LIMIT LIVDK485 Manuel utilisateur
Instruction Manual
Fridge Freezer
MODEL: LIVDK485
CONTENTS
Safety warnings
Safety warnings 001
Refrigerator Features
Names of components
Refrigerating chamber
009
009
Frequently asked questions 011
Installtion Instruction
Placement Start
Human-Machine Interface and Button Operation
005
006
Maintenance of refrigerators
Cleaning
Defrost
Stop using
010
010
010
Freezing chamber 009
---
---
---
---
---
---
---
---
---
---
---
---
Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of
obstruction.
Do not use mechanical devices or other means to accelerate the defrosting process, other
than those recommended by the manufacturer.
Do not damage the refrigerant circuit.
Do not use electrical appliances inside the food storage compartments of the appliance,
unless they are of the type recommended by the manufacturer.
The appliance has to be unplugged after use and before carrying out user maintenance on
the appliance.
This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance by a person responsible for
their safety.
Children should be supervised to ensure that they do not play with the appliance.
If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or
similarly qualified persons in order to avoid a hazard.
Please abandon the refrigerator according to local regulators for it use flammable blowing
gas and refrigerant.
Please according to local regulations regarding disposal of the appliance for its flammable
refrigerant and blowing gas. Before you scrap the appliance, please take off the doors to
prevent children trapped.
This appliance is intended to be used in household and similar applications such as
-staff kitchen areas in shops, offices and other working environments;
-farm houses and by clients in hotels, motels and other residential type environments;
-bed and breakfast type environments;
-catering and similar non-retail applications.
Do not store explosive substances such as aerosol cans with a flammable propellant in this
appliance.
Safety warnings
Prohibition symbols
The symbols indicate prohibited matters, and those
behaviors are forbidden. Non-compliance with the
instructions may result in product damages or endanger
the personal safety of users.
Warning symbols
The symbols indicate matters that must be followed, and
those behaviors must be strictly executed in line with the
operation requirements. Non-compliance with the
instructions may result in product damages or endanger
the personal safety of users.
Note symbols
The symbols indicate matters to pay attention to, and
these behaviors shall be specially noted. Due
precautions are needed or minor or moderate injuries
or damages of the product will be caused.
Indicates a hazardous situation which, if not avoided,
could result in death or serious injury
Indicates a hazardous situation which, if not avoided,
will result in death or serious injury
Indicates a hazardous situation which, if not avoided,
could result in minor or moderate injury.
This chapter describes the important security matters to prevent
usersfrom injury or property damage. Please understand fully the
followingtext (logo, icon) and comply with the safety warnings.
001
Safety warnings
Please use a dedicated three-hole power socket which is 10A or
more and the power socket shall not be sharedwith other electrical
appliances.
The power cord should be firmly contacted with thesocket or else
fires might be caused. Please ensurethat the grounding electrode
of the power socket is equipped with a reliable grounding line.
Do not pull the power cord when pulling thepower plug of the
refrigerator. Please firmlygrasp the plug and pull out it from the
socket directly.
Do not damage the power cord under any condition so as to
ensure safety use, do not use when the power cord is
damaged or the plug is worn.
Worn or damaged power cord shall be replaced in
manufacture-authorized maintenance stations.
The refrigerator adopts 220-240V/50Hz AC power, voltage fluctuations
over the range of 220-240±10%V will cause malfunction or even damage,
so a 750 W automatic voltage regulator must be installed in concert
with the AC power.
Please turn off the valve of the leaking gas and then open the doors
and windows in case of leakage of gas and other flammable gases.
Do not unplug the refrigerator and other electrical appliances
considering that spark may cause a fire.
To ensure safety, it is not recommended that to place regulators,
rice cookers, microwave ovens and other appliances at the top of the
refrigerator, those recommended by the manufacture are not included.
Do not use electrical appliances in the food pantry.
Electricity related warnings
This chapter describes the important security matters to prevent
usersfrom injury or property damage. Please understand fully the
followingtext (logo, icon) and comply with the safety warnings.
002
Safety warnings
Related warnings for use
Authorized demolition or renovation of the refrigerator is not prohibited.
It is forbidden to damage the refrigerant lines and the repair and
maintenance of the refrigerator must be carried out by professionals.
Damaged power cord must be replaced by the manufacturer, its
maintenance department or related professionals in order to avoid
danger.
The surrounding of the appliances around or the embedded structure
shall not be obstructed while good ventilation shall be maintained.
The gaps between refrigerator doors and between doors and
refrigerator body are small, be noted not to put your hand in these
areas to prevent squeezing the finger. Please be gentle when
switching off the refrigerator door to avoid falling articles.
Do not pick foods or containers in the freezing chamber when the
refrigerator is running, especially metal containers in order to avoid
frostbite.
Do not allow children to enter or climb the refrigerator to prevent that
children are sealed in the refrigerator or children are injured by the
falling refrigerator.
Do not spray or wash the refrigerator; do not put the refrigerator in
moist places easy to be splashed with water so as not to affect the
electrical insulation properties of the refrigerator.
Do not place heavy objects on the top of the refrigerator considering
that objectives may fall when switching the door, and accidental
injuries might be caused.
Please pull of the plug in case of power failure or cleaning. Do not
connect the freezer to power supply within five minutes to prevent
damages to the compressor due to successive starts.
003
This chapter describes the important security matters to prevent
usersfrom injury or property damage. Please understand fully the
followingtext (logo, icon) and comply with the safety warnings.
Safety warnings
Warnings related to placing items
Do not put flammable, explosive, volatile and highly corrosive items
in the refrigerator to prevent damages to the product or fire accidents.
Do not place flammable items near the refrigerator to avoid fires.
This product is household refrigerators and shall be only suitable for
the storage of foods. According to national standards, household
refrigerators shall not be used for other purposes, such as storage
of blood, drugs or biological products.
Do not place items such as bottled or sealed container of fluid such
as bottled beers and beverages in the freezer to prevent bursts and
other losses.
Warnings related to disposal
The refrigerator's R600a refrigerant and cyclopentane foam materials are combustible materials
and discarded refrigerators should be isolated from fire sources and can not be burned.
Please transfer the freezer to qualified professional recycling companies for processing to avoid
damages to the environment or other hazards.
Please remove the door of the refrigerator and shelves which shall be properly
placed to avoid accidents of children entering and playing in the refrigerator.
004
Beer
Freezer
Corrosive s
Expl osives
Flammable
Blo od
Medici ne
biologi cals
Dry ice
Dry ic e
Do not store or place dry ice in the refrigerator.
This chapter describes the important security matters to prevent
usersfrom injury or property damage. Please understand fully the
followingtext (logo, icon) and comply with the safety warnings.
Installtion Instruction
Before using the refrigerator, remove all
packaging materials including bottom
cushions and foam pads and tapes
inside the refrigerator, tear off the
protective film on the door and the
refrigerator body.
The refrigerator is placed in a
well-ventilated indoor place; the
ground shall be flat, and sturdy
(rotate left or right to adjust the
wheel for leveling if unstable).
Keep away from heat and avoid
direct sunlight. Do not place the
freezer in moist or watery places
to prevent rust or reduction of
insulating effect.
The top space of the refrigerator shall be
greater than 30cm, and the distances from
both sides and backside shall be more
than 10 cm to facilitate the opening and
closing and heat dissipation.Wipe the
refrigerator inside and outside with warm
moist rag (add a small amount of
detergent in the warm water and wipe
clean finally with clean water).
Placement
005
The refrigerator shall stay for half an
hour before connecting 220-240V/
50Hz power when it is firstly started.
The refrigerator shall run 2 to 3
hours before loading fresh or
frozen foods; the refrigerator shall
run for more than 4 hours in summer
in advance considering that the
ambient temperature is high.
Please leave enough space to ensure
feasible opening and drawer removal.
Dimensions shown are for reference only.
Start
Placement Start
833mm
745mm
1051mm
927mm
power-on).
Human-Machine Interface and Button Operation
Keys
A.REF.TEMP
B.
C.
D.
Display
For the first power-on, the full display lasts 3s while the start-up tone rings;
then, the panel displays normally (The setting temperature of refrigerating
chamber and freezing chamber is 5℃and -18℃, respectively, upon the first
Display of normal running
Display a fault code (loop display) when a failure occurs; display the setting
temperature of refrigerating chamber when no failure occurs;
Display control
In normal cases, the display screen will display LOCK without door opening
and key operations for 30s, and then die out after 30s under the locking state;
when the display screen is off, it will light up normally with key operations;
when a failure to the category of "Visible Fault Code", the display screen turns
on and then dies out after 30s;
FRZ.TEMP
MODE
LOCK/UNLOCK
Display screen
A
B
C
D
007
Lock/Unlock
Hold the key "LOCK/UNLOCK" for 2s under the unlocking state, the system
enters the locking state and gives a buzzing sound of locking.
Hold the key "LOCK/UNLOCK" for 2s under the locking state, the system
enters the unlocking state and gives a buzzing sound of unlocking.
The system enters the locking state automatically without any key operation
for 30s.
Except that door opening alarm and fault alarm can be relieved under the
locking state as well, the following key operations must be operated under
the unlocking state. For any operation under the locking state, a buzzing
sound of wrong operation will ring.
Settings of refrigerating chamber
Temperature setting of refrigerating chamber
Press the key REF.TEMP to select the area of refrigerating temperature and
then press the key REF.TEMP to adjust the temperature of refrigerating
chamber; the temperature drops 1℃ for pressing the key REF.TEMP once;
press the key REF.TEMP again after the temperature reaches 2℃, the
refrigerating chamber is set to 8℃. The temperature setting of refrigerating
chamber varies between 2 ~8℃, which will be effective upon locking.
Settings of freezing chamber
Temperature setting of freezing chamber
Press the key FRZ.TEMP to select the freezing temperature area and then
press the key FRZ.TEMP to adjust the temperature of freezing chamber; the
temperature drops 1℃ for pressing the key FRZ.TEMP once; press the key
FRZ.TEMP again after the temperature reaches -24℃, the freezing chamber
is set to -16℃ and the temperature setting varies between -24 ~ -16℃, which
will be effective upon locking.
Mode setting
Press the key “MODE”, the corresponding modes will be circulated as below:
When the refrigerating chamber is on, cycle settings SUPER COOL→ SUPER
FRZ→SUPER COOL/SUPER FRZ→VACATION→NONE→SUPER COOL…
When the refrigerating chamber is off, cycle settings SUPER FRZ→VACATION
→NONE→SUPER FRZ…
Under the SUPER COOL mode, the refrigerating chamber defaults to 2℃
automatically; upon exiting the SUPER COOL mode, the setting temperature
of refrigerating chamber will restore to that before the SUPER COOL mode.
Under the SUPER FRZ mode, the freezing chamber defaults to -24℃
automatically; upon exiting the SUPER FRZ mode, the setting temperature of
freezing chamber will restore to that before the SUPER FRZ mode.
List of Fault Codes
008
Error Code
E1
E2
E4
E5
E6
E7
EH
Description
Temperature sensor failure of refrigerating chamber
Temperature sensor failure of freezing chamber
Failure of defrosting sensor in refrigerating chamber
Failure of freezing & defrosting sensor
Communication Failure
Failure of circulating temperature
Humidity sensor failure
Under the VACATION mode, the refrigerating chamber defaults to closed while
the freezing chamber defaults to -18℃ automatically;
Upon exiting the VACATION mode, the setting temperature of
refrigerating chamber and freezing chamber will both be restored to those
before the VACATION mode.
Table des matières
Langues :
Autres manuels LIMIT Réfrigérateur
LIMIT
LIMIT LIKO112 Manuel utilisateur
LIMIT
LIMIT LIDD326NFX Manuel utilisateur
LIMIT
LIMIT LIDD265 Manuel utilisateur
LIMIT
LIMIT LIFR98S Manuel utilisateur
LIMIT
LIMIT LIKO102 Manuel utilisateur
LIMIT
LIMIT LIFR119 Manuel utilisateur
LIMIT
LIMIT LIDD266 Manuel utilisateur
LIMIT
LIMIT LIDD161 Manuel utilisateur
LIMIT
LIMIT LIDDT217 Manuel utilisateur
