Logitech IK1041 Manuel utilisateur
Setup Guide | 设置指南
Keys-To-Go
Ultra-portable keyboard iK1041 超便携键盘
Keys-To-Go - Ultra-portable keyboard
2
Contents / 目录
English. . . . . . . . . . . . . . . . . . 3 简体中文 . . . . . . . . . . . . . . . . .11
Keys-To-Go - Ultra-portable keyboard
English 3
Know your product
4
6
7
9
8
2
1
35
www.logitech.com/support/keystogo-ipad
PDF
ON
OFF
1 2
1 2 3
1 2
2.5 h
®
2s
®
®
Keys-To-Go
3
Keys-To-Go
Ultra-portable keyboard iK1041 超便携键盘
1. Hot keys
2. Keyboard
3. Bluetooth® connect key
4. Battery check key
5. Bluetooth and battery status light
6. On/o switch
7. Micro-USB charging port
8. Micro-USB charging cable
9. Documentation
Keys-To-Go - Ultra-portable keyboard
4 English
Set up your product
1. Turn on the keyboard:
ON
Bluetooth discovery starts automatically
and continues for 15 minutes. The status
light blinks blue.
If the status light briefly turns red,
charge the battery. For more
information, see “Charge the battery.”
2. Establish Bluetooth connection:
®
®
Keys-To-Go
On your iPad, make sure Bluetooth is on.
Select Settings > Bluetooth > On.
Select “Keys-To-Go” from the Devices
menu.
Tip: If “Keys-To-Go” isn’t in the list, try pressing
and holding the Bluetooth connect key on
your keyboard for 2 seconds.
Keys-To-Go - Ultra-portable keyboard
English 5
Charge the battery
You should charge the battery when:
• the status light turns red briefly when
you turn on the keyboard, or
• the status light blinks red when you press
the battery check key:
A fully charged battery provides about
3 months of power when the keyboard
is used about two hours a day.
Charging your battery
1. Use the micro-USB charging cable
provided to connect the keyboard to
your computer or a USB power adaptor.
The status light blinks green while
the keyboard is charging.
USB
2. Charge your keyboard until the status
light turns solid green.
Each minute of charging gives you about
two hours’ use.
Note: This ratio is approximate and is based
on the standard user experience. Your result
may vary.
It takes 2.5 hours to fully charge
the battery.
Keys-To-Go - Ultra-portable keyboard
6 English
Hot keys
Home = iPad Home screen
Switch applications
Search
Type keywords in the search bar
for contacts, music, notes, events,
mail, web, Wikipedia, and more
Switch language
Switches the keyboard language
Virtual keyboard
Shows/hides the virtual keyboard
Screen Shot
Previous track
Play/Pause
Next track
Mute
Volume down
Volume up
Bluetooth connect
Battery check
Function keys
Fn + X = Cut
Fn + C = Copy
Fn + V = Paste
Fn + Left cursor = Select left
Selects text on the left,
word by word
Fn + Right cursor = Select right
Selects text on the right,
word by word
Note:
• To select a function key, press and hold the Fn key, and then press the key indicated above.
Keys-To-Go - Ultra-portable keyboard
English 7
Use your product
Status light indications
Light Description
Blinking green The battery is charging.
Solid green When charging, indicates that the battery
is fully charged (100%).
When you press the battery check key,
solid green for 2 seconds indicates that
the battery power is good (above 20%).
Blinking red Battery power is low (less than 20%).
Recharge the battery.
Solid red When you first turn on your keyboard,
the status light shows solid red briefly
if battery power is low.
Blinking blue Fast: The keyboard is in discovery mode,
ready for pairing.
Slow: The keyboard is trying to reconnect
to your iPad.
Solid blue Bluetooth pairing or reconnection
is successful.
Connecting to a dierent iOS device
1. Make sure the keyboard is turned on.
2. On your iOS device, check that Bluetooth is turned on.
Select Settings > Bluetooth > On.
3. Press and hold the Bluetooth connect key on
the keyboard for 2 seconds. The keyboard turns
discoverable for 3 minutes.
4. Select “Keys-To-Go” from the Devices menu.
Keys-To-Go - Ultra-portable keyboard
8 English
When you’ve finished using your product
When not in use, turn o the keyboard to conserve battery power.
OFF
Note:
• The keyboard enters sleep mode if powered on and not used for 2 hours. To exit sleep mode,
press any key.
Keys-To-Go - Ultra-portable keyboard
English 9
Battery disposal at product end of life
1. Cut along the fabric at the top edge of
the keyboard:
2. Use a screwdriver to pry the fabric away
from the area around the on/o switch:
3. Separate the inner and outer fabric layers,
and pull them away from the corner:
4. Pull back the yellow plate to reveal
the battery and remove it:
5. Dispose of the battery according
to local laws.
Keys-To-Go - Ultra-portable keyboard
10 English
Visit Product Support
There’s more information and support
online for your product. Take a moment
to visit Product Support to learn more
about your new Bluetooth keyboard.
Browse online articles for setup help,
usage tips, and information about
additional features. If your Bluetooth
keyboard has optional software, learn
about its benefits and how it can help you
customize your product.
Connect with other users in our Community
Forums to get advice, ask questions,
and share solutions.
At Product Support, you’ll find a wide
selection of content including:
• Tutorials
• Troubleshooting
• Support community
• Online documentation
• Warranty information
• Spare parts (when available)
Go to:
www.logitech.com/support/keystogo-ipad
Troubleshooting
The keyboard does not work
• Press any key to wake the keyboard from
sleep mode.
• Turn the keyboard O and then back On.
• Recharge the internal battery. For more
information, see “Charge the battery.”
• Re-establish the Bluetooth connection
between the keyboard and your iPad:
• On your iPad, check that Bluetooth
is turned on.
• Press and hold the Bluetooth connect
key on your keyboard for 2 seconds.
• Choose “Keys-To-Go” from the
Devices menu on your iPad.
The status light briefly turns blue after
the Bluetooth connection is made.
What do you think?
Thank you for purchasing our product.
Please take a minute to tell us what you think of it.
www.logitech.com/ithink
