LG CodeZero A9 Series Manuel utilisateur

Condential

MFL68043161_Rev00. 08252021

CodeZero

SERVICE MANUAL

For Vacuum and Auto Empty charging Station Set Model

CAUTION

BEFORE SERVICING THE UNIT, READ THE SAFETY PRECAUTIONS IN THIS MANUAL.

Buyer Model Name : A9******

Factory Model Name : S99******

Any reproduction, duplication, distribution (including by way of email, facsimile or other electronic means), publication, modification, copying or transmission of this

Service Manual is STRICTLY PROHIBITED unless you have obtained the prior written consent of the LG Electronics entity from which you received this Service

Manual. The material covered by this prohibition includes, without limitation, any text, graphics or logos in this Service Manual.

-2-

Only training and service purposes

Table of Contents

■LG CodeZoro Vacuum ...................................................................................................3

■LG CodeZero Auto Empty Charging Station..............................................................54

Condential

MFL68043160_Rev00. 08252021

CodeZero

SERVICE MANUAL

CAUTION

BEFORE SERVICING THE UNIT, READ THE SAFETY PRECAUTIONS IN THIS MANUAL.

Buyer Model Name : A9******

Factory Model Name : S99******

Any reproduction, duplication, distribution (including by way of email, facsimile or other electronic means), publication, modification, copying or transmission of this

Service Manual is STRICTLY PROHIBITED unless you have obtained the prior written consent of the LG Electronics entity from which you received this Service

Manual. The material covered by this prohibition includes, without limitation, any text, graphics or logos in this Service Manual.

-4-

Only training and service purposes

Table of Contents

■Product Specifications ................................................5

■Structure and name of each part .................................6

■Vacuum features ...........................................................8

■Before Use .....................................................................9

■Precautions and directions for use ..........................10

■Maintenance ................................................................13

■Technical Note on the Part .........................................14

■Directions for Use ......................................................15

■Using the Smart Function ..........................................24

■How to Disassemble, Reassemble

and Repair Main Parts ................................................26

■Safety precautions and checkpoints for repairs......36

■Actual wiring diagram ................................................37

■Circuit diagram ...........................................................38

■Failures and measures ..............................................43

■Cleaning function operation and error modes ........46

■Exploded view of structure and list of parts ...........47

Only training and service purposes

Product Specifications

Classification Name Specification

Product Body

Model S9******

Dimensions Width 260 mm X Length 270 mm X Height 1120 mm

Weight Approximately 2.6 kg

Power

consumption

Turbo mode 370 W (up to 590 W)

High mode 120 W

Standard mode 68 W

Battery run time

(based on dual

batteries*1)

When using the power drive nozzle*3

•Up to 12 minutes in the Turbo mode

•Up to 40 minutes in the High mode

•Up to 80 minutes in the Standard mode

•80 minutes in the Mop-only mode*4 (recommended hours of use)

When using the product without a nozzle mounted

•Up to 14 minutes in the Turbo mode

•Up to 60 minutes in the High mode

•Up to 120 minutes in the Standard mode

Battery run time

(based on single

battery*2)

When using the power drive nozzle

• Up to 6 minutes in the Turbo mode

• Up to 20 minutes in the High mode

• Up to 40 minutes in the Standard mode

• 80 minutes in the Mop-only mode (recommended hours of use)

When using the product without a nozzle mounted

•Up to 7 minutes in the Turbo mode

•Up to 30 minutes in the High mode

•Up to 60 minutes in the Standard mode

Battery

Model name EAC633822**

Type Rechargeable lithium-ion battery

Rating DC 25.2 V / 2300 mAh / 1EA or 2EA

*1 It is measured at room temperature based on the company test criteria, using two fully charged batteries in the product via Wi-Fi connection. (One new battery fully charged while

attached to the product body and another new battery fully charged in the charging compartment of the charging station)

*2 It is measured at room temperature based on the company test criteria, using one new fully charged battery in the battery charging compartment of the charging station while

connected to Wi-Fi.

*3 The battery run time may become shorter if the power drive nozzle (a slim nozzle for floors, carpets, quilts and mops) which contains a motor that directly rotates the rotating brush or

the mop plate is used. If may vary depending on the environment and the service life.

*4 The battery run time in the Mop-only mode is based on the time for which the mop rotates. As it differs from the period of available water supply, fill the tank with water if there is no

water in the tank when using the product.

NOTE

•Dual batteries (two) or a single battery (one) is provided, depending on the model.

•Dimensions include the product body, expandable pipe and nozzle.

-6-

Only training and service purposes

Structure and name of each part

Only training and service purposes

Structure and name of each part

-8-

Only training and service purposes

Vacuum features

1. The product has a high level of suction power, which can be adjusted according to the

area to be cleaned.

Strong suction powered by an inverter motor can be adjusted using the Suction Control

button according to the area to be cleaned.

2. Featuring an anti-tangle power nozzle

Removes ultrafine dust.

3. Featuring dual lithium batteries (for applicable models only)

Two long-life lithium batteries eliminate the need to recharge during cleaning. Based on

the Standard mode, each battery can be used for approximately 40 minutes when fully

charged, allowing up to approximately 80 minutes cleaning.

4. Wireless type vacuum

A wireless type vacuum solves problems related to limited cord length.

Only training and service purposes

Before Use

Useful Information

Make sure that the exhaust filter or free filter is assembled correctly.

•Make sure the dust bin lid is closed properly before use. If the dust bin lid is open, the

suction power will decrease, and it will affect the cleaning performance.

•If foreign objects block the nozzle, expandable pipe or inlet, the product may not work

properly. Remove the following foreign objects before cleaning:

−Foreign objects that may block the nozzle: Tissues, pantihose, plastic bags, etc.

−Foreign objects that may degrade the performance: Small toys, toothpicks and cotton

swabs

•Static electricity can be generated by the product body through environmental factors

such as temperature and humidity. If the problem persists, contact the LG Electronics

Service Centre.

•When cleaning a high place, support the bottom of the product body with your hand.

•Remove small stones, sands, fine dust, etc., from the brush of the nozzle to prevent a

coated floor from being scratched.

•Follow the manufacturer’s recommendations when cleaning floors, carpets and rugs.

•Do not clean a TV, LCD or monitor with a nozzle, because its surface may be scratched.

•Do not vacuum large quantities of cookies or nutshells which are light in weight at the

one time.

•For the following foreign objects, remove the nozzle or expandable pipe and adjust the

suction power to High or Turbo mode before cleaning them:

−Heavy foreign objects, such as coins, screws and landscaping stones- Foreign

objects, such as beans, that can bounce off the rotating brush

•For battery run times, refer to the product specifications in the user manual. Battery run

times may vary according to the mode used and the type of floor being cleaned.

-10-

Only training and service purposes

Precautions and directions for use
