Setup Guide | 设置指南
Ultrathin
Magnetic clip-on
keyboard cover
iK1061
带磁力夹的键盘盖
Ultrathin - Magnetic clip-on keyboard cover
English 3
Know your product
71
3
9
10
11
5
4
6
8
2
1
4
®
Ultrathin keyboard cover
®
ON
50°-70°
1 32
1 2
10°-40°
1 32
®
Ultrathin keyboard cover
XXXXXX
4
www.logitech.com/support/ultrathin-i6
PDF
Ultrathin
Magnetic clip-on
keyboard cover
iK1061
带磁力夹的键盘盖
1. Protective cover
2. Battery pull tag
3. Adjustable slot for iPad®
4. Hot keys
5. Keyboard
6. Magnetic clip for attaching to iPad
7. Bluetooth and battery status light
8. Battery holder (two Lithium coin
batteries pre-installed)
9. Bluetooth® connect button
10. On/o switch
11. Documentation
Ultrathin - Magnetic clip-on keyboard cover
4 English
Set up your product
®
50°-70°
®
Ultrathin keyboard cover
®
UltraThin keyboard cover
XXXXXX
1. Pull out the battery tag.
• Your keyboard powers up.
The status light shows solid green
for a few seconds.
• Bluetooth discovery starts
automatically and continues
for 15 minutes. The status light
blinks blue (fast blink).
• If the status light briefly
turns red, replace the batteries.
For more information, see “Replacing
your keyboard batteries.”
2. Place your iPad into the slot in
the Keyboard Cover.
3. Establish Bluetooth connection:
• On your iPad, make sure Bluetooth
is on. Select Settings > Bluetooth
> On.
• Select “Ultrathin” from the Devices
menu.
• Enter the six digit passkey shown on
your iPad screen using your Keyboard
Cover, and press Enter.
The status light shows solid blue for
a few seconds to confirm that Bluetooth
connection is complete.
4. Tilt your iPad to suit your viewing angle.
Multiple angles are available to select,
from 50° to 70°.
Note:
• You will need to apply downward pressure
when you tilt your iPad.
• The maximum weight that can be loaded
onto the slot is 5kg.
Ultrathin - Magnetic clip-on keyboard cover
English 5
Hot keys
Home = iPad Home screen
Switch applications
Siri®
Use your voice to send messages,
make calls, schedule meetings,
and more
Search
Type keywords in the search bar
for contacts, music, notes, events,
mail, web, Wikipedia, and more
Switch language
Switches the keyboard language
Virtual keyboard
Shows/hides the virtual keyboard
Screen Shot
Previous track
Play/Pause
Next track
Mute
Volume down
Volume up
Lock screen
Locks or unlocks the iPad screen
Function keys
Fn + X = Cut
Fn + C = Copy
Fn + V = Paste
Fn + Left cursor = Select left
Selects text on the left,
word by word
Fn + Right cursor = Select right
Selects text on the right,
word by word
Note:
• To select a function key, press and hold the Fn key, and then press the key indicated above.
Ultrathin - Magnetic clip-on keyboard cover
6 English
Connecting to a dierent iPad
®
1. Place the new iPad into the slot in
the Keyboard Cover.
2. Make sure the Keyboard Cover
is turned on.
3. On your iPad, check that Bluetooth is
turned on. Select Settings > Bluetooth
> On.
4. Press the Bluetooth® connect button on
the Keyboard Cover. The Keyboard Cover
is discoverable for 3 minutes.
5. Select “Ultrathin” from the Devices menu.
6. Enter the six digit passkey shown on
your iPad screen using your Keyboard
Cover, and press Enter.
Bluetooth connection is complete.
Use your product
Status light indications
Light Description
Solid green Battery power is good (90%-100%).
Solid red Battery power is low (less than
10%). Replace the batteries.
Blinking blue Fast: The keyboard cover is in
discovery mode, ready for pairing.
Slow: The keyboard cover is trying
to reconnect to your iPad.
Solid blue Bluetooth pairing or reconnection
is successful.
Ultrathin - Magnetic clip-on keyboard cover
English 7
Detaching your iPad
1. Pull back: Tilt your iPad backwards
until it is vertical:
50°-70°
2. Push down: Apply downward pressure
to ensure that the slot is completely flat:
3. Lift iPad: Lift your iPad out of
the Keyboard Cover vertically:
Ultrathin - Magnetic clip-on keyboard cover
8 English
Attaching your iPad to the Keyboard Cover for travel
1. Slide your iPad towards the hinge at the
back of the Keyboard Cover. As your iPad
gets close to the rear hinge, it pops up:
10°-40°
2. Attach your iPad to the rear hinge:
3. Lower your iPad down on to
the Keyboard Cover until it closes.
A magnetic clip holds the iPad
in position:
Note:
• DO NOT try to slide your iPad into the hinge
from the opposite direction:
Ultrathin - Magnetic clip-on keyboard cover
English 9
Replacing your keyboard batteries
1. Place your Keyboard Cover face down
on a flat surface.
2. Using a fingernail or thumbnail,
pry open the battery holder:
3. Turn your Keyboard Cover over so that
the keys are facing upwards, remove the
old batteries from the holder and insert
new batteries.
4. Close the battery holder:
Note: Your Keyboard Cover is provided with
two Panasonic CR2032 3V 225mAh Lithium coin
batteries pre-installed. These provide two-year
battery life, based on two hours usage per day.
When your batteries need to be replaced,
we recommend that you use Panasonic CR2032
3V 225mAh Lithium coin batteries.
Ultrathin - Magnetic clip-on keyboard cover
10 English
Troubleshooting
The Keyboard Cover does not work
• Press any key to wake the Keyboard
Cover from sleep mode.
• Turn the Keyboard Cover O and then
back On.
• If the battery indicator flashes red,
replace the batteries.
• Re-establish the Bluetooth connection
between the Keyboard Cover and iPad:
1. On your iPad, check that Bluetooth
is turned ON.
2. Select Bluetooth, locate “Ultrathin”
in the Devices list, and remove it.
(Click the “i” symbol, and select
“Forget this Device”.)
3. Turn Bluetooth OFF, and then back
on. “Ultrathin” should NOT be
displayed in the Devices list.
4. Press the Bluetooth connect button
on the Keyboard Cover.
5. Select “Ultrathin” from the Devices
menu.
6. Enter the six digit passkey shown on
your iPad screen using your Keyboard
Cover, and press Enter.
My iPad doesn’t fit into the slot
• Make sure you are inserting your iPad on
its side into the slot, with the Home key
on the right hand side. (The Keyboard
Cover does not support portrait mode.)
• Make sure you are using your keyboard
cover with an iPad only, and not with any
other covers or thick glass protectors.
