Lincoln Electric STT-10 HEAD & CONTROLS BOOM MOUNT OR BENCH MODELS... Manuel utilisateur

STT-10 Head & Controls

Boom Mount or Bench Models

OPERATOR’S MANUAL

IM586-B

August, 2007

Safety Depends on You

Lincoln arc welding and cutting

equipment is designed and built

with safety in mind. However, your

overall safety can be increased by

proper installation ... and thought-

ful operation on your part. DO

NOT INSTALL, OPERATE OR

REPAIR THIS EQUIPMENT

WITHOUT READING THIS

MANUAL AND THE SAFETY

PRECAUTIONS CONTAINED

THROUGHOUT. And, most

importantly, think before you act

and be careful.

For use with:

STT-10 Control - Boom Mount Code 10447, 10832

10 Series Wire Drive - Boom Mount Code 10443, 10763, 10818

STT-10 Boom Package Code 10448

Synergic 7F Wire Drive Code 10190, 10191

STT-10 - Bench Model Code 10446, 10766, 10821

STT-10 - Zipline Boom Package Code 10499, 10500, 10773
