Linn SNEAKY MUSIC DS Guide de l'utilisateur
SNEAKY MUSIC DS
NETWORK MUSIC PLAYER
SYSTEM INSTALLATION AND SETUP MANUAL
www.linn.co.uk
SNEAKY MUSIC DS
INSTALLATION AND SETUP
COPYRIGHT AND ACKNOWLEDGEMENTS
Copyright © 2008 Linn Products Ltd. First edition March 2008.
Linn Products Limited, Glasgow Road, Waterfoot, Eaglesham, Glasgow,
G76 OEQ, Scotland, United Kingdom
All rights reserved. No part of this publication may be reproduced, stored in
a retrieval system, or transmitted, in any form or by any means, electronic,
mechanical, photocopying, recording, or otherwise, without the prior written
permission of the publisher.
The content of this manual is furnished for information use only, is subject to
change without notice, and should not be construed as a commitment by
Linn Products Limited. Linn Products Limited assumes no responsibility or
liability for any errors or inaccuracies that may appear in this manual.
Trade marks used in this publication: Linn, the Linn logo and Sneaky are
registered trade marks of Linn Products Limited. Music DS is a trade mark of
Linn Products Limited.
Linn Products Limited disclaims any proprietary interest in trade marks and
trade names other than its own.
UK Registered Design no: 4006236
Pack 1395/E
CONTENTS
www.linn.co.uk
SNEAKY MUSIC DS
INSTALLATION AND SETUP
1 OVERVIEW 1
2 SET UP OF THE NAS 3
3TWONKY MEDIA 7
4RIPSTATION MICRO DS 11
5RIPPING A LARGE COLLECTION OF CDs 11
6 THE WIRELESS CONTROL POINT, AND INSTALLING THE
LINN GUI AND CONFIG APPLICATION 12
7SNEAKY MUSIC DS INSTALLATION 13
8THE LINN CONFIG APPLICATION 16
9FINAL STEPS 19
10 TECHNICAL SPECIFICATIONS 20
The Sneaky Music DS operates within a standard Ethernet network.
There are six components involved in the network.
1 OVERVIEW
www.linn.co.uk
SNEAKY MUSIC DS
INSTALLATION AND SETUP
1. Ethernet switch
2. Wireless Access Point (WAP)
5. Wireless control point
3. PC/laptop
4. Network Attached Storage (NAS)
6. Sneaky Music DS
1
Ethernet
Analogue audio
Wireless
loudspeakers
The first two components provide network infrastructure.
1. Ethernet switch
This device is the connection point for all other components on the
network, allowing them to communicate with each other. Also required
for accessing SHOUTcast Internet radio.
2. WAP
Plugs into the switch thereby allowing wireless components to
communicate with wired ones.
A PC/laptop is required for system installation.
3. PC/laptop
The PC or laptop is a standard computer that is used during setup and
configuration of the Sneaky Music DS system. The same, or another
computer, may be used after setup to add new music to the NAS. In
order for the computer to communicate with the Sneaky Music DS
system, it must be connected to the switch.
The final three devices interact together to provide the Sneaky Music DS
music experience. They are:
4. NAS
Securely stores music on a hard drive array. Additionally, the NAS runs
three important pieces of software:
a. Media Server
Indexes and allows retrieval of the music from the NAS.
b. DHCP Server
Responsible for allocating IP addresses to all devices on the
network.
1 OVERVIEW (continued...)
www.linn.co.uk
SNEAKY MUSIC DS
INSTALLATION AND SETUP
c. Network Sharing Protocols
Allows computers to place new music on the NAS.
5. Wireless control point
Allows the user to browse, select, and control the playback of music.
It requests information about the location of the music from the Media
Server and then passes this information to the Sneaky Music DS.
6. Sneaky Music DS
Follows instructions from the wireless control point to retrieve music
from the NAS (and SHOUTcast Internet radio via the Ethernet switch),
and then transforms the digitally stored music into high quality analogue
audio. The Sneaky Music DS plays WAV, FLAC and MP3 files.
This describes a default network architecture for the Sneaky Music DS.
Many other network configurations are possible, depending on specific
requirements.
Important:
Installation of the Sneaky Music DS requires knowledge of networks and
network security. You should not attempt to install the Sneaky Music DS
unless you are comfortable working in these areas. Linn Products Limited
cannot be held responsible for any network security compromise and/or loss
of data due to improper installation.
2
To make installation easier, here we describe in detail the steps needed
to setup an Infrant ReadyNAS NV+. For other NAS devices consult the
documentation from your NAS vendor. The instructions below assume
that the NAS has been supplied with hard drives pre-installed. The RAID
configuration for the Infrant ReadyNAS NV+ is best set at X-RAID. For
other manufacturers’ devices RAID 5 should be chosen to allow easy future
expansion of storage.
1. On the installation PC/laptop disable all firewalls and the proxy server.
2. Follow the Getting Started Guide supplied with the ReadyNAS, up
to and including installing the RAIDar software. Once installed and
running, RAIDar will scan the network for the Ready NAS. If the screen
below appears, check all connections, ensure all firewalls and the proxy
server are disabled, then press ‘Rescan’.
2 SET UP OF THE NAS
www.linn.co.uk
SNEAKY MUSIC DS
INSTALLATION AND SETUP
You will be asked for a user name and password. Enter the default
user name and password as shown in the ReadyNAS installation
guide. After you log in, select ‘Next’ from the bottom-right corner.
3
When the screen below appears, select the appropriate NAS (if more
than one is available), then press ‘Setup’.
5. The ‘Ethernet’ screen
Select the IP address assignment appropriate for the network the
Akurate DS system is being installed into. Press ‘Apply’, then ‘Next’.
6. The ‘Global Network Settings’ screen
Select a hostname for the NAS, e.g. ‘nas001’. This name
should be unique to the network. This name will be used to refer
to the NAS from other devices on the network, for example the
ripping software (please refer to the Ripstation Micro DS section for
details). Leave other settings unchanged. Press ‘Apply’, then ‘Next’.
7. The ‘Admin Password’ screen
Complete the required information. Press ‘Apply’, then ‘Next’.
8. The ‘Security Mode’ screen
Nothing on this screen needs changed. Press ‘Next’.
2 SET UP OF THE NAS (continued...)
www.linn.co.uk
SNEAKY MUSIC DS
INSTALLATION AND SETUP
4
4. The ‘Alerts’ screen
Enter one or more service email contacts. If there are any problems
with the NAS, email notification will automatically be sent from the
NAS. This allows the problem to be diagnosed and corrective
action taken before the user is aware that a problem exists. Press
‘Apply’, then ‘Next’.
3. The ‘Clock’ screen
Select the appropriate timezone and time for your location. If the
‘Synchronize clock…’ checkbox is selected, deselect it. Press
‘Apply’, then ‘Next’.
11. The ‘Share List’ screen
Click on the CIFS icon on the line beginning ‘media’. This will take you
to ‘Share Options’…
2 SET UP OF THE NAS (continued...)
www.linn.co.uk
SNEAKY MUSIC DS
INSTALLATION AND SETUP
9. The ‘Standard File Protocols’ screen
Select the NFS checkbox. Leave other settings unchanged. Press
‘Apply’, then ‘Next’.
10. The ‘Streaming Services’ screen
Nothing on this screen needs changes. Press ‘Next’.
5
12. The ‘Share Options’ screen
Set the default access to ‘Read/Write’. Repeat this on the ‘NFS’,
‘HTTP/S’ and ‘Rsync’ tabs. Leave the ‘AFP’ and ‘FTP/S’ tabs set to
‘Disabled’.
Select the Advanced Options tab.
Make the following settings:
Share folder owner: media
Share folder group: nogroup
Share folder rights: Read/write
Share group rights: Read/write
Share folder everyone rights: Read/write
Uncheck ‘Set ownership and permission for existing files…’
Check ‘Grant rename and delete privileges to non-owner of files.’
This completes the initial setup of the NAS.
2 SET UP OF THE NAS (continued...)
www.linn.co.uk
SNEAKY MUSIC DS
INSTALLATION AND SETUP
6
Installing TwonkyMedia Server
To complete the installation of the Infrant ReadyNAS, TwonkyMedia Server
software has to be installed onto it. This is a UPnP media server and allows
access to all material stored on the NAS.
TwonkyMedia will present the music files to the user in such a way that they
will be ordered by Artist, Album, Artist/Album, Genre, etc… It gives various
options for searching through the music, as explained below.
3 TWONKY MEDIA
www.linn.co.uk
SNEAKY MUSIC DS
INSTALLATION AND SETUP
Downloading TwonkyMedia
TwonkyMedia for a PC or NAS other than an Infrant ReadyNAS can be
downloaded from the TwonkyMedia website: http://www.twonkymedia.
com. If you are using an Infrant ReadyNAS, download the software and
installation manual from the Linn website: http://www.linn.co.uk/ds_
software, then follow the steps below.
Suggested TwonkyMedia Setup
There are various options for setting up TwonkyMedia which will effect how
the information is displayed to the user. This can be customised for each
individual customer as required.
1. Log onto the NAS. Select ‘Advanced Control’. From the menu on the
left select ‘Services’, then ‘Streaming Services’.
2. Ensure the ‘TwonkyMedia’ service checkbox is enabled.
3. Follow the http link to connect to the TwonkyMedia server and
purchase a license from the online shop.
7
