Logitech FabricSkin i5 Manuel utilisateur
Setup Guide
FabricSkin Keyboard Folio i5
Logitech FabricSkin Keyboard Folio i5
2
Contents
English 3
Deutsch 12
Français 21
Italiano 30
Español 39
Português 48
Nederlands 57
Svenska 66
Dansk 75
Norsk 84
Suomi 93
Ελληνικά 102
По-русски 111
Magyar 120
Česká verze 129
Po polsku 138
Eesti 147
Latviski 156
Lietuvių 165
Hrvatski 174
Srpski 183
Slovenščina 192
Slovenčina 201
Română 210
Български 219
Українська 228
Türkçe 237
247
www.logitech.com/support 255
Logitech FabricSkin Keyboard Folio i5
English 3
Know your product
5
1
2
4
3
6
7
8
9
10
1. iPad holder
2. Protective folio
3. Function keys
4. Keyboard
5. Bluetooth® and battery status light
6. Reset button
7. Micro-USB charging port
8. Bluetooth connect button
9. Micro-USB charging cable
10. Product documentation
PDF
FabricSkin Keyboard Folio i5
www.logitech.com/support/fabricskin-keyboard-folio-i5
1 2
43
Logitech FabricSkin Keyboard Folio i5
4 English
Setting up the keyboard folio
Getting started
1. Open the keyboard folio, make sure
the edge of your iPad is aligned with
the iPad holder and push down:
2. Move the keyboard folio into the typing
position:
The keyboard turns on automatically.
Establishing connection with your iPad
The keyboard folio links to your iPad via
a Bluetooth connection. The first time you use
the keyboard folio, you must pair it with
your iPad.
The status light blinks blue to indicate that the
keyboard is discoverable, ready for pairing
with your iPad.
The first time you use the keyboard it remains
discoverable for 15 minutes.
If the status light turns red, charge the battery.
For more information, see “Charging the
keyboard battery.”
To pair your keyboard folio with your iPad:
1. On your iPad:
•Make sure your iPad’s Bluetooth feature
is on. Select Settings > Bluetooth > On.
•Select “FabricSkin Keyboard Folio i5”
from the Devices menu.
Logitech FabricSkin Keyboard Folio i5
English 5
2. If your iPad requests a PIN, enter it using
the folio keyboard (not on your iPad).
When successful connection is made,
the status light turns solid blue for a short
time, and then turns o.
Connecting to another iPad
1. Move the keyboard folio into the typing
position.
2. Make sure your iPad’s Bluetooth feature
is on. Select Settings > Bluetooth > On.
3. Press the Bluetooth Connect button:
The keyboard is discoverable for 3 minutes.
4. Select “FabricSkin Keyboard Folio i5”
on your iPad’s Devices menu.
5. If your iPad requests a PIN, enter it using
the folio keyboard (not on your iPad).
When successful connection is made,
the status light turns solid blue for a short
time, and then turns o.
Using the keyboard folio
Two viewing positions
The keyboard folio provides two viewing
positions—one for typing and another
for browsing.
To type, move the iPad holder into the typing
position, aligning it with the built-in magnet
to secure it. Turn on the keyboard:
To browse, place the iPad holder in the
browsing position remembering to switch o
the keyboard to conserve battery power:
If you don’t use the keyboard for a while
in the typing position, it enters sleep mode
automatically. Pressing any key wakes it.
Closing the keyboard folio powers o
your iPad.
Logitech FabricSkin Keyboard Folio i5
6 English
Detaching your iPad
To detach your iPad from the folio, bend back
one of the iPad holder corners:
Your iPad is then released:
Storing your iPad for travel
1. Insert your iPad in the iPad holder.
2. Close the keyboard folio:
Cleaning your folio
Wipe your FabricSkin Keyboard folio with
a wet cloth. DO NOT use solvent.
Logitech FabricSkin Keyboard Folio i5
English 7
Status light indicators
Your keyboard folio’s status light provides information about the battery power
and Bluetooth connection:
Light Description
Blinking green The battery is charging.
Solid green The battery is fully charged (100%).
Red Battery power is low (less than 10%). Recharge the battery.
Blinking blue Fast: The keyboard is in discovery mode, ready for pairing.
Slow: The keyboard is trying to reconnect to your iPad.
Solid blue Bluetooth pairing or reconnection is successful.
Logitech FabricSkin Keyboard Folio i5
8 English
Function keys
Home = iPad Home screen
Fn + 1 = Lock screen
Locks or unlocks the iPad screen
Fn + 2 = Siri
Use your voice to send messages,
make calls, schedule meetings,
and more
Fn + 3 = Search
Launches the iPad search function
Fn + 4 = Switch language
Switches the keyboard language
Fn + 5 = Virtual keyboard
Shows/hides the virtual keyboard
Fn + 7 = Previous track
Fn + 8 = Play/Pause
Fn + 9 = Next track
Fn + 0 = Mute
Fn + dash = Volume down
Fn + plus = Volume up
Fn + X = Cut
Fn + C = Copy
Fn + V = Paste
Fn + Left cursor = Select left
Selects text on the left, word by word
Fn + Right cursor = Select right
Selects text on the right,
word by word
Fn + Spacebar =
Switch applications
Note: To select a function key, press and hold the Fn key, and then press the key indicated above.
Logitech FabricSkin Keyboard Folio i5
English 9
Charging the keyboard battery
If the battery status light is red the keyboard
folio battery needs to be charged.
1. Plug one end of the micro-USB cable into
the charging port, and the other end into
a USB port on your computer.
Alternatively, you can use a 5V USB charger,
such as that provided with your iPad,
providing the power output rating is at
least 500mA.
The status light blinks green as the battery
charges.
2. Charge the battery until the battery status
light turns solid green.
Battery information
•A fully charged battery provides about
three months of use when the keyboard
is used about two hours a day.
•Charge the battery if the status light turns
red briefly after the keyboard turns on.
•When not in use, turn o the keyboard
to conserve battery power.
•The keyboard enters sleep mode
automatically if not used for a while
in the typing position. Press any key
to wake it.
USB
Logitech FabricSkin Keyboard Folio i5
10 English
Battery disposal at product end of life
1. Pry o top cover of keyboard with
screwdriver:
2. Detach battery from circuit board
and remove battery:
3. Dispose of your product and its battery
according to local laws.
Visit Product Central
There’s more information and support online
for your product. Take a moment to visit
Product Central to learn more about your new
keyboard folio.
www.logitech.com/support/fabricskin-
keyboard-folio-i5
Browse online articles for setup help,
usage tips, and information about
additional features.
Connect with other users in our Community
Forums to get advice, ask questions,
and share solutions.
Find a wide selection of content including:
•Tutorials
•Troubleshooting
•Support community
•Online documentation
•Warranty information
•Spare parts (when available)
