Lightolier 6" Cloud Manuel utilisateur

For Factory Technical Infor ation: (978) 657-7600 • Fax (978) 658-0595

631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710

We reserve the right to change details of design, aterials and finish.

Lightolier is a Philips group brand

07/09

Job Information Type:

Job Name:

Cat. No.:

Lamp(s):

Volts/Ballast:

Bel ont 6" Cloud

Page 1 of 2 Surface Mount Fluorescent, 24", 36 or 48" Lengths

2 La p T8

• 6" white opal acrylic lens (vacuum formed).

• Can be horizontally or vertically wall mounted.

• Can be ceiling mounted.

• Efficiency 69.0%.

• Lens secured to body with screws at ends..

• Quarter turn latch secures channel cover for easy wireway access.

• Heavy duty channel of code gauge die formed steel.

• Fully enclosed wiring.

• UL Listed snap-on end caps (body).

• Green grounding screw installed in channel.

Features Dimensions

(102mm)

24" (610mm) or 36" (914mm)

K.O. (8)

6" (152mm)

4-1/8"

(105mm)

4-1/8"

(105mm)

6" (152mm)

4-5/8"

(117mm)

2' or 3' Channel

(102mm)

48" (1219mm)

4' Channel

1-1/8"

(29mm)

6-3/8" (162mm) 2" Dia. K.O.

with 7/8" Dia. K.O. 7/8" Dia. K.O. (4) K.O. (8)

•

26-1/2" (673mm) 38-1/2" (978mm)

•

50-1/2" (1282mm)

•

For Factory Technical Infor ation: (978) 657-7600 • Fax (978) 658-0595

631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710

We reserve the right to change details of design, aterials and finish.

Job Information Type:

Lightolier is a Philips group brand

Angle End 45.0 Cross

0 708 708 708

5 702 707 707

15 688 693 698

25 624 649 673

35 551 595 639

45 457 535 599

55 349 472 560

65 221 402 511

75 108 339 453

85 20 280 403

95 19 246 364

105 49 226 330

115 79 212 306

125 108 186 261

135 128 167 226

145 138 147 186

155 152 123 152

165 162 108 143

175 167 162 157

Specifications

Materials: Chassis parts are die-formed heavy gauge code cold rolled steel,

4-1/8" channel width.

Ballast Cover: Code gauge steel secured with quarter turn latch.

Lens: 6" white opal acrylic lens (vacuum formed).

Finish: Chassis exterior phosphate undercoating, baked white

polyester enamel.

Electrical: Thermally protected class “P” ballast, non PCB. If K.O. is within 3"

of ballast, use wire suitable for at least 90°.

Labels: I.B.E.W./UL and ULc Listed.

This product may have a mercury containing lamp. Manage in accord with

Disposal Laws. See: www.lamprecycle.org

Bel ont 6" Cloud

Page 2 of 2 Surface Mount Fluorescent, 24", 36 or 48" Lengths

2 La p T8

Chassis

Model No. SW4S232HPFUNVHI

with shielding BCW6X48

LER = FP - 69.0 IW - 29.6 BF - 0.88

Comparative yearly lighting energy cost per

1000 lumens = $3.87

Ordering Information

NOTE: Chassis and shielding are packed in separate cartons. When ordering, enter as separate line items.

Report Number: 19743

Lamp: F32T8

Luminaire: Belmont 6" Cloud, 24", 36" or

48" Lengths, 2 Lamp T8

Ballast: Electronic

Report is based on 2850 Lumens per lamp.

Efficiency: 69.0%

CIE Type-Direct-Indirect

Plane: 0-Deg 90-Deg

Spacing Criteria: 1.2 1.2

CANDLEPOWER0

AVERAGE AVERAGE AVERAGE AVERAGE

IN DEG. 0-DEG. 45-DEG. CROSS

45 3092. 2648. 2737.

55 2832. 2537. 2725.

65 2329. 2446. 2748.

75 1696. 2461. 2818.

85 655. 2619. 3085.

LUMINANCE DATA IN CANDELA/SQ. METER

COEFFICIENTS OF UTILIZATION

ZONAL CAVITY METHOD. EFFECTIVE

FLOOR CAVITY REFLECTANCE 0.200

PCC 80 70 50

RCR 70 50 30 70 50 30 50 30

01 68 64 60 64 60 57 54 51

02 60 55 50 57 52 46 46 41

03 56 47 41 52 45 40 40 35

04 51 41 35 46 40 34 34 30

05 46 36 30 42 34 28 30 27

06 42 33 27 40 30 26 28 23

07 39 29 23 36 28 23 25 20

08 36 27 20 34 26 20 23 19

09 34 25 19 32 23 17 20 17

10 32 23 17 29 22 17 20 14 ZONE LUMENS % LAMP % FIXT

00-030 562 9.9 14.3

00-040 936 16.4 23.8

00-060 1764 31.0 44.9

00-090 2762 48.5 70.3

90-180 1169 20.5 29.7

00-180 3931 69.0 100.0

LIGHT DISTRIBUTION

Length Shielding Chassis Lamp Ballast 20THD 10THD

2' BCW6X24 SW2S217HPFUNVHI2-T8 2 Lamp Elec. T8 HI

3' BCW6X36 SW3S225HPFUNVHI2-T8 2 Lamp Elec. T8 HI

4' BCW6X48 SW4S232HPFUNVHI2-T8 2 Lamp Elec. T8 HI

NOTE: Chassis and shielding shown are stock items. For other ballast options see Folio H110-42.NOTE: UNV =120-277.
