Linear 2 GIG Go!Bridge Manuel utilisateur

2GIG-BRDG1-900

Go!Bridge IP Communicator

INSTALL INSTRUCTIONS

TheGo!Bridge™IPCommunicator(2GIG‐BRDG1‐900)provides

Internetconnectivitybetweenthemonitoringservice’sCentralStation

andtheGo!Control®Panel(requiresthe900MHzTransceiver(2GIG‐

XCVR)).

Itsupportsautomaticfirmwareupdates,providesinteractivesecurity

services,andincreasessupervisionusingsignal‐forwardingtothe

CentralStation.Tocommunicatewirelesslywiththecontrolpanel,the

900MHzTransceiverModule(2GIG‐XCVR)mustbeinstalledinthe

panelandtheGo!Bridgemustbeconnectedtothelocalnetwork

routerusinganEthernetcable(notprovided).

Box Contents

Verifythatthepackageincludesthefollowing:

•1—Go!Bridge

•1—5‐VDCUSBMini‐BPowerSupply

•1—Stand

Requirements

Beforeyouinstall,program,andtesttheGo!Bridge,ensurethecontrol

panelbeingpairedwiththeGo!Bridgemeetstheserequirements:

•FirmwareVersion1.12(orhigher)

•2GIG‐XCVR900MHzTransceiver

NOTE: Toprotectdatasentviathelocalwirelessnetwork,isit

recommendedthatyouinstalltheGo!Bridgeonalocal

networkwhereWPA(Wi‐FiProtectedAccess)orWEP(Wire

EquivalentPrivacy)Encryptionisalreadyenabled.

Afterinstalling,programming,andtestingtheGo!Bridge,youwillneed

toregisteranewcustomerwiththethird‐partymonitoringservice.

SeeRegistrationonpage2.

Figure 1 Go!Bridge Front View—LED Indicators and Learn Button

Powering ON the Go!Bridge

UsethesestepstopowerONtheGo!Bridge:

1EnsuretheGo!Bridgeisconnectedtoapowersource.

NOTE: DonotconnectanEthernetcabletotheGo!Bridgeatthis

time.Youwillconnectthecablewhencompletingthestepsin

ProgrammingtheGo!BridgeintotheControlPanel.

2(Optional)Placethestand(provided)onacounter,desktop,or

otherflatsurface.SettheGo!Bridgeinthestand.

3VerifythatthetwoLEDsontheGo!BridgeilluminateinRED(see

Figure1Go!BridgeFrontView—LEDIndicatorsandLearnButton).

NOTE: Ifthe900MHzLEDilluminatesinGREEN(thelowerLED),

verifythatthenetworkcableisnotconnectedtothe

Go!Bridge.Ifthecableisdisconnectedanditisstillilluminated

GREEN,usetheendofanopenpapercliptopressandrelease

therecessedResetbutton.Thebuttonislocatedinsidethe

smallholeontheportsideoftheGo!Bridge,directlyabove

theEthernetport.Thisrestoresthefactorysettings.SeeFigure

2Go!BridgeRearView—PortsandRecessedResetButton.

Figure 2 Go!Bridge Rear View—Ports and Recessed Reset Button

4AftertheGo!BridgeispoweredON,continuewithProgramming

theGo!BridgeintotheControlPanel.

Programming the Go!Bridge into the Control

Panel

UsethesestepstoplacethecontrolpanelandGo!Bridgeinlearning

mode.Thisgivesthecontrolpaneltheabilitytolearnthenetwork

settingstransmittedbytheGo!Bridge.

NOTE: Toscrollbetweenoponsonthecontrolpanel,tapthe←

and→arrows.Tomovetothepreviousornextprompttapthe

↑and↓arrows.

1ConnectanEthernetcable(notincluded)totherouterand

Go!Bridge.

2EnsurethecontrolpanelispoweredON.ThentaptheHome 

button.

3Tapthesystemlogointhelower‐rightcornerofthecontrolpanel

Homescreen.

4AttheEnterYourCodepage,enteryour4‐digitinstallercodetogo

totheInstallerToolbox(page1of2)page.

5AttheInstallerToolbox(page1of2)page,tapSystem

Configuration.

6AttheQ1:SelectRFSensor#(01to48)page,tapGoTo.

7AttheEnterQuestionNumber(2Digits)page,enter92.

8AtQ92SelectNetworkDevice(0to1),tap→toscrollto(1)

Go!Bridge.Thentap↓.

9AtQ:NetworkDeviceID(ReadOnly),tapLearn.Thisgivesthe

paneltheabilitytodiscovertheread‐onlynetworkdeviceID

transmittedbytheGo!Bridge.

AtthePairwithXcvrDevicepage,the“initiatinglearningprocess”

messageappears.

ANetworkLED

B 900MHzLED

CLearnbutton

ARecessedResetbutton

BEthernetport

CPowersupplyport

INSTRUCTIONS: FILE: 77-000044-001-BRDG1-900-INSTALL-INSTRUCTIONS-REVB-PRT-EN.PDF - DATE: 5/5/2014 - INK: BLACK - MATERIAL: 20 LB MEAD BOND - SIZE: 8.5"X11" - SCALE: 1 - PRINTING: FRONT AND BACK - FOLDING: FOLD TO FIT IN BOX - PAGES: 3

10 OntheGo!Bridge,pressandreleasethelearnbutton(thisisthe

small,blackplasticbuttonontheLEDsideoftheGo!Bridgebelow

the900MHzLED).ThistransmitsthedeviceIDtothecontrolpanel.

Whenthe“learnoperationsucceeded”messageappearsandthe

paneldisplaystheType(Go!Bridge)andID#,theGo!Bridgeand

panelarelinked.The900MHzLEDontheGo!Bridgealsoflashes

GREEN.

11 AtthePairwithXcvrDevicepage,tapOK.Thentap↓tocontinue

withConfiguringtheGo!BridgeSettingsbelow.

Configuring the Go!Bridge Settings

ToconfiguretheGo!Bridgesettings:

1AttheQ:SelectConfigurationSource(0to1)screentap→to

selectthe(0)DHCPsetting.ThisassignstheGo!BridgeanIP

Addressonthelocalnetwork.ItisrecommendedthatyoutapNext

toskipsteps2‐3andcontinuewithstep4.

2Ifyoutap↓(insteadofNext)instep1above,theQ:SelectPort#

(1to8)pageappears.Entertheportnumberforthethird‐party

monitoringservices’server.Thentap↓.

3AtQ:Used(0to1),tap→toselectoneoftheseoptions:

•(0)Disabled(Recommended).Thisisthedefaultsetting.Then

tapNextandskiptostep4.

•(1)Enabled.Thentap↓.AttheQ:EnterPortValue(0‐65535)

screen,tap↓toacceptthedefaultportvalue.Next,attheQ:

EnterPortForwardIPAddressscreen,tap↓toacceptthe

addressconfiguredbytheprovider.Youcanconfigureupto

eight(8)ports.Ifyouarefinishedconfiguringports,tapNext.

4AttheSummaryofNetworkDevicepage,tap↓.Verifythelistof

portnumbersandforwardIPaddressesappearsasprogrammed.

ThentapSkip.

5AtQ93EnterBroadbandNetworkFailureTime(1to255),enter

thedesirednumberofminutesthatmustpassbeforeanetwork

failuretriggersthecontrolpaneltoissueatroublealert.The

defaultvalueis30minutes.Thentap↓.

NOTE: Atroublealertconsistsofanaudiblebeepandthecontrol

panel’sHomescreendisplaysatroublemessage.

6AtQ94SelectBroadbandNetworkFailureReport(0or1),tap→

toselectwhetherornottoreportthebroadbandnetworkfailure

tothemonitoringservice:

•(1)Enabled.Thisisthedefaultsetting.Networkfailuresare

reportedtomonitoringservice.

•(0)Disabled.Networkfailuresarenotreported.

7TapEnd.

8AttheSummaryofSystemConfigurationpage,verifythesettings.

ThentapSaveChanges.

9TapExittotheclosetheSystemConfiguration.

LED Indicators

ThetablebelowdetailstheLEDcolorsfortheGo!Bridge:

Verifying the Settings

InadditiontoverifyingthesettingsafterconfiguringtheGo!Bridge,

youcanalsoverifythesettingsatanytimeasfollows:

1AtthecontrolpanelHomescreen,tapSecurity.

2TapMenu.

3TapToolbox.

4IntheEnterYourCodetoAccesstheToolboxpage,enterthe

mastercode.

5Tap→toscrolltotheToolbox(3of3)page.ThentapGo!Bridge

Status.

Asummarypagedisplaysthefollowinginformation:

•NetworkConfiguration.TheDHCPconfigurationsource.

•IPAddress.TheIPAddressfortheGo!Bridge.Thisisa32‐bit

numericaddressthatidentifiesthedeviceonthenetwork.

•SubnetMask.Thesubnetmaskforthenetwork.Alldevices

thatarejoinedtoanetworkbelongtoasubnetwork.

•Gateway.TheIPAddressfortheaccesspointtotheexternal

network.Typically,thisistheIPAddressofthelocalnetwork

routerornodethatcontroltrafficforyourISP.

•MACAddress.ThisistheMediaAccessControl(MAC)Address.

ItisaphysicaladdressthatisencodedtotheGo!Bridgeduring

themanufacturingprocess.

Testing

TheGo!Bridgeteststhenetworkconnectiontothethird‐party

monitoringservice.AreportshowsifGo!Bridgehassuccessfully

connected(orfailedtoconnect)totheexternalserver.

Registration

ToregistertheGo!Bridgewiththemonitoringservice,refertoyour

specificprovider’sregistrationinstructions.

SPECIFICATIONS

HousingMaterial ABSplasticandpoly‐carbonate

Color White

LEDs Internetand900MHz

Dualcolor(REDandGREEN)

Dimensions(LxWxD) 6.25x4.5x1in

Power 5‐VDCUSBMini‐BPowerSupply

Radio 25channelfrequency‐hoppingspreadspectrum,403kHz

channelspacing(910.2‐920.275MHz),GFSKmodulation,

128kbps,+19dBmmaximumRFpowerout

Ethernet100BASE‐T

SerialtoEthernetProcessor Texas InstrumentsStellarisCortexMS

IMPORTANT NOTE

ShouldthelocalnetworkloseInternetaccessduetoapoweroutage

orinterruption,theGo!Bridgeisnotequippedwithabatterybackup

system.Tobestprepareforpowerfailuresandtoensurethesecurity

systemmaintainsInternetaccesswiththemonitoringserviceforlife‐

safetycommunicationsduringpowerfailures,thelocalnetworkmust

haveadedicatedUninterruptedPowerSupply(UPS)orbatterybackup

solutionfromathird‐partymanufacturerinplace.LinearLLCdoesnot

supply,provide,recommend,ortesttheGo!BridgewithanyUPSor

batterybackupsolution.Itisalsoassumedthatowner’sInternet

ServiceProvider(ISP)maintainsabackupbattery(orpowergenerator)

fortheirremotenetworkequipment.

NetworkLED GlobeIcon

SolidGREEN Indicatesthepresenceofanexternalnetworkconnection.

FlashingGREEN NetworkcableispluggedinandIPaddressisactivelybeing

assigned.

SolidRED Networkcableunplugged.

900MHzLED IconLabeled“900MHz”

SolidGREEN Linkedandcommunicatingwiththecontrolpanel.

FlashingGREEN Linkedtothecontrolpanel.Communicationissuesexist.

SolidRED Notlinkedtothecontrolpanel,turnssolidafteradevicereset.

FlashingRED Notlinkedtothecontrolpanel.

REGULATORY INFORMATION

Wireless Product Notice

Radiocontrolsprovideareliablecommunicationslinkandfillan

importantneedinportablewirelesssignaling;however,thereare

somelimitationswhichmustbeobserved.

•ForUnitedStatesInstallationsOnly:Theradiosarerequiredto

complywithFCCRulesandRegulationsasPart15devices.Assuch,

theyhavelimitedtransmitterpowerandthereforelimitedrange

(approximately400ft.).

•Areceivercannotrespondtomorethanonetransmittedsignalat

atimeandmaybeblockedbyradiosignalsthatoccuronornear

theiroperatingfrequencies,regardlessofcodesettings.

• ChangesormodificationstothedevicemayvoidFCCcompliance.

• Infrequentlyusedradiolinksshouldbetestedregularlytoprotect

againstundetectedinterferenceorfault.

•Ageneralknowledgeofradioanditsvagariesshouldbegained

priortoactingasawholesaledistributorordealer,andthesefacts

shouldbecommunicatedtotheendusers.

FCC Notice

ThisdevicecomplieswithPart15oftheFCCRules.Operationis

subjecttothefollowingtwoconditions:

1Thisdevicemaynotcauseharmfulinterference,and

2Thisdevicemustacceptanyinterferencereceived,including

interferencethatmaycauseundesiredoperation.

Thisequipmenthasbeentestedandfoundtocomplywiththelimits

forClassBDigitalDevice,pursuanttoPart15oftheFCCRules.These

limitsaredesignedtoprovidereasonableprotectionagainstharmful

interferenceinaresidentialinstallation.Thisequipmentgenerates

andcanradiateradiofrequencyenergyand,ifnotinstalledandused

inaccordancewiththeinstructions,maycauseharmfulinterference

toradiocommunications.However,thereisnoguaranteethat

interferencewillnotoccurinaparticularinstallation.Ifthis

equipmentdoescauseharmfulinterferencetoradioortelevision

reception,whichcanbedeterminedbyturningtheequipmentoffand

on,theuserisencouragedtotrytocorrecttheinterferencebyoneor

moreofthefollowingmeasures.

•Reorientorrelocatethereceivingantenna

•Increasetheseparationbetweentheequipmentandreceiver

•Connecttheequipmentintoanoutletonacircuitdifferentfrom

thattowhichthereceiverisconnected

•Consultthedealeroranexperiencedradio/TVtechnicianforhelp

Anychangesormodificationsnotexpresslyapprovedbytheparty

responsibleforcompliancecouldvoidtheuser’sauthoritytooperate

theequipment.

Leschangementsoumodificationsnonapprouvésexpressémentpar

lapartieresponsabledelaconformitépourraitannulerl'autoritéde

l'utilisateuràfairefonctionnerl'équipement.

Industry Canada Notices

ThisdevicecomplieswithIndustryCanadalicense‐exemptRSS

standard(s).Operationissubjecttothefollowingtwoconditions:(1)

thisdevicemaynotcauseinterference,and(2)thisdevicemustaccept

anyinterference,includinginterferencethatmaycauseundesired

operationofthedevice.

LeprésentappareilestconformeauxCNRd'IndustrieCanada

applicablesauxappareilsradioexemptsdelicence.L'exploitationest

autoriséeauxdeuxconditionssuivantes:(1)l'appareilnedoitpas

produiredebrouillage,et(2)l'utilisateurdel'appareildoitaccepter

toutbrouillageradioélectriquesubi,mêmesilebrouillageest

susceptibled'encompromettrelefonctionnement.

Repairstocertifiedequipmentshouldbemadebyanauthorized

Canadianmaintenancefacilitydesignatedbythesupplier.Anyrepairs

oralterationsmadebytheusertothisequipment,orequipment

malfunctions,maygivethetelecommunicationscompanycauseto

requesttheusertodisconnecttheequipment.

Usersshouldensurefortheirownprotectionthattheelectrical

groundconnectionsofthepowerutility,telephonelinesandinternal

metallicwaterpipesystem,ifpresent,areconnectedtogether.This

precautionmaybeparticularlyimportantinruralareas.

WARNING: Usersshouldnotattempttomakesuchconnections

themselves,butshouldcontacttheappropriateelectric

inspectionauthority,orelectrician,asappropriate.

Limited Warranty

ThisLinearproductiswarrantedagainstdefectsinmaterialand

workmanshipfortwo(2)years.Thiswarrantyextendsonlyto

wholesalecustomerswhobuydirectfromLinearLLCorthrough

LinearLLC’snormaldistributionchannels.LinearLLCdoesnotwarrant

thisproducttoconsumers.Consumersshouldinquirefromtheir

sellingdealerastothenatureofthedealer’swarranty,ifany.

TherearenoobligationsorliabilitiesonthepartofLinearLLCfor

consequentialdamagesarisingoutoforinconnectionwithuseor

performanceofthisproductorotherindirectdamageswithrespect

tolossofproperty,revenue,orprofit,orcostofremoval,installation,

orreinstallation.Allimpliedwarrantiesforfunctionality,arevalidonly

untilthewarrantyexpires.ThisLinearLLCWarrantyisinlieuofall

otherwarrantiesexpressedorimplied.

FortechnicalsupportintheUSAandCanada:

855‐2GIG‐TECH(855‐244‐4832)

Email:2gigtechsupport@linearcorp.com

Visitwebsitefortechnicalsupporthoursofoperation

FortechnicalsupportoutsideoftheUSAandCanada:

Contactyourregionaldistributor

Visitdealer.2gig.comforalistofdistributorsinyourregion

PN:77‐000044‐001Rev.B

Ce manuel convient aux modèles suivants

Autres manuels Linear Téléphone portable

Linear

Linear UC330-VC nuLinc Manuel utilisateur

Manuels Téléphone portable populaires d'autres marques

Zte

Zte BLADE A520 Manuel utilisateur

Nokia

Nokia Lumia 620 Manuel utilisateur

Blackbe;rry

Blackbe;rry KEYone Manuel utilisateur

Bea-fon

Bea-fon X5 Premium Manuel utilisateur

Blackbe;rry

Blackbe;rry 8707 Series Manuel utilisateur

Blackbe;rry

Blackbe;rry Storm Mode d'emploi

LG LM-X420QN Manuel utilisateur

LifeWatch

LifeWatch V Manuel utilisateur

Bea-fon

Bea-fon SILVER LINE SL860 Manuel utilisateur

IKI Mobile

IKI Mobile KF4.5i Manuel utilisateur

Hitech

Hitech HT-850 Manuel utilisateur

Yezz

Yezz Fashion F10 Manuel utilisateur

Point Mobile

Point Mobile PM60 Manuel utilisateur

Blackbe;rry

Blackbe;rry Q10 Manuel utilisateur

Blackbe;rry

Blackbe;rry Bold 9900 Manuel utilisateur

Blackbe;rry

Blackbe;rry STORM 9500 - VERSION 5.0 Manuel utilisateur

LG LM-K420EMW Manuel utilisateur

ISAFE MOBILE

ISAFE MOBILE IS655.2 Manuel utilisateur
