Linksys EC1000 Instructions d'utilisation d'origine

Model No.

Quick Installation

A Division of Cisco Systems, Inc.

Model No.

WIRED

EC1000

Gigabit ExpressCard Adapter

Package Contents

• One Gigabit ExpressCard Adapter

• Setup Wizard CD-ROM with User

Guide in PDF format

• One Quick Install ation Guide

•NetworkCable

• Registration Card

AInsert the Setup Utility CD into

your PC's CD-ROM drive.

BThe Setup Utility's Welcome

screen should appear on your

monitor. If it does not, this

means the Setup Utility is not

automatically running as it

should. Start the Setup Utility

manually by clicking the Start

button, selecting Run, and typ-

ing d:\setup.exe (where "D" is

your PC's CD-ROM drive).

Click the Install button.

CThe Welcome screen will

appear. Click Next.

DThe Choose Destination Loca-

tion folder will appear next. To

install the driver in the default

folder location, click Next.

Install the Driver

AMake sure that your Notebook

PC is turned off.

BLocate your PC’s ExpressCard

slot (usually located on the

side). Insert the pin end of the

Gigabit ExpressCard Adapter

into the slot with the LEDs fac-

ing up. Make sure that the

Adapter seats firmly in place.

CConnect an Ethernet cable to

the Ethernet port on the

Adapter, then connect the

other end to the Ethernet port

on the switch or other network-

ing device.

The setup and hardware

insttallation are complete.

Install the Hardware

To install the driver in a different

folder, click Browse and select

a folder location. Then, click

Next.

EThe driver files will be copied

onto your PC.

FThis screen will appear when

the installation is complete.

Click Finish.

GClick the Exit tab to exit the Util-

ity.

Continue to Step 2 to install the

Adapter.

IMPORTANT: Make sure to run the Setup

Utility before installing the Adapter or the

Setup won’t work,

Linksys is a registered trademark or trademark of

Cisco Systems, Inc. and/or its affiliates in the U.S.

EC1000-QI-51130 KL

For additional information or troubleshooting help, refer

to the User Guide on the Setup CD-ROM. You can also call

or email for further support.

24-hour Technical Support

800-326-7114

(toll-free from US or Canada)

E-mail Support

[email protected]

Website

http://www.linksys.com or

http://support.linksys.com

RMA (Return Merchandise Authorization)

http://www.linksys.com/support

FTP Site

ftp://ftp.linksys.com

Sales Information

800-546-5797 (800-LINKSYS)
