www.lg.com
*MFL69561901*
SIMPLE MANUAL
Portable
Bluetooth Speaker
MODELS
PH1 / PH1R / PH1L
2
Safety Information
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER (OR
BACK) NO USER-SERVICEABLE PARTS INSIDE REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.
This lightning ash with arrowhead symbol within an equilateral triangle is
intended to alert the user to the presence of uninsulated dangerous voltage
within the product’s enclosure that may be of sufcient magnitude to constitute
a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the user
to the presence of important operating and maintenance (servicing) instructions
in the literature accompanying the product.
WARNING:
yTo prevent re or electric shock hazard, do not expose this product to rain or moisture.
yDo not install this equipment in a conned space such as a book case or similar unit.
yThis unit contains magnets which can be harmful to some kind of object
(Ex : Magnetic card, Pacemaker etc..).
CAUTION:
yDo not block any ventilation openings. Install in accordance with the manufacturer’s
instructions. Slots and openings in the cabinet are provided for ventilation and to ensure
reliable operation of the product and to protect it from over heating. The openings shall be
never be blocked by placing the product on a bed, sofa, rug or other similar surface. This
product shall not be placed in a built-in installation such as a bookcase or rack unless proper
ventilation is provided or the manufacturer’s instruction has been adhered to.
3
yThe apparatus should not be exposed to water (dripping or splashing) and no objects lled
with liquids, such as vases, should be placed on the apparatus.
yNo naked ame sources, such as lighted candles, should be placed on the apparatus.
yIt is recommended that you use the 5 V AC adapter (more than 1.8 A) with this device.
If you do not use the recommended adapter, charging is unavailable or charging time may
differ.
yTo avoid re or electric shock, do not open the unit. contact to qualied personnel only.
yDo not leave the unit in a place near the heating appliances or subject to direct sunlight,
moisture, or mechanical shock.
yTo clean the unit, use a soft, dry cloth. If the surfaces are extremely dirty, use a soft cloth lightly
moistened with a mild detergent solution. Do not use strong solvents such as alcohol, benzine,
or thinner, as these might damage the surface of the unit.
yDo not use volatile liquids such as insecticide spray near the unit. Wiping with strong pressure
may damage the surface. Do not leave rubber or plastic products in contact with the unit for a
long period of time.
yDo not place the unit over the vehicle’s air bag. When the air bag deploys, it may result in injury.
Before using in the car, x the unit.
yDo not use the handsfree function during driving a car.
yDo not leave the unit on an unstable place such as high shelves. it may fall down because of
the vibration of the sound.
yDo not use high voltage products around this product. (ex. Electrical swatter) This product may
malfunction due to electrical shock.
4
CAUTION when using this product in environments of low humidity.
yIt may cause static electricity in environments of low humidity.
yIt is recommended to use this product after touching any metal object which conducts
electricity.
CAUTION concerning the Power Cord
The Power Plug is the disconnecting device. In case of an emergency, the Power Plug must
remain readily accessible.
NOTICE: For safety marking information including product identication and supply ratings, please
refer to the main label on the bottom or the other surface of the product.
This device is equipped with a portable battery or accumulator.
Safety way to remove the battery or the battery from the equipment: Remove the old battery
or battery pack, follow the steps in reverse order than the assembly. To prevent contamination
of the environment and bring on possible threat to human and animal health, the old battery or
the battery put it in the appropriate container at designated collection points. Do not dispose
of batteries or battery together with other waste. It is recommended that you use local, free
reimbursement systems batteries and accumulators. The battery should not be exposed to
excessive heat such as sunshine, re or the like.
Do not remove battery incorporated with product for your safety. If you need to replace the
battery, take it to the nearest authorized LG Electronics service point or dealer for assistance.
5
Power Power On / Off ..................... Hold
Bluetooth
To pair your mobile device, select LG PH1 (xx) from
device list.
When successfully Paired, Bluetooth LED will turn on.
Playback
Controls
Play / Pause ........................ Press
Forward Skip ....................... Press X2
Backward Skip ..................... Press X3
Handsfree
Function Receive / Disconnect................ Press
AC Adapter
(Not supplied)
Off : Full Charged
On : Charging
Blink : Low Battery (Power on)
Portable input
6
Mood LED light Controls
Mood LED light Turn On / Off ........................ Hold
Speaker Power On:
Various colors / White color / Music-synchronized .... Press
Speaker Power Off:
Various colors / White color ......................... Press
Important Notice
yFully charge the device before using for the rst time.
yIt is recommended that you use the 5 V AC adapter (more than 1.8 A) with this
unit.
yPress and hold the button for more than 2 seconds to turn on or off the unit.
yBluetooth connection using the TV, PC or dongle is not supported.
yResetting
- In case that the unit freezes due to malfunction, press and buttons
at the same time.
7
Specification
Power Supply:
- 5 V 0 1.8 A (AC Adapter)
- Built-in rechargeable battery
Power consumption:
- 2.5 W
Dimensions (W x H x D):
Approx. 81 mm X 88 mm X 82 mm
Net Weight: Approx. 0.19 kg
Operating Temperature: 0 °C to 35 °C
Operating Humidity: 5 % to 60 %
External Connector:
- ø 3.5 mm mini jack
- Micro USB port for charging battery
Communication: Bluetooth
Speaker:
- Type : Built-in
- Impedance Rate : 4 Ω
- Rated Input Power : 2 W
- Max. Input Power : 4 W
Battery :
- Battery capacity : 700 mAh
- Operating time is approx. 5 hours. It may
vary depending on the battery status and
operational conditions.
yDesign and specications are subject to
change without notice.
For more information, download the online owner’s manual. http://www.lg.com
