LG GP3 Manuel utilisateur

OWNER’S MANUAL

GAMING SPEAKER

Please read this manual carefully before operating your set and retain it for future

reference.

Model

GP3

www.lg.com

2112_Rev01

MFL71861502

Gaming Speaker Quick Guide

Connecting and Using the Speaker

AAC Adapter (Not supplied)

aCharge the speaker before using it by opening the rear cover and

connect the speaker to an AC adapter(not supplied).

Note

• When you use the supplied USB cable, please use a separate USB port. The black USB port is for data transfer

or charging, and white USB port is only for charging.

Soundbar Quick Guide

bConnect the speaker to the PC via a USB cable ([See

“Connecting via USB Cable” on page 10.)

AConnect the speaker to the PC via a USB C-type cable.

BPress the Power button on the speaker to turn it on.

CPress the Function button on the speaker repeatedly until the function LED turns white.

If you are using a voice chat through integrated microphone or headset, press the Microphone button.

cConnect the speaker to a smartphone via Bluetooth ([See

“Connecting to Bluetooth” on page 13.)

APress the Power button on the speaker to turn it on.

BPress the Function button on the speaker repeatedly until the function LED turns blue.

CPress the Settings button on the smartphone and select Bluetooth. Turn on the Bluetooth function. (

Off > On)

DFind "LG-GP3 (XX)" on the device list on the smartphone and connect to it. Once the smartphone is

connected via Bluetooth, the Function LED turns blue.

EOn the smartphone, play a music of your choice

dConnecting the LG XBOOM App ([See “Connecting to the

GAMING SPEAKER App” on page 19.)

AFind the LG XBOOM app on the Google Play or App Store and install it on your smartphone.

BRun the LG XBOOM app and use more features (EQ , Voice Chat, Setting etc.)

Press and hold the Headset button for 2 seconds to turn the logo lighting on or off.

If you are using a headset or earphones, connect it to the terminal.

Table of Contents

Gaming Speaker Quick Guide

2Connecting and Using the Speaker

Exploring the Product

5Top

7Back

Charge

8Charging the Battery

9Checking Battery Status

Connecting via USB Cable

10 Connecting to PC for Gaming

12 Using Voice Chat

Connecting to Bluetooth

13 Connecting Smartphone to the Speaker via

Bluetooth

16 Connecting Two Bluetooth Devices to the

Speaker

17 Talking on the Phone Hands-free

18 Using Voice command

Connecting to the GAMING

SPEAKER App

19 Installing app

20 Installing PC app

Additional Functions

21 Setting Sound Effects

25 Resetting the Speaker

25 Resetting Bluetooth

26 Using Auto Power Off

Safety Precautions

27 Safety and Regulatory

Before Reporting Product

Malfunction

30 Troubleshooting

Appendix

32 Specications

33 Registered Trademarks and Licenses

34 Open Source Software Notice Information

34 Handling the Product

Exploring the Product

Top

a b c e

aPower Turns the speaker on or off.

Power LED Press and hold the Power button for 2 seconds to check the battery level

while the power or the speaker is on. ([See “Checking Battery Status” on page

9.)

Function Press the button repeatedly to select the desired input mode or function.

Input Mode/Function How to Use

USB/Bluetooth Press the button.

Connect to another smartphone Press and hold the button for 2

seconds.

Reset Bluetooth Press and hold the button for 7

seconds.

Function LED Indicates the input mode or Bluetooth connection status.

LED Input

Mode LED Status Description

USB Turns on in

white. Connect to the PC.

Bluetooth Blinks in blue. Ready for Bluetooth device

connection.

Bluetooth Turns on in

blue. Connected to a Bluetooth device.

Exploring the Product

Headset - Switches the sound output between the headset or earphones and the speaker

while the headset or earphones is connected.

- Press the button to receive an incoming call on the Bluetooth device while

Bluetooth is connected. ([See “Talking on the Phone Hands-free” on page

17.)

- Press and hold the button for 2 seconds while the speaker is on to turn the

logo lighting on or off.

Headset LED You can check the sound output status of the headset, earphones or the speaker.

bVolume You can turn the button to the right (+) or left (-) to adjust the sound volume.

cMicrophone - You can use voice chat while the speaker is connected to the PC via a USB

cable. ([See “Using Voice Chat” on page 12.)

- You can use voice command while the speaker is connected to Bluetooth. ([

See “Using Voice command” on page 18.)

- You can mute the sound of your own voice when talking on the phone through

the speaker while it is connected to Bluetooth. ([See “Talking on the Phone

Hands-free” on page 17.)

Microphone LED You can check the voice chat, voice command, and hands-free status.

dBuilt-in

microphone

You can use the built-in microphone for voice chat, voice command, and hands-

free functions.

eFPS /RTS /

Pressthebuttontoselectthedesiredsoundeldeffect.([See “Setting Sound

Effects” on page 21.)

FPS/RTS/EQ LED Youcanchecktheselectedsoundeldeffect.

flogo light You can adjust the logo light using the LG XBOOM app.

Back

a b c

aRESET When the speaker does not function properly, use a sharp object such as a pin

to press the hole.

bDC IN 5 V 02 A Plug in a USB (C-Type) cable to connect the speaker to the PC.

Or connect an AC adapter to charge the speaker.

cPlug in the headset or earphones wire to connect it to the speaker.

• The microphone on the headset can only be used for voice chat in the USB

mode.

dBack Cover Make sure to fully close the back cover after use.

>CAUTION

Use caution when handling the speaker. The speaker on the rear is exposed. Avoid making contact with the

exposed speaker.

Charge

Charging the Battery

Thespeakerisabuilt-inbattery.Makesuretochargethebatterysufcientlybeforeuse.

a Open the back cover and connect the USB cable to DC IN 5 V 02 A port of the speaker.

b Connect the supplied USB cable to the AC adapter.

c Plug the AC power cord into an AC outlet.

Note

• It takes about 3.5 hours to fully charge the speaker. The charging time may differ depending on the battery

status or the speaker operation status.

• Once the battery is fully charged, you can use the speaker for about 6 hours.

- This is based on a continuous use with the volume level at 50% and the logo light and sound effects off. It

may vary depending on the battery or the operation status.

>CAUTION

AC adapter is not supplied. It is recommended that you use the 5 V AC adapter approved by LG Electronics Inc.

(more than 2 A) with this speaker because of danger of explosion. If you do not use the recommended adapter,

charging is unavailable or charging time may differ.

Charge

Checking Battery Status

Charging Status

Once the battery charging starts, the power LED indicates the charging status.

LED LED Status Battery Status

Turns on and off in green 15

seconds. Charging is complete.

It is red. Charging is in progress.

Note

• Playing tracks while charging may lengthen the charging time.

Use Status

When you turn on the speaker or press and hold the Power button for 2 seconds, the power LED is turned on

for 3 seconds according to the battery status.

LED LED Status Battery Status

Turns on in green. The battery level is above 70%.

Turns on in amber. The battery level is between

10~70%.

Blinks in red.

The battery level is below 10%,

and the battery needs to be

charged.

Note

• The battery status cannot be checked while charging.

Connecting via USB Cable

You can connect the device to a gaming PC to enjoy deep and rich sounds.

You can play your PC games with more realistic sounds.

Connecting to PC for Gaming

Please check the following rst.

• This product can be used with gaming PCs and laptops that support UAC* (USB Audio Class)

• GP3supportsUAC*1.0specication.

- It is not supported when connecting devices other than a PC or laptop via USB cable.

* UAC(USB Audio Class): Digital audio connection standard that uses a USB interface.

• ItmaynotworkproperlydependingonthespecicationsofdevicethatsupportUAC(USBAudioClass)

For more information, contact your device manufacturer.

• Thespeaker’sPCspecicationsareasfollows:

- Windows OS: 10 version (20H2)

- MAC OS: 11.2 version

It is recommended to use the speaker with this version or later.

• If PC's Speaker be set up 7.1 channel on PC it could be better the FPS sound effect.

a Open the back cover of the speaker and connect the DC IN 5 V 02 A to the PC’s USB terminal via

a USB cable.

Connecting via USB Cable
