Logitech CANVAS Manuel utilisateur
CANVAS
Keyboard Case for iPad mini, 2, 3
iK0771 键盘保护套 - 适用于 iPad mini, 2, 3
Setup Guide | 设置指南
3 English
Logitech CANVAS – Keyboard Case – For iPad mini, 2, 3
Know your product
1
2
3
4
5
6
7
8
9
www.logitech.com/support/canvas-ipad-mini
PDF
1 2
43
ON
®
Type + keyboard case
®
®
CANVAS
Keyboard Case
for iPad mini, 2, 3
iK0771 键盘保护套
适用于 iPad mini, 2, 3
1. Tablet holder
2. Function keys
3. Keyboard
4. Bluetooth® and battery
status light
5. Bluetooth connect button
6. Micro-USB charging port
7. On/o switch
8. Micro-USB charging cable
9. Product documentation
4 English
Logitech CANVAS – Keyboard Case – For iPad mini, 2, 3
Setting up the keyboard case
Getting started
1. Open the keyboard case, make sure
the edge of your iPad mini is aligned
with the tablet holder and push down:
2. Move the keyboard case into
the typing position:
Establishing connection with
your iPad mini
The keyboard case links to your iPad mini
via a Bluetooth connection. The first time
you use the keyboard case, you must pair it
with your iPad mini.
To pair your keyboard case with
your iPad mini:
1. Turn on the keyboard:
The Bluetooth light blinks to indicate
that the keyboard is discoverable,
ready for pairing with your iPad mini.
The first time you turn on the keyboard
it remains discoverable for 15 minutes.
If the battery status light shows red,
charge the battery. See “Charging the
keyboard battery” for more information.
5 English
Logitech CANVAS – Keyboard Case – For iPad mini, 2, 3
2. On your iPad mini:
• Make sure Bluetooth is on.
Select Settings > Bluetooth > On.
• Select “Canvas iPad mini”
from the Devices menu.
3. If your iPad mini requests a PIN,
enter it using the keyboard
(not on your iPad mini).
When successful connection is made,
the Bluetooth light turns solid blue
for a short time, and then turns o.
Connecting to another iPad mini
1. Make sure the keyboard is turned on.
2. On your iPad mini, make sure Bluetooth
is on.
Select Settings > Bluetooth > On.
3. Press the Bluetooth connect button:
®
Bluetooth Name
The keyboard is discoverable
for 3 minutes.
4. Select “Canvas iPad mini”
from the Devices menu.
5. If your iPad mini requests a PIN,
enter it using the keyboard
(not on your iPad mini).
When successful connection is made,
the Bluetooth light turns solid blue
for a short time, and then turns o.
6 English
Logitech CANVAS – Keyboard Case – For iPad mini, 2, 3
Using the keyboard folio
Two viewing positions
The keyboard case provides two viewing
positions—one for typing and another
for browsing.
To type, move the keyboard case
into the typing position, aligning it with
the built-in magnet to secure it:
Turn on the keyboard.
To browse, place the keyboard case
in the browsing position:
Remember to switch o the keyboard
to conserve battery power.
If you don’t use the keyboard for a while
in the typing position, it enters sleep mode
automatically. Press any key to wake it.
Detaching your iPad mini
To detach your iPad mini from the case,
bend back one of the tablet holder corners:
Your iPad mini is then released:
Storing your iPad mini for travel
1. Insert your iPad mini in the tablet holder.
2. Close the keyboard case:
7 English
Logitech CANVAS – Keyboard Case – For iPad mini, 2, 3
Status light indicators
Your keyboard case’s status light provides information about the keyboard’s battery power
and Bluetooth connection:
Light Description
Green The battery has adequate charge.
Red Battery power is low (less than 10%). Recharge the battery.
Blinking blue Fast: The keyboard is in discovery mode, ready for pairing.
Slow: The keyboard is trying to reconnect to your iPad.
Solid blue Bluetooth pairing or reconnection is successful.
8 English
Logitech CANVAS – Keyboard Case – For iPad mini, 2, 3
Function keys
Fn + 1 = Lock screen
Locks or unlocks the iPad mini
screen
Fn + 2 = Siri
Use your voice to send messages,
make calls, schedule meetings,
and more
Fn + 3 = Search
Launches the iPad mini search
function
Fn + 4 = Switch language
Switches the keyboard language
Fn + 5 = Virtual keyboard
Shows/hides the virtual keyboard
Fn + 6 = Screenshot
Fn + 7 = Previous track
Fn + 8 = Play/Pause
Fn + 9 = Next track
Fn + 0 = Mute
Fn + dash = Volume down
Fn + plus = Volume up
Home = iPad mini Home screen
Displays the iPad mini Home screen
Fn + X = Cut
Fn + C = Copy
Fn + V = Paste
Fn + Left cursor = Select left
Selects text on the left,
word by word
Fn + Right cursor = Select right
Selects text on the right,
word by word
Fn + Spacebar =
Switch applications
Note: To select a function key, press and hold the Fn key, and then press the key indicated above.
9 English
Logitech CANVAS – Keyboard Case – For iPad mini, 2, 3
Charging the keyboard battery
If the battery status light is red
the keyboard case battery needs
to be charged.
1. Plug one end of the micro-USB cable
into the charging port, and the other end
into a USB port on your computer.
Alternatively, you can use a 5V
USB charger, such as that provided with
your iPad mini, providing the power
output rating is at least 500mA.
The status light blinks green as
the battery charges.
2. Charge the battery until the battery
status light turns solid green.
It takes one hour to fully charge
the battery.
Battery information
• A fully charged battery provides about
six months of use when the keyboard
is used about two hours a day.*
• Charge the battery if the status light
turns red briefly after the keyboard
turns on.
• When not in use, turn o the keyboard
to conserve battery power.
• The keyboard enters sleep mode
automatically if not used for a while
in the typing position. Press any key
to wake it.
* Actual battery life will vary with use, settings, and environmental conditions.
USB
10 English
Logitech CANVAS – Keyboard Case – For iPad mini, 2, 3
Battery disposal at product
end of life
1. Pry o top cover of keyboard
with screwdriver.
2. Detach battery from circuit board
and remove battery.
3. Dispose of your product and its battery
according to local laws.
Visit Product Support
There’s more information and support
online for your product. Take a moment
to visit Product Support to learn more
about your new Bluetooth keyboard.
Browse online articles for setup help,
usage tips, and information about
additional features. If your Bluetooth
keyboard has optional software, learn
about its benefits and how it can help you
customize your product.
Connect with other users in our Community
Forums to get advice, ask questions,
and share solutions.
At Product Support, you’ll find a wide
selection of content including:
• Tutorials
• Troubleshooting
• Support community
• Online documentation
• Warranty information
• Spare parts (when available)
Go to:
www.logitech.com/support/
canvas-ipad-mini
