Linak TECHLINE LA25 Manuel d'instructions

Actuator LA25

Endstop signals and relative positioning - Single hall

Connection diagram

LINAK.COM/TECHLINE

FOR MOUNTING INSTRUCTIONS AND GUIDANCE IN USAGE, PLEASE SEE THE RELEVANT USER’S MANUALS

Connection diagram

2019 © LINAK A/S

Endstop signals and relative positioning - Single hall

25XXXXXXXX0K0X0X=XXXXX10XXXXXX

*YELLOW/GREEN: Endstop signals out are NOT potential free (see speciﬁcations on next page)

Tip: If you wish to use the endstop signals, you will have to keep power on the brown, blue,

red and black wires, otherwise the signal will be lost.

BROWN

BLUE

YELLOW*

GREEN*

RED

VIOLET

BLACK

FOR MOUNTING INSTRUCTIONS AND GUIDANCE IN USAGE, PLEASE SEE THE RELEVANT USER’S MANUALS

I/O Speciﬁcations

2019 © LINAK A/S

Endstop signals and relative positioning - Single hall

Input/Output Specification Comments

Description The actuator can be equipped with Single hall that

gives a relative positioning feedback signal when the

actuator moves.

See connection diagram, figure above

Brown 12-24VDC (+/-)

12V ± 20%

24V ± 10%

Under normal conditions:

12V, max. 5A depending on load

24V, max. 2.5A depending on load

To extend actuator:

Connect Brown to positive

To retract actuator:

Connect Brown to negative

Blue To extend actuator:

Connect Blue to negative

To retract actuator:

Connect Blue to positive

Red Signal power supply (+) 12-24VDC Current consumption:

Max. 40mA, also when the

actuator is not running

Black Signal power supply GND (-)

Green Endstop signal out Output voltage min. VIN - 2V

Source current max. 100mA

NOT potential free

Yellow Endstop signal in

Violet Single Hall output (PNP)

Movement per single Hall pulse:

LA25030 Actuator = 0.25 mm per pulse

LA25060 Actuator = 0.5 mm per pulse

LA25090 Actuator = 0.75 mm per pulse

LA25120 Actuator = 1.0 mm per pulse

LA25200 Actuator = 1.7 mm per pulse

Depending on load the frequecy is 10-20 Hz

Pulse ON time is minimum 8ms. OFF time between two

ON pulses is minimum 8ms.

Overvoltage on the motor can result in shorter pulses.

Output voltage min. VIN - 2V

Max. current output: 12mA

Max. 680nF

N.B. For more precise

measurements, please contact

LINAK A/S.

Low frequency with a high load.

Higher frequency with no load.

Input: Single hall output:

White Not to be connected

FOR MOUNTING INSTRUCTIONS AND GUIDANCE IN USAGE, PLEASE SEE THE RELEVANT USER’S MANUALS

The user is responsible for determining the suitability of LINAK products for speciﬁc application. LINAK takes great care in providing

accurate and up-to-date information on its products.

However, due to continuous development in order to improve its products, LINAK products are subject to frequent modiﬁcations and

changes without prior notice.Therefore, LINAK cannot guarantee the correct and actual status of said information on its products.

While LINAK uses its best efforts to fulﬁl orders, LINAK cannot, for the same reasons as mentioned above, guarantee the availability

of any particular product. Therefore, LINAK reserves the right to discontinue the sale of any product displayed on its website or listed

in its catalogues or other written material drawn up by LINAK.

All sales are subject to the Standard Terms of Sale and Delivery for LINAK. For a copy hereof, please contact LINAK.
