LG WM2688H*M Guide d'installation

WM2688H*M Steam Washer Training

PRODUCT TRAINING

WM2688H*M Discovery Steam Washer

WM2688H*M Steam Washer Training

Contact Information

Customer Service (and Part Sales) (800) 243-0000

Technical Support (and Part Sales) (800) 847-7597

USA Website us.lgservice.com

Customer Service Website us.lgservice.com

B2B Service Website biz.lgservice.com

LG CS Academy lgcsacademy.com

Published March 2006 by LG Technical Support and Training

T- 2

WM2688H*M Steam Washer Training

Preliminary Matters (The Fine Print)

IMPORTANT SAFETY NOTICE

The information in this training manual is intended for use by persons

possessing an adequate background in electrical equipment, electronic

devices, and mechanical systems. In any attempt to repair a major

appliance, personal injury and property damage can result. The

manufacturer or seller maintains no liability for the interpretation of this

information, nor can it assume any liability in conjunction with its use.

When servicing this product, under no circumstances should the

original design be modified or altered without permission from LG

Electronics. Unauthorized modifications will not only void the warranty,

but may lead to property damage or user injury. If wires, screws, clips,

straps, nuts, or washers used to complete a ground path are removed

for service, they must be returned to their original positions and

properly fastened.

T- 3

WM2688H*M Steam Washer Training

Preliminary Matters (The Fine Print)

CAUTION

To avoid personal injury, disconnect the power before servicing this

product. If electrical power is required for diagnosis or test purposes,

disconnect the power immediately after performing the necessary checks.

Also be aware that many household appliances present a weight hazard.

At least two people should be involved in the installation or servicing of

such devices. Failure to consider the weight of an appliance could result in

physical injury.

T- 3

WM2688H*M Steam Washer Training

Preliminary Matters (The Fine Print)

ESD NOTICE

Some of the electronic in appliances are electrostatic discharge (ESD)

sensitive. ESD can weaken or damage the electronics in these appliances

in a manner that renders them inoperative or reduces the time until their

next failure. Connect an ESD wrist strap to a ground connection point or

unpainted metal in the appliance. Alternatively, you can touch your finger

repeatedly to a ground connection point or unpainted metal in the

appliance. Before removing a replacement part from its package, touch the

anti-static bag to a ground connection point or unpainted metal in the

appliance. Handle the electronic control assembly by its edges only. When

repackaging a failed electronic control assembly in an anti-static bag,

observe these same precautions.

T- 3

WM2688H*M Steam Washer Training

Preliminary Matters (The Fine Print)

REGULATORY INFORMATION

This equipment has been tested and found to comply with the limits for a

Class B digital device, pursuant to Part 15 of the FCC Rules. These limits

are designed to provide reasonable protection against harmful interference

when the equipment is operated in a residential installation. This

equipment generates, uses, and can radiate radio frequency energy, and,

if not installed and used in accordance with the instruction manual, may

cause harmful interference to radio communications. However, there is no

guarantee that interference will not occur in a particular installation. If this

equipment does cause harmful interference to radio or television reception,

which can be determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of the

following measures: Reorient or relocate the receiving antenna; Increase

the separation between the equipment and the receiver; Connect the

equipment to an outlet on a different circuit than that to which the receiver

is connected; or consult the dealer or an experienced radio/TV technician

for help.

T- 3

WM2688H*M Steam Washer Training

Preliminary Matters (The Fine Print)

COMPLIANCE

The responsible party for this device’s compliance is:

LG Electronics Alabama, Inc.

201 James Record Road,

Huntsville, AL, 35824.

T- 3

WM2688H*M Steam Washer Training

Introduction

The DISCOVERY series of washers and dryers is the top of

the line and includes every option and feature.

Most notable are the steam generator and the LCD display.

T- 6

WM2688H*M Steam Washer Training

Specifications

T- 6

WM2688H*M Steam Washer Training

Features

LARGE CAPACITY

The larger drum (4.0 cu. ft.) allows washing of

larger (heavier) loads and oversized items

(comforters, curtains, blankets, etc.) There is less

wrinkling and tangling of the laundry.

DIRECT DRIVE

The brushless DC motor drives the drum directly

without belts, pulleys, or transmissions. The

maximum spin speed of 1,320 RPM extracts more

water from the laundry, reducing drying times.

TILTED DRUM/LARGE DOOR

The tilted drum (10°) and large door opening allow

easier loading and unloading.

T- 7
