LOGICOM FIVE Manuel utilisateur

* The latest user manuals can be downloaded from our website http://www.logicom-

europe.com in PDF format

QUICK START GUIDE*

LOGICOM FIVE Smartphone GPS/WIFI/BT/GSM/3G/4G-LTE

Non-contractual photo

TRADEMARKS

Android is a trademarks of Google LLC.

Bluetooth® is a registered trademark of Bluetooth SIG, Inc.

trademarks of Adobe Systems Incorporated in the United States and/or other

countries.

THIS PRODUCT IS LICENSED UNDER THE AVC PATENT PORTFOLIO

LICENSE FOR THE PERSONAL AND NON-COMMERCIAL USE OF A

CONSUMER TO

(i) ENCODE VIDEO IN COMPLIANCE WITH THE AVC STANDARD (“AVC

VIDEO”) AND/OR

(ii) DECODE AVC VIDEO THAT WAS ENCODED BY A CONSUMER

ENGAGED IN A PERSONAL AND NON-COMMERCIAL ACTIVITY AND/OR

WAS OBTAINED FROM A

VIDEO PROVIDER LICENSED TO PROVIDE AVC VIDEO. NO LICENSE IS

GRANTED OR SHALL BE IMPLIED FOR ANY OTHER USE. ADDITIONAL

INFORMATION MAY BE OBTAINED FROM MPEG LA, L.L.C. SEE

HTTP://MPEGLA.COM

Facebook, the Facebook logo, and the F logo are trademarks or registered

trademarks of Facebook, Inc.

Foursquare is the registered trademark of Foursquare Labs, Inc.

This software is partly based onthe work of the Independent JPEG Group.

The MPEG Layer-3 audio encoding technology and the patents are licensed

by Fraunhofer IIS and Thomson.

THIS PRODUCT IS LICENSED UNDER THE MPEG4 PATENT

PORTFOLIO LICENSE FOR PERSONAL, NON-COMMERCIAL USE BY A

CONSUMER TO

(i) ENCODE MPEG4 VIDEO AND/OR

(ii) DECODE MPEG4 VIDEO THAT WAS ENCODED BY A CONSUMER IN

PERSONAL AND NON-COMMERCIAL ACTIVITY AND/OR WAS

OBTAINED FROM A VIDEO PROVIDER LICENSED TO PROVIDDE

MPEG4 VIDEO. NO LICENCE IS GRANTED OR SHALL BE IMPLIED FOR

ANY OTHER USE. ADDITIONAL INFORMATION MAY BE OBTAINED

FROM MPEG LA, L.L.C. SEE HTTP://MPEGLA.COM

SD, SDHC, microSD and the microSDHC logos aretrademarks of SD-3C,

LLC.

THIS PRODUCT IS LICENSED UNDER THE VC-1 PATENT PORTFOLIO

LICENSE FOR

PERSONAL, NON-COMMERCIAL USE BY A CONSUMER TO

(i) ENCODE VC-1 VIDEO AND/OR

(ii) DECODE VC-1 VIDEO THAT WAS ENCODED BY A CONSUMER IN A

PERSONAL AND NON-COMMERCIAL ACTIVITY AND/OR WAS

OBTAINED FROM A VIDEO PROVIDER LICENSED TO PROVIDDE VC-1

VIDEO.

NO LICENCE IS GRANTED OR SHALL BE IMPLIED FOR ANY OTHER

USE. ADDITIONAL INFORMATION MAY BE OBTAINED FROM MPEG LA,

L.L.C.

SEE HTTP://WWW.MPEGLA.COM

Wi-Fi, the Wi-Fi CERTIFIED logo, WPA, WPA2 and Wi-Fi Protected Setup

are trademarks or registered trademarks of the Wi-Fi Alliance.

Windows Media is either a registered trademark or trademark of Microsoft

Corporation in the United States and/or other countries.

All other system, product or service names are trademarks or registered

trademarks of their respective owners. The symbols ((TM)) and (R) are not

used in this manual.

Contents of the package

⚫1 x Smartphone FIVE

⚫1 x Battery V435868ART

⚫1 x Mains adapter charger (Model: PS06CA050K1000EU; 5V 1A)

(SHENZHEN Flypower Technology CO., LTD;.)

⚫1 x USB cable

⚫1 x Quick start guide in French

⚫1 x Quick start guide in English

WARNING: Packaging materials such as tape, plastic sheets, string and

labels are not included in this product.

ATTENTION: for your safety, please do not remove the protective film

from the screen which is under the antistatic film (with tab). It protects

your screen from light scratches and in case of a fall it provides

optimal protection.

Logicom is not liable for any personal injury that results from the customer

removing the protective film. Please note that this protective film does not

make the product more solid. To replace this protective film, please contact

specialist smartphone dealers.

Installation guide

1. Description of the Smartphone.

1 –Front camera

2 –Rear camera & flash

3 –Volume

4 –ON/OFF button

5 –Jack socket

6 –Micro USB socket

7 –Speakers

2. Inserting a SIM card.

Your smartphone is a dual SIM mobile phone, which allows you to usetwo

phone lines on the same smartphone. Your smartphone has two SIM ports

(1 and 2). To insert the SIM card(s):

•Switch off the phone and remove the back cover and the battery.

•Insert the SIM card correctly into the SIM card slot. Make sure that the

cards are inserted in the correct direction.

•SIM 1 uses a Nano-SIM card and SIM 2 uses a Nano-SIM card.

•Then replace the SIM compartment.

•

3. Inserting a MicroSD card

It is possible to increase the internal memory of the device with a MicroSD

card. (not supplied) (MicroSD card of 64GB maximum).

•Switch off the phone and remove the back cover and the battery.

•Insert the SD card correctly into theSD card slot.

•Then put the battery and the back cover of the smartphone back on.

SIM 1

SIM 2

4. Using and charging the battery

Installing the battery:

•Remove the back cover of your smartphone

•Insert the battery, ensuring that the image on the right is facing you.

•Put the back cover of the smartphone back on.

CAUTION: Only use the battery supplied with your smartphone

Model: V435868ART (Li-ion –3,8V –2300mAh)

•To replace a battery, please contact your dealer's service department.

SD Card support

Battery

slot

Charging the battery:

•To charge the battery, plug the USB cable (supplied) into the USB port

on your smartphone. Then connect the cable to a USB port or an AC

adapter (supplied) to a power outlet.

•The battery charge icon lights up during charging to indicate the

charging status. If the temperature of the battery exceeds 45°C, the

battery can no longer be charged.

•When the battery is fully charged, you can remove theUSB cable from

the device.

5. Use of the smartphone

If you have any questions about the use of your smartphone, please

https://support.google.com/android

IMPORTANT:

•The smartphone is charged only via its USB port.

•Make sure your smartphone battery is completely empty before

charging it for the first time.

•The battery should be charged for at least 5 to 8 hours on the first

charge.

•After being storedfor a prolonged period, it may be necessary to charge

and empty the battery several times for maximum performance.

Note: You can use the device while it is charging. The battery

may then take longer to fully charge.

Precautions to be taken when charging the

battery:

•Only use the USB cable supplied with your appliance to charge the

battery. Do not use any other power supplies or electrical devices.

•The USB socket to which the appliance is connected must be installed

near the equipment and must always be within easy access.

•Always wait at least 5 seconds after switching off the device before

restarting it. Turning the appliance off and immediately back on again

can damage electrical circuits.

•Do not disassemble, open or shred the battery cells. Do not dispose of

the battery in fire or water. Do not charge the battery if the ambient

temperature is greater than 45°C. Store the battery in aclean and dry

place. Avoid leaving the battery in direct sunlight.

•Do not short-circuit the battery. Do not store the battery in a place where

it may be short-circuited by other metal objects. Do not drop or hit the

battery

•Do not leave the battery within the reach of children. If a child swallows

an element, consult a doctor immediately. If the battery leaks, be careful

not to let the liquid come into contact with your skin or eyes. If this

occurs, wash with plenty of water and seek medical attention.

•For repair or replacement of the battery, contact a qualified technician.

•The life of the battery depends largely on how you use it. Do not expose

the battery to temperatures below 0°C or above 60°C. This could affect

its functioning. Do not leave the battery on a prolonged charge when not

in use

•Intense electromagnetic interference or electrostatic discharge may

cause malfunction or loss of data. If the device is not working correctly,

restart the smartphone or unplug the USB cable from the device and

then plug it back in.

•If possible, remove the battery when the smartphone is not in use

•Dispose of the battery and the equipment separately. Do not dispose of

the battery with household waste, for further information about recycling

batteries, contact your local municipality, your local waste disposal

centre or the point of sale where you purchased this product.

Warning on telephone use while driving

In France, according to article R412-6-1 of the Highway Code, the use

of a hand-held telephone by the driver of a vehicle is prohibited when

driving.

The penalties for non-compliance with this article are a fine and the

loss of points from the driving licence.

It is also forbidden to wear any system such as headphones, pedestrian kits,

earphones or helmets, which may limit the attention and hearing of drivers.

WARNING: this regulation only applies in France. When travelling

abroad, please check the regulations in force in your destination

country beforehand.
