Lightline Lasertechnik Laserlink Manuel utilisateur

Preliminary Manual

Manual

Introduction

Dear customer,

thank you for choosing the Laserlink lasercontroller, which links lighting operators with showlasers in

real time.

The Laserlink is the 2nd Generation of the former successful Lightline DMX-Box.

Main feature is to operate a lasersystem easy as a lighting fixture from any lighting console.

For that DMX, ARTNET1 and RDM can be used.

Hence, the laserlink has up to 2 individual ILDA outputs being able to supply 2 independent scanning

systems with 16-bit XY-Scanning and 16-bit RGBO data as a standalone unit or can be mounted

directly into a lasersystem.

For automatic effects like rotations, all systems are synchronized by DMX protocol.

Another main feature is the possibility of using Syncronorm Depence2 WYSIWYG visualization. It is

fully integrated into the software without need of hardware.

As the standalone unit it is very small size and is very easy to integrate into your stage setup as there

is a mount for TV-Bolt or clamp and safety eye bolt.

Please, read the following safety notes carefully, especially before you connect the device to a laser

projector rated more than class 1.

1 Art-Net™ is Designed by and Copyright Artistic Licence Holdings Ltd.

Preliminary Manual

Content

Introduction ............................................................................................................................................. 1

Safety Notes ............................................................................................................................................ 4

Packaging List: ......................................................................................................................................... 6

Installation of the system: ....................................................................................................................... 6

Laserlink PINOUT ..................................................................................................................................... 7

DMX Sheet for Fixture: .......................................................................................................................... 10

Patching: ................................................................................................................................................ 11

First startup: .......................................................................................................................................... 11

Adjustable values and value ranges. ..................................................................................................... 12

Main Screen ........................................................................................................................................... 13

CONTROL SETUP ................................................................................................................................ 14

Scanner Setup .................................................................................................................................... 17

System Setup ..................................................................................................................................... 20

Network Settings ............................................................................................................................... 21

Touchscreen Calibration .................................................................................................................... 22

Factory Settings ................................................................................................................................. 23

Error Log ............................................................................................................................................ 23

Update System .................................................................................................................................. 24

Reboot System .................................................................................................................................. 24

Testpicture ......................................................................................................................................... 25

Color calibration ................................................................................................................................ 31

Load/Save config ............................................................................................................................... 34

RDM operation ...................................................................................................................................... 35

General RDM Commands: ................................................................................................................. 35

RDM Commands Output 1: ............................................................................................................... 36

RDM Commands Output 2: ............................................................................................................... 37

DMX functionality: ................................................................................................................................. 38

Safety Channel ................................................................................................................................... 38

Service coarse 8-bit 0..255 ................................................................................................................ 38

Shutter/Strobe coarse 8-bit 0 .. 255 .................................................................................................. 39

Dimmer /Dimmer fine coarse 16-bit 0..65535 .................................................................................. 39

RED coarse linear 8-bit 0 .. 255 ......................................................................................................... 39

GREEN coarse linear 8-bit 0 .. 255 ..................................................................................................... 39

BLUE coarse linear 8-bit 0 .. 255 ........................................................................................................ 39

Preliminary Manual

Orange coarse linear 8-bit 0 .. 255 .................................................................................................... 39

PAN/ PAN fine coarse 16-bit 0 .. 65535 (- 32.768 .. 32767) ........................................................... 40

TILT/ TILT fine coarse 16-bit 0 .. 65535 (- 32.768 .. 32767) ........................................................... 40

Gobo coarse 8-bit 0 .. 255 ................................................................................................................. 40

ROT Z/ ROTZ fine coarse 16-bit 0..65535 (- 32.768 .. 32767) ........................................................ 42

Color1 Colorsegments coarse 8-bit 0 .. 255 ...................................................................................... 42

Color1 Colorspeed coarse 8-bit 0 .. 255 ............................................................................................ 44

Color2 Colorsegments coarse 8-bit 0 .. 255 ...................................................................................... 44

Color2 Colorspeed coarse 8-bit 0 .. 255 ............................................................................................ 46

ColorXFade coarse 8-bit 0 .. 255 ........................................................................................................ 46

ZOOM/ ZOOM fine coarse 16-bit 0 .. 65535 .................................................................................... 46

ROT X/ ROTX fine coarse 16-bit 0..65535 (- 32.768 .. 32767) ........................................................ 47

ROT Y/ ROTY fine coarse 16-bit 0 .. 65535 (- 32.768 .. 32767) ...................................................... 47

Modifier 1 Select coarse 8-bit 0 .. 255 .............................................................................................. 48

Modifier 1 Speed coarse 8-bit 0 .. 255 .............................................................................................. 49

Modifier 2 Select coarse 8-bit 0 .. 255 .............................................................................................. 50

Modifier 2 Speed coarse 8-bit 0 .. 255 .............................................................................................. 50

Delay/Point repeat coarse 8-bit 0 .. 255 ........................................................................................... 51

Laserlink Technical Data ........................................................................................................................ 52

Preliminary Manual

Safety Notes

 Each person which is responsible for the installation, the use or service of this unit must be:

 qualified

 together with a laser: must have a "Laserschutzbeauftragtenschein" or must be a

certified laser-safety officer.

 must follow the instructions in this manual.

WARNING!

Be careful when using the device. You risk an electrical shock from high voltage, if you touch the

wires!

Install and use according to the valid laser safety rules of your country.

 The device has left our company in manufacturer proofed state. To maintain this status and

to ensure a permanent safe operation, it is absolutely necessary to follow the safety

instructions and warnings in this manual.

IMPORTANT!

Errors caused by not following these instructions are not covered by the warranty. The

manufacturer will not accept liability for any resulting defects or problems.

 Keep the unit away from radiators or other heat sources!

 If the unit has been exposed to tremendous temperature changes (e.g. after transportation),

do not turn it on immediately. The resulting condensation could damage the unit. Don`t

switch unit on until the device reaches room temperature.

 This device belongs to protection class I. Therefore, it is imperative that the green/yellow

wire is connected to the earth contact of the plug. The electrical connection must be made

by a qualified person.

 Make sure that the cable has never been squeezed or damaged by sharp objects. Check

the device and the cables regularly.

 If the cable is damaged, it must be replaced immediately by the manufacturer, its service

agent or a qualified person in order to avoid danger.

 Ensure that wires never come in contact with other wires! Handle the power cord and all

connections with caution!

 Make sure that the line voltage is not higher than the voltage specified in this manual.

 Disconnect the unit from the AC mains when it is not in use or when cleaning it.

 Disconnect connections only by pulling the cable plug.

Preliminary Manual

Optical safety in use together with a connected lasersystem

RISK OF EYE INJURIES! RISK TO HEALTH!

 Never stare into direct or scattered beam! Never point laser beams into the audience or

towards people. Do not point laser beams to animals.

 Do not stare at laser light reflected from any surface.

 Do not use laser in the presence of inflammable, explosives, or volatile solvents such as

alcohol or gasoline.

 Direct eye contact with the output beam will cause serious injury and possible blindness.

 Defects caused by modifications of the device by unqualified handling or an unqualified person

are not covered by the warranty.

 Keep the product away from children and unskilled people.

 There are no wear parts in the device. Maintenance and service must be performed only by an

authorized service partner.

 Disconnect the unit from the AC mains when not in use or when cleaning it.

 Laser beams might be also powerful enough to burn skin or clothing. Laser beams can ignite

volatile substances such as alcohol and can damage light-sensitive elements in video

cameras, and video beamer.

Preliminary Manual

Packaging List:

The Laserlink comes in following OEM configuration:

1 pieces of Laserlink

1 pieces of Neutrik Powercon True1 cable

Optional:

- Safety eye bolt, Safety 50cm

- Manfrotto clamp

- TV-bolt

- DMX Adapters

- Cat cable

- ILDA-Cable

Installation of the system:

Preliminary Manual

Laserlink PINOUT

Output connectors D-SUB 25 pol ILDA-Standard

It is recommended to use a standard 25 pol DSUB extension cable

Signal name: Pin Notes:

X + 1 0 to +10V

Y + 2 0V to 10V

Blanking + 3 Not connected

Interlock A 4 Connected Pin 17

R + 5 Red, 0V to + 5V

G + 6 Green, 0V to +5V

B + 7 Blue (typically 476nm), 0V to +5V

Deep Blue+ 8 Not connected

ORANGE+ 9 Orange, 0V to +5V

Cyan+ 10 Not connected

Z + 11 Not connected

Not connected 12 Not connected

Shutter 13 Shutter 0V off 5V on

X - 14 Connected to Ground pin 25

Y - 15 Connected to Ground pin 25

Blanking - 16 Not connected

Interlock B 17 Connected Pin 4

R - 18 Connected to Ground pin 25

G - 19 Connected to Ground pin 25

B - 20 Connected to Ground pin 25

Deep blue - 21 Not connected

Yellow - 22 Connected to Ground pin 25

Cyan - 23 Not connected

Z - 24 Not connected

Ground 25 GND

Preliminary Manual

DMX 512-Connection:

The laserlink is equipped with 5-pin XLR sockets for DMX in and DMX out.

The sockets are wired in parallel.

PINOUT DMX 5 pole Connector

Female Male

Pin Description

1 GND

2 Signal –

3 Signal +

4 not connected

5 not connected

For more than one Laserlink module you can daisychain:

Connect the DMX-Out from console to the DMX-IN of the first fixture. Then Connect DMX-Out to DMX-

IN of the second fixture and so on.

Attention: In some cases, the DMX-line has to be terminated with a 120OHM resistor at the last fixture

between Signal + and Signal –.

Note: The Laserlink is no Artnet Node. It’s not possible to go via Artnet to Laserlink No. 1 and from

there further on with DMX.

Preliminary Manual

Ethernet RJ45 connection

The Laserlink can be connected via Ethernet/Artnet to the NET socket. The Art-Net protocol is based

on UDP. Artnet has the advantage that you can send a larger number of channels than DMX 512.

For ARTNET communication you have to set an IP Address for identification and the Universe for the

DMX512 frame and channels.

The pinout of the Ethernet RJ45 connector is:

Pin Description

J1 TD+

J2 TD-

J3 RX+

J4 not connected

J5 not connected

J6 RX-

J7 not connected

J8 not connected

Connection to Mains

The Laserlink has an autoranging powersupply that goes from 100 to 240VAC and 50/60Hz.

Plug Marking

Connection

Live

brown

black

Neutral

blue

white

Earth

Yellow/green

green

Note: For proper connection consult a qualified electrician.

Preliminary Manual

DMX Sheet for Fixture:

The Laserlink has one basic DMX-sheet which can be easily copied 4 times to get full access and

output of the Laserlink device:

Channel Laserlink Description Default

1 Safetychannel Safetychannel 0%

2 Servicechannel Output 1 Blanking options

3 Shutter/Strobe Shutter/ Strobe 100%

4 Dimmer 16 Bit 0%

5 Dimmer Fine

6 Red 0-255 100%

7 Green 0-255 100%

8 Blue 0-255 100%

9 Orange 0-255 100%

10 Pan PAN 16 bit 50%

11 Pan Fine

12 Tilt TILT 16 bit 50%

13 Tilt Fine

14 Gobo Maximum 255

15 RotZ Rotation Z 16-bit 50%

16 RotZ-Fine

17 Color 1 Colorsegments 255 Colorgobos 0-255 0

18 Color 1 Colorspeed Colorspeed 0-255 0

19 Color 2 Colorsegments 255 Colorgobos 0-255 0

20 Color 2 Colorspeed Colorspeed 0-255 0

21 Color X-Fade7mix Fade Colorprogram 1 into Colorprogram 2 0

22 Zoom ZOOM 16 Bit 50%

23 Zoom Fine

24 Rot X Rotation X 16 Bit 50%

25 Rot X Fine

26 Rot Y Rotation Y 16 Bit 50%

27 Rot Y Fine

28 Modifier 1 Animationseffects like Prism, Sparkle etc. 0

29 Modifier speed 1 Effect Speed 0

30 Modifier 2 Visible, Oscillate etc. 0

31 Modifier Speed 2 Effect Speed 0

32 Delay/Point Repeat Scanrate 0

Table des matières

Manuels Matériel de DJ populaires d'autres marques

ALPHA LITE

ALPHA LITE ALPHA 1500 Manuel du propriétaire

Chauvet

Chauvet OVATION E-930VW Manuel utilisateur

Zumtobel

Zumtobel APHRODITE Home Manuel utilisateur

Snow Masters

Snow Masters Zig Oscillator Manuel utilisateur

EuroLite

EuroLite 50530554 Manuel utilisateur

Beamz

Beamz BUV243 Manuel utilisateur

thomann

thomann Stairville DJ Lase 40-G MK-III Manuel utilisateur

Eagletone

Eagletone 6 Eyes Flower Manuel utilisateur

EuroLite

EuroLite FLD-1508 Manuel utilisateur

Technical Pro

Technical Pro LG8xSEA Manuel utilisateur

JB Systems

JB Systems Lounge Laser DMX Manuel utilisateur

Lightmaxx

Lightmaxx Vega Halo 90 Manuel utilisateur

Elation

Elation FUZE WASH Z350 Manuel utilisateur

Maverick

Maverick MK3 WASH Manuel utilisateur

Infinity

Infinity TF-260C7 Fresnel Manuel utilisateur

Chauvet

Chauvet EVE E-50Z Manuel utilisateur

Eliminator Lighting

Eliminator Lighting E 138 Manuel utilisateur

EuroLite

EuroLite Mini Multicolor LED Flashing Light SC Manuel utilisateur
