light-for-me!
User’s Manual!
3XML Alexandra RCA head*!
!
Light-for-me 3XML Alexandra head:!
!
- 3 x XML diodes!
- 4th red signalling diode!
- 3600 lumens!
- light angle: 13 degrees!
-36 W!
- piezo switch!
- three modes of light: 10%, 50% and 100%!
- control over LEDs temperature!
- control over battery pack discharge!
- made from anodised aluminium!
- detachable cable!
- cable length:!
!!standard: 110cm!
!!SideMount (custom made): up to 123cm!
!
!
3XML Alexandra head can be powered by light-for-me ACCUS with compatible RCA cable
entry point. Burn time (given at 100% power) depends on the battery pack and is as
follows:!
!
ACCU XS 4.4Ah: !2.2h!
ACCU S 6.6Ah: !3.2h!
ACCU M 11.25Ah: !5.2h!
ACCU L 20Ah: !9.6h!
!
Given burn times may differ from actual burn time +/- 10%.!
Given burn times are based on battery packs provided by light-for-me only.!
Given burn times are based on one head connected only.!
!
4th red signalling diode - this diode lights up when:!
- there is a break in connection head - battery pack; this can happen if the RCA plug was
not connected properly to the port or when the RCA plug or port are rusty/dirty;!
-the battery pack voltage is too low to power the head;!
-there is an error on the driver board.!
In all the above situations the red diode flashes!
!
*This manual refers to 3XML Alexandra head & 3XML Alexandra Heavy-Duty hea!
www.light-for-me.com
Before the dive!
Check the head’s visual condition - see if the front glass is not chipped or broken. Check
the cable - if it is cut or damaged, do not dive! Check the cable’s RCA plug - it should be
clean and dry, remove any dust or sand with a clean tissue (see photo below).!
!
!
Put the head’s RCA plug into the ACCUs cable
entry, press it slightly and turn the rotating cap
tightly.!
!
!
Check if the head is working by pressing the
piezo switch - make sure the torch is not
switched on for more than 10-15 seconds on
the surface.!
!
!
!
!
!
!
!
After the dive!
Before disconnecting the head from the canister, rinse the whole set (head plus accu) well
in fresh water. Dry the head, cable and RCA connection point (plug and canister’s top)
completely before disconnecting the RCA plug from the canister. !
To disconnect the plug from the canister, turn the rotating nut in an anti-clockwise direction
and pull it firmly. Do not pull by the cable.!
Immediately after disconnecting the cable’s RCA plug - dry it.!
Check the visual condition of the head again.!
!
!
Between the dives!
Store the head in a dry place. !
Store the head disconnected from the ACCU to prevent accidental turning on. !
!
!
!
