Logitech Type + Manuel utilisateur

Type +

Protective case with integrated keyboard

For iPad Air

Setup Guide

Contents

English. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

繁體中文 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

한국어 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21

English 3

Logitech Type + - For iPad Air

Know your product

1. iPad holder

2. Protective folio

3. Hot keys

4. Keyboard

5. Bluetooth® and battery

status light

6. Bluetooth connect button

7. Micro-USB charging port

8. Micro-USB charging cable

9. Product documentation

Type +

Protective case with integrated keyboard

For iPad Air

1 2

43 ®

Type+ Keyboard Case

PDF

4 English

Logitech Type + - For iPad Air

Setting up the keyboard folio

Getting started

1. Open the keyboard folio, make sure

the edge of your iPad is aligned with

the iPad holder and push down:

2. Move the keyboard folio into the typing

position:

The keyboard turns on automatically.

Establishing connection with your iPad

The keyboard folio links to your iPad via

a Bluetooth connection. The ﬁrst time

you use the keyboard folio, you must pair it

with your iPad.

The status light blinks blue to indicate that

the keyboard is discoverable, ready for

pairing with your iPad.

The ﬁrst time you turn on the keyboard

it remains discoverable for 15 minutes.

If the status light turns red, charge

the battery. For more information,

see “Charging the keyboard battery.”

To pair your keyboard folio with your iPad:

1. On your iPad:

• Make sure the Bluetooth feature of

your iPad is on. Select Settings >

Bluetooth > On.

• Select “Type+ Keyboard Case”

from the Devices menu.

English 5

Logitech Type + - For iPad Air

2. If your iPad requests a PIN, enter it using

the folio keyboard (not on your iPad).

When successful connection is made,

the status light turns solid blue for

a short time, and then turns o.

Connecting to another iPad

1. Move the keyboard folio into the typing

position.

2. Make sure the Bluetooth feature of your

iPad is on. Select Settings > Bluetooth > On.

3. Press the Bluetooth Connect button:

The keyboard is discoverable for

3 minutes.

4. Select “Type+ Keyboard Case” on the

Devices menu of your iPad.

5. If your iPad requests a PIN, enter it using

the folio keyboard (not on your iPad).

When successful connection is made,

the status light turns solid blue for

a short time, and then turns o.

Using the keyboard folio

Two viewing positions

The keyboard folio provides two viewing

positions—one for typing and another

for browsing.

To type, move the keyboard folio into the

typing position, aligning it with the built-in

magnet to secure it:

The keyboard turns on automatically

when you move the keyboard folio into

the typing positon.

To browse, place the keyboard folio in

the browsing position:

The keyboard powers o automatically

when you move the keyboard folio out of

the typing position.

6 English

Logitech Type + - For iPad Air

Detaching your iPad

To detach your iPad from the folio,

bend back one of the iPad holder corners:

Your iPad is then released:

Storing your iPad for travel

1. Insert your iPad in the iPad holder.

2. Close the keyboard folio:

English 7

Logitech Type + - For iPad Air

Status light indicators

Your keyboard folio’s status light provides information about the battery power

and Bluetooth connection:

Light Description

Blinking green The battery is charging.

Green The battery is fully charged (100%).

Red Battery power is low (less than 10%). Recharge the battery.

Blinking blue Fast: The keyboard is in discovery mode, ready for pairing.

Slow: The keyboard is trying to reconnect to your iPad.

Solid blue Bluetooth pairing or reconnection is successful.

8 English

Logitech Type + - For iPad Air

Hot keys

Home = iPad Home screen

Switch applications

Siri

Use your voice to send messages,

make calls, schedule meetings,

and more

Launches the iPad search function

Switch language

Switches the keyboard language

Virtual keyboard

Shows/hides the virtual keyboard

Screenshot

Previous track

Play/Pause

Next track

Mute

Volume down

Volume up

Lock screen

Locks or unlocks the iPad screen

Function keys

Fn + X = Cut

Fn + C = Copy

Fn + V = Paste

Fn + Left cursor = Select left

Selects text on the left,

word by word

Fn + Right cursor = Select right

Selects text on the right,

word by word

Note: To select a function key, press and hold the fn key, and then press the key indicated above.

English 9

Logitech Type + - For iPad Air

Charging the keyboard battery

If the status light is red the keyboard folio

battery needs to be charged.

1. Plug one end of the micro-USB cable

into the charging port, and the other

end into a USB port on your computer.

Alternatively, you can use a USB charger

providing the power output rating is

no more than 5V - 500mA.

The status light blinks green as the

battery charges.

2. Charge the battery until the status light

turns solid green.

Battery information

• A fully charged battery provides about

three months of use when the keyboard

is used about two hours a day.

• Charge the battery if the status light

turns red brieﬂy after the keyboard

turns on.

• When not in use, turn o the keyboard

to conserve battery power.

• The keyboard enters sleep mode

automatically if not used for a while

in the typing position. Press any key

to wake it.

• One minute of charging can provide 2

hours of use; approximately 1.5 hours of

charging can provide a full power.*

* Actual charging and battery life will vary with use, settings, and environmental conditions.

USB

10 English

Logitech Type + - For iPad Air

Battery disposal at product

end of life

1. Pry o top cover of keyboard

with screwdriver.

2. Detach battery from circuit board

and remove battery.

3. Dispose of your product and its battery

according to local laws

Visit Product Support

There’s more information and support

online for your product. Take a moment

to visit Product Support to learn more

about your new Bluetooth keyboard.

Browse online articles for setup help,

usage tips, and information about

additional features. If your Bluetooth

keyboard has optional software,

learn about its beneﬁts and how it can

help you customize your product.

Connect with other users in our Community

Forums to get advice, ask questions,

and share solutions.

At Product Support, you’ll ﬁnd a wide

selection of content including:

• Tutorials

• Troubleshooting

• Support community

• Online documentation

• Warranty information

• Spare parts (when available)

Go to:

www.logitech.com/support/type-air
