OWNER'S MANUAL

LG CLOUD T SERIES BOX

CBT42

Please read the safety information carefully before using the product.

LG Cloud T Series Box Model List

ENG

English

Table of Contents

3 ASSEMBLING AND

PREPARING

3 Unpacking

4 PartsandButtons

5 ProductInstallation

5 - UsinginHorizontalPosition

5 - UsinginVerticalPosition

5 - MountingontheBackoftheMonitor

6 CONNECTING LAN/

PERIPHERALS

6 - LANConnection

6 - DVIConnection

7 - ExtendedMonitorConnection

7 - Peripheraldeviceconnection

9 TROUBLESHOOTING

10 SPECIFICATIONS

10 PowerIndicator

ENG

English

ASSEMBLING AND PREPARING

MainUnit StandBase MountBracket

PowerCordOwner'sManual/Card FourScrews

AC/DCAdapter

ASSEMBLING AND PREPARING

Unpacking

Pleasecheckwhetherallthecomponentsareincludedintheboxbeforeusingtheproduct.Ifthereare

missingcomponents,contacttheretailstorewhereyoupurchasedtheproduct.Notethattheproductand

componentsmaylookdifferentfromthoseshownhere.

 OnlyuseanapprovedLGpoweradapter.

 Damagecausedbyotherpoweradaptersisnotcoveredbywarranty.

 Notethatthecomponentsmaylookdifferentfromthoseshownhere.

 Withoutpriornotice,allinformationandspecificationsinthismanualaresubjecttochangetoimprove

theperformanceoftheproduct.

 Topurchaseoptionalaccessories,visitanelectronicsstoreoronlineshoppingsiteorcontacttheretail

storewhereyoupurchasedtheproduct.

CAUTION

NOTE

ENG

English

ASSEMBLING AND PREPARING

Parts and Buttons

Power Indicator &

Power Button

 On:PowerOn

 Off:PowerOff

InputConnectors

Front Side

Rear Side

ENG

English

ASSEMBLING AND PREPARING

Product Installation

Using in Horizontal Position

Using in Vertical Position

1 Firmlyattachthestandonthebottomofthe

productasillustratedbelow.

2 Usingacoin,turnthescrewclockwiseto

securethestandbase.

Mounting on the Back of the

Monitor

1 Fixthemountbracketonthebackofthe

monitorwith4screwsasillustratedbelow.

2 Puttheproductonthetwolatchesasillustrated

below.

Assembletheproductbyaligningthebelow

twoholesoutof4holesontheproduct.

 Attachthestand

basetothe

standhingewith

itsfrontpartfac-

ingforward.

 Ifthisproductisusedwithupsidedown,it

maynotworkproperly.

 UsetheproductwiththeKensingtonlock

facingupward.

NOTE

 Theproductmaynotbemountedonsome

monitorswithmountbracket.

-Inthiscase,usetheproductinhorizontal

orverticalposition.

 Whenconnectingtheperipheralsafter

mountingtheproductonthemonitor,be

suretoholdtheproduct.

CAUTION

NOTE

ENG

English

Connecting LAN/Peripherals

CONNECTING LAN/PERIPHERALS

DVI Connection

Transmitsdigitalvideosignalstothemonitor.Con-

necttheproductusingtheDVIcableasillustrated

below.

 Connecttheinputsignalcable

andturninthedirectionofthe

arrow.Topreventdisconnection

securethecabletightly.

 TheLANcableissoldseparately.

 ThefollowingLANcabletypecanbeused:

Standard:IEEE802.3ETHERNET

 ConnecttheLANcableandtheperipheralde-

vicestousetheCITRIXcloudmonitor.

 Whenconnectingthepowercordtothe

outlet,useagrounded(3-hole)multi-socket

oragroundedpoweroutlet.

 DVIcableisnotincludedinthebasiccom-

ponents.UsetheDVIcableprovidedwith

themonitororthestandardDVIcable.

CAUTION

NOTE

LAN Connection

Connecttherouterorswitchtothemonitorusinga

LANcableasillustratedbelow.

ENG

English

Connecting LAN/Peripherals

 Ifthemain/subscreenwaschangedafter

extendedmonitorwasconnected,themain/

subcanbechangedinSetup.

Extended Monitor Connection

Transmitsanalogsignalstothemonitor.Connect

theproductusingtheD-subcableasillustrated

below.

Peripheral device connection

UsetheUSB,microphone,andheadphoneportto

connectaperipheraldevicetotheBOX.Connect

asillustrated.

Front Side

Rear Side

NOTE

ENG

English

Connecting LAN/Peripherals

 Thecloudserversettingsmayaffecttheperfor-

manceoftheheadphones,earphonesorspeak-

ersdependingontheconnectedcloudserver.

 Thecloudserversettingsmayaffectthe

functionsorspeedofthespecificUSBstor-

agedevicedependingontheconnected

cloudserver.

 Peripheraldevicesaresoldseparately.

 TheUSBportscanbeusedtoconnectthe

keyboard,mouse,andotherUSBdevices.

 Foranangleplugearphone/microphone,itis

difficultconnectitwithaperipheraldevice,so

useastraighttype.

AngleType StraightType

NOTE

ENG

English

TROUBLESHOOTING

Nothing is displayed on the screen

IsthepoweradapteroftheBox

pluggedin?



Checkifthepowercordiscorrectlypluggedintothepoweroutlet.

Isthepowerindicatoron? 

Checkthepowerindicator.

Isthepowerindicatordisplayingas

red?



Adjustthebrightnessandthecontrastoftheconnectedmonitor.

AretheBOXandthemonitorcon-

nectedwiththesignalcable?



CheckwhetherthemonitorandtheBoxareproperlyconnectedtoDVI

cableorD-SUBcable(usingDVItoD-Subgender).

 Thisboxtypeproductisusedbyconnectingthemonitor.

 Ifthemonitordoesnotworknormally,thescreenmaynotbedisplayedcorrectly.

NOTE

ENG

English

SPECIFICATIONS

SupportedDis-

playResolution

(D-SUB,DVI-D)

MaximumResolution 1920x1200@60Hz

RecommendedResolution 1920x1200@60Hz

Power Voltage 19V 1.2A

Powerconsumption(Typ.)

(Cloud)

CloudMode8W

OffMode≤0.5W

Dimension Dimensions(WidthxHeightxDepth)

Withstand 70.3mmx189.3mmx143.6mm

WithoutStand 185mmx30.5mmx143.6mm

Weight(Without

Packaging)

0.65kg

AC/DCadapter TypeADS-40SG-19-319025G,manufacturedbySHENZHENHONORELECTRONIC

OrTypeLCAP21,manufacturedbyLIENCHANGELECTRONICENTERPRISE

OrTypePSAB-L203A,manufacturedbyLGInnotekCo.,Ltd

Output:19V 1.3A

Environmental

Conditions

OperatingCondition Temperature:10°Cto35°C;Humidity:10%to80%

StoringCondition Temperature:-20°Cto60°C;Humidity:5%to90%

Thespecificationsaresubjecttochangewithoutnotice.

Power Indicator

Mode LED Color

OnMode Red

OffMode Off
