ProSpec™Track Lighting 26238W

Page 1 of 2 Wall Wash Ring PAR38

Job Information Type:

Job Name:

Cat. No.:

Lamp(s):

Notes:

Lighto ier a Genlyte Thomas Company www.lightolier.com

631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 67 - 710

We reserve the right to change details of design, materials and finish.

Features

1. Track attachment fitting: Die-cast aluminum with separate mechanical

and electrical functions. Fitting cannot be engaged or disengaged while fix-

ture is powered. Polarity is not a concern with ProSpec track because of its

symmetrical positioning of circuits within the track, adapters are reversed to

access one or the other circuit.

2. Stem: 5/8" O.D. .0 9" wall, stainless steel.

3. Horizonta Locking feature: Machined knob mechanisms permit the lock-

ing of horizontal aiming position. Adjustment range is: horizontal 0-350°.

Indicator guide with 5° intervals allows precise fixture aiming.

4. Vertica Locking feature: Machined knob mechanisms permit the locking

of vertical aiming position. Adjustment range is: vertical 0° (nadir) - 90°.

Indicator guide with 15° intervals allows precise fixture aiming

5. Lampho der: Porcelain, medium base, nickel plated screw shell, #18 ga.

braided SF-1 leads.

6. Housing: 20 ga. (.036) steel.

7. Lamp and accessory support: .032 steel, flared for easy entry of reflector

assembly, matte black finish.

8. Kick ref ector assemb y: Holds one accessory behind the spread lens;

example: color filter, UV filter, Heat filter. Assembly is removable from front

using a twist and lock motion.

9. Ref ector: Embossed texture anodized aluminum; reflects light towards

upper portion of wall and ceiling line.

10. Lever: Energizes fixture by 90° rotation.

11. C amping tabs: Expands or releases gripper springs from track ledge; grip-

per springs hold attachment fitting securely within track.

Finish

All painted finishes are powder coated baked enamel.

Ordering Information

Cata og No. Finishes Mountings Lamps

26238W WH Matte White ProSpec™Track System PAR38 250W Max.

26238W BK Matte Black

Options & Accessories

Accessories: 3/" dia. series. Filters, lenses, screens and louvers.

150W max when using accessories. Holds one accessory behind the

spread lens. Order accessories separately

E ectrica

Electrical components: Polycarbonate moldings.

Contacts: Heavy gauge 1/2 hard brass developed for Lightolier's "U"

shaped track conductors.

Labe s

UL; I.B.E.W.

5-3/4"

11-3/4"

14-1/8"

ProSpec Track System

10-1/8"

Pivot

ProSpec™Track Lighting 26238W

Page 2 of 2 Wall Wash Ring PAR38

Lighto ier a Genlyte Thomas Company www.lightolier.com

631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 67 - 710

We reserve the right to change details of design, materials and finish.

DISTANCE TO SIDE OF UNIT

6" 12" 18" 24" 30" 36" 42" 48"

011.0 6.5 5.5 3.0 2.0 1.5 1.0 0.5 0.5 19.5 16.5 19.5 15.0 10.5 15.0

170.065.034.012.05.58.01.51.01.097.0109.597.080.048.580.0

2115.0 110.0 66.0 26.0 9.0 3.5 2.0 1.0 1.0 171.0 190.5 171.0 129.0 95.0 129.0

2.5 140.0 130.0 80.0 36.0 14.0 4.5 2.5 1.5 1.0 217.0 231.0 217.0 160.0 120.0 160.0

3 120.0 115.0 77.0 39.0 16.5 6.0 2.5 1.5 1.5 203.0 217.0 203.0 144.0 120.0 144.0

448.0 48.0 40.0 24.0 14.0 7.5 3.0 2.0 1.5 102.0 113.0 102.5 71.0 69.0 71.0

517.0 17.0 16.0 11.5 8.5 5.5 3.0 2.0 1.5 46.5 51.0 46.5 33.0 32.5 33.0

6 8.0 7.0 8.0 6.0 5.0 3.5 2.8 2.0 1.5 25.5 27.0 25.5 18.5 18.5 1 8.5

7 4.0 4.0 5.0 3.5 3.0 3.0 2.0 2.0 1.0 15.0 18.5 15.0 12.0 12.5 12.0

82.5 3.0 3.0 2.5 2.5 2.5 2.0 1.5 0.5 11.5 14.0 11.5 9.0 0.0 9.0

10'-0" Ceiling Height Track 40" from Wall*

DISTANCE TO SIDE OF UNIT

12' 24' 36' 48" 60' 72" 84'

06.05.02.52.52.01.00.50.012.09.512.07.56.07.5

113.011.09.03.52-01.00.50.521.524.021.517.013.517.0

2 23.0 18.0 12.0 4.5 3.0 1.0 0.5 0.5 82.5 83.0 82.5 26.0 18.0 26.0

3 25.0 28.0 14.5 5.0 8.0 1.0 0.5 0.5 86.5 40.5 36.5 28.0 21.0 28.0

4 33.0 27.0 15.0 6.0 2.5 1.0 0.5 0.5 48.0 45.0 48.0 36.0 22.5 36.0

4.5 34.0 28.0 16.0 6.0 2.5 1.0 1.0 0.5 48.0 47.0 48.0 37.0 23.5 37.0

5 28.0 25.0 15.0 6.0 2.5 1.5 1.0 0.5 41.0 43.0 41.0 31.5 22.0 81.5

6 20.0 18.0 13.0 5.5 2.0 1.5 1.0 0.5 82.0 34.0 32.0 28.5 20.0 23.5

715.018.09.04.01.51.51.01.025.025.025.018.014.518.0

810.08.56.03.01.51.51.01.018.018.018.018.010.513.0

98.07.04.52.01.51.51.01.014.014.014.011.08.511.0

10 5.0 4.0 8.5 1.5 1.5 1.5 1.0 1.0 9.0 10.5 9.0 7.5 6.5 7.5

12'-0" Ceiling Height Track 66" from Wall*

DISTANCE TO SIDE OF UNIT

12' 24' 36' 48' 60' 72' 84' 96'

03.53.02.52.01.01.00.50.50.55.05.05.04.03.042

15.55.04.03.01.51.00.50.50.57.57.57.56.03.56.2

28.07.55.53.52.01.51.00.50.510.510.010.58.55.08.8

39.08.57.04.52.51.51.04.00.512.012.012.09.55.59.8

410.010.08.05.58.02.01.01.00.518.514.518.510.56.510.6

512.512.010.06.53.52.01.01.00.517.017.517.013.58.013.4

615.014.011.07.54.52.51.51.01.020.020.020.016.59.516.4

6.5 15.0 14.0 11.0 8.0 4.5 3.0 1.5 1.0 0.5 21.5 20.5 21.5 16.5 10.0 16.4

714.012.510.57.54.58.01.51.00.520.019.520.015.09.515.6

812.511.510.07.04.03.01.51.50.518.518.018.513.59.015.6

910.09.08.06.04.08.01.51.50.516.015.016.011.08.511.2

10 8.5 8.0 7.0 5.0 4.0 3.0 1.5 1.5 0.5 14.0 18.5 14.0 19.5 8.5 19.6

11 7.0 6.5 6.0 4.5 8.0 8.0 1.5 1.5 0.5 12.5 11.0 12.5 7.5 7.0 7.6

12 5.5 5.0 4.2 3.0 3.0 2.0 1.5 1.5 0.5 9.5 8.5 9.5 6.0 6.5 6.2

Lighting Data: 150W PAR38 FL

FOOTCANDLES ON WALL: Single Units Multiple Units†

EXAMPLE: With track located 40" from wal and

multiple units spaced 38" on center and aimed

60∫from horizontal, the illumination on wall

5' 6" from floor will be 48 f.c. beneath units

and 47 f.c. between units.

38"40"

48 f.c.

47 f.c.

60°

5'-6"

8'-0" Ceiling Height Track 22" from Wall*

Track Dist.

from Wall

Track Dist.

from Wall

Track Dist.

from Wall

*At recommended track distance from wall for

corresponding ceiling height, wall washer will

provide maximum Illumination at eye level

(5' 6' above floor) when aimed 60 from horizontal

(I.E.S. recommended practice).

† Footcandles shown In table for multiple units are

based on a minimum of 5 units when on 18", 27", or

38" centers and 8 units when on 57" 62", or 98"

centers.

Footcandle values are based on average room

conditions.
