in accordance with

applicable safety codes.

Never touch electrodes, wires, or circuit components with bare

hands. Wear dry welding gloves when welding.

The operator must be insulated from the work piece.

Smoke and gas can be harmful to health.

Ensure that the working area is well ventilated.

Avoid breathing smoke and gas generated during the welding

process. Cutting and welding can cause cancer because of the

smoke that comes from the welds and cuts.

Arc-light emission can be harmful to eyes and skin.

Always wear a welding helmet, anti-radiation glass, and work

clothes while welding.

Ensure that people in or near the working area are protected.

FORCECUT40-40AMPPlasmacutter 110v/220v

9 | P a g e

Welding splash is a fire hazard.

Keep flammable material away from the work place.

Keep a fire extinguisher nearby, and have all personnel trained in its

use. Surface noise generated while welding or cutting can be

harmful to hearing.

In the event of a machine fault.

Refer to this instruction manual.

If the fault cannot be determined, contact your local dealer or

supplier for assistance.

FORCECUT40-40AMPPlasmacutter 110v/220v

10 | P a g e

Safety Tips

Consider the following tips to ensure safe operation of your welding/cutting equipment:

Ensure that this welding equipment is installed in an area free of corrosive chemical gases,

flammable gases or materials, and explosive chemicals.

The area should contain little dust, and have a humidity of no more than 80%.

Operate the welding equipment in an area sheltered from direct sunlight and precipitation.

Work area temperature should be maintained at - to

If, because of an overload, the machine suddenly stops, and it is necessary to restart it, leave

the internal fan operating to lower the inside temperature.

Always wear protective clothing and a welding mask to protect your skin.

Wear safety goggles designed to darken the arc generated by your machine.

Wear suitable noise protection to protect your hearing.

Ensure that machine is grounded through the power cord or on the machine case.

Never operate the machine in bare feet or on a wet floor.

Never switch the machine off while it’s in use. Doing so will damage the internal circuitry.

Ensure that your circuit breaker is rated to handle the current requirements of your machine.

Use a UL approved receptacles and plugs with your machine. Never hard wire the machine to

main power.

Work in a well-ventilated area to avoid smoke. Keep your head out of the smoke. Ensure that

air is flowing away from you to avoid inhaling smoke.

Ensure proper ventilation through the machine’s louvers. Maintain a distance of at least 12

inches between this cutting equipment and any other objects in the work area.

Use a screen or curtain designed to keep passer byes from viewing the arc.

The arc spray and metal spray from machine use may cause nearby fires. Use caution.



If, after reviewing this manual, you have any problems in setting up or operating your

machine, contact us at [email protected].
